Shenzhen Shichuangxinke Electronics Co.,Ltd
professional makes good quality, provide perfect product and service for every customer.
 |
| Place of Origin: | China ,Guang Dong |
| Brand Name: | Shichuangxinke |
| Certification: | CE RoHS FCC CCC TUV UL |
| Model Number: | SCXK-P25 |
| Minimum Order Quantity: | 1 square meters |
|---|---|
| Price: | negotiation |
| Packaging Details: | wooden box flight case, wooden case, carton, it is up to you. |
| Delivery Time: | 7-10 working days after deposit payment received |
| Payment Terms: | L/C, T/T, Western Union, D/A, D/P |
| Supply Ability: | 5000sqm per month |
| Pixel Pitch: | 25mm | Pixel Configuration: | 1R1G1B |
|---|---|---|---|
| Scanning Mode: | Static Full Color | Module Size: | 200x200mm |
| Cabinet Size: | 1600x1200mm | Certificates: | CE RoHS FCC CCC UL |
| Application: | Stadium,airport,shopping Mall,street Advertising | Material: | Aluminum |
| Warranty: | 2-3 Years | ||
| Highlight: | advertising led display board,advertising led billboard |
||
1R1G1B Ultra Thin Rental Outdoor Led Screen Video Wall 25mm Pixel Pitch
Features
1. High-quality LED: Adopt wafer direct-insert LED, with excellent anti-static and anti-ultraviolet performance; waterproof patch three-in-one LED lamp beads: IP65 grade, all-weather use, white balance performance is far better than direct-insert series.
2. Energy saving: low current, high brightness lamp beads, equipped with PFC switching power supply, saving 30% power.
3. High refresh rate, high grayscale: Adopt PWM driver IC, up to 16bit, refresh rate greater than 5000HZ, still maintain high grayscale at low brightness.
4. Color correction: support point-to-point correction to ensure the consistency of LED color and brightness, and the new screen has no color difference.
5. Dual backup: power supply and system dual backup are optional, with reliable performance.
6. Error detection and monitoring: can monitor internal temperature, voltage, cooling fan, etc., and automatically detect errors.
Applications
Applied to outdoor places such as station, port, airport, meeting room, shopping mall, hotel, building, stadium etc. It uses as video and information display.
Specifications
| outdoor DIP P25 | |||||
| Resolution/mm | 25 | ||||
| Pixel configuration | 1R1G1B | ||||
| Pixel density/pixels/m² | 1600/m² | ||||
| Module resolution | 8x8 | ||||
| Module size/mm | 200x200MM | ||||
| View distance | 14-300m | ||||
| Single point brightness adjust | Can be added | ||||
| Single point color adjust | Can be added | ||||
| White balance brightness | >7500cd/㎡ | ||||
| Color temperature | 6500K-9500K | ||||
| Horizontal view angle | 120(degrees) | ||||
| Vertical view angle | 60(degrees) | ||||
| Signal Process bit | 10 or 16bit | ||||
| Grey process | 1024x1024x1024 16834x16834x16834 65536x65536x65536 | ||||
| Control distances | Internet cable:100m, multimembrane:500m, monofilm:2km | ||||
| Driving mode | Constant driving current | ||||
| Scanning mode | 1/4 SCANNING | ||||
| Frame rate | 60Hz | ||||
| Refresh frequency | >3000Hz | ||||
| Control mode | Computer synchronous | ||||
| Brightness adjusted range | Manual, automatic operation, stepless continuous adjusted | ||||
| 255 steps. No grey loss | |||||
| Out of control point | <1/10000 | ||||
| Working hours | ≥72hours | ||||
| Mean Time Between Failure | >5000hours | ||||
| Life time | 100000hours | ||||
| Life-all-white(brightness halving) | 50000hours | ||||
| Environment temperature range | Operating temperature range: -20-45℃ | ||||
| Self-check technology | LED spot self-check, communications check, power check, | ||||
| temperature monitor(need customization) | |||||
| Remote monitoring | Remote supervision and control, record potential fault, | ||||
| send out warning signs to the operators.(need customization) | |||||
| Software environment | WindowsNT,Windows1999,WindowsXP | ||||
| Luminous point width between centres | Deviation<3% | ||||
| Brightness uniformity | <10% | ||||
| Color uniformity(chromaticity coordinate) | ±0.003 | ||||
| Power supply request | AC85-264V(50Hz-60Hz) | ||||
| Contrast | (1000:1) | ||||
| System protection | Moistureproof,dustproof,high temperature protection,anti-corrosion,anti-burning,anti-static,anti-vibration | ||||
| Humidity(working) | working:10-95% | ||||
| Humidity(storing) | storing:10-95% | ||||
Trade Info
1). Trade terms: FOB, CIF, EXW
2). Payment methods: T/T, Western Union, PayPal, Escrow, MoneyGram
3). Payment methods: T/T, 30% deposit before production, 70% balance before shipment
4). Production cycle: 8-15 days for less than 20 square meters, 30 days for more than 50 square meters. Samples can be delivered within 3 days
5). Transportation methods: Sea, air and express
6). Port of shipment: Shenzhen, Mainland China
Contact Person: Lillian seori
Tel: +8619386814677
