Name: P4 Indoor Full Color SMD LED Video Wall 4mm Pixel Pitch 640x640mm Cabinet
Brand: Shenzhen ShiXin Display Technology Co.,Ltd
SKU: P4
Price: 10000.00 USD
Availability: InStock

Home Products Indoor Full Color LED Display

P4 Indoor Full Color SMD LED Video Wall 4mm Pixel Pitch 640x640mm Cabinet

Product Details:

Place of Origin:	Shenzhen in China
Brand Name:	SCXK
Certification:	CE/ROHS/FCC/ISO/CB/UL
Model Number:	P4

Payment & Shipping Terms:

Minimum Order Quantity:	3 pcs
Price:	negotiation
Packaging Details:	flight case, wooden case, carton, it is up to you.
Delivery Time:	7-10 working days after receive your payment
Payment Terms:	T/T,Western Union
Supply Ability:	5000 sqm per month

Contact Now

Detailed Product Description

Pixel Pitch:	4mm	Led Type:	SMD2727
Display Function:	Video/Text/Image	Waterproof:	IP43
Cabinet Material:	Die Catsing Aluminum Or Iron	Viewing Angle:	H:160 V:140
Voltage:	DC5V	Brightness:	More Than 1000cd/㎡
Module:	320*160mm	Cabinet:	640*640mm
Highlight:	indoor led display screen , indoor led billboard

HD P4 Indoor SMD Back Stage Background Rental Full Color Large LED Video Wall Display Screen

LED displays, also called LED screens, LED video walls, or LED signs, with their unique advantages, have gradually replaced traditional billboards and light boxes. LED display advertising has become a powerful force in the media industry.
Unlike traditional advertising that can only show static pictures, LED displays perfectly combine text, images, video, and sound with high resolution, brightness, and full color. These dynamic displays easily attract attention and create memorable advertising experiences with greater effectiveness.
LED display screens are widely applied in media advertising, transportation, security, real estate, and stage show backgrounds.

Product Specifications

Specification	Indoor SMD P4
Lamp size	2121
Resolution/mm	4
Pixel configuration	RGB 3 in 1
Pixel density/pixels/m²	62500/m²
Module resolution	32x32
Module size/mm	128x128
View distance	≥4m
Single point brightness adjust	Can be added
Single point color adjust	Can be added
White balance brightness	>2000cd/㎡
Color temperature	6500K-9500K
Horizontal view angle	120(degrees)
Vertical view angle	120(degrees)
Signal Process bit	10 or 14 bit
Grey process	1024x1024x1024 16834x16834x16834 65536x65536x65536
Control distances	Internet cable:100m, multimembrane:500m, monofilm:5km
Driving mode	Constant driving current
Scanning mode	1/16
Frame rate	60Hz
Refresh frequency	>1200Hz
Control mode	Computer synchronous
Brightness adjusted range	Manual, automatic operation, stepless continuous adjusted 255 steps. No grey loss
Out of control point	<1/10000
Working hours	≥72hours
Mean Time Between Failure	>5000hours
Life time	100000hours
Life-all-white(brightness halving)	50000hours
Environment temperature range	Operating temperature range: -20-45℃ Storing temperature range: -30-65℃
Maximum power:/㎡	<1100W
Average power:/㎡	<280W
Self-check technology	LED spot self-check, communications check, power check, temperature monitor(need customization)
Remote monitoring	Remote supervision and control, record potential fault, send out warning signs to the operators.(need customization)
Software environment	WindowsNT,Windows1999,WindowsXP
Luminous point width between centres	Deviation<3%
Brightness uniformity	<10%
Color uniformity(chromaticity coordinate)	±0.003
Power supply request	AC85-264V(50Hz-60Hz)
Contrast	(3000:1)
System protection	Moistureproof,dustproof,high temperature protection,anti-corrosion,anti-burning,anti-static,anti-vibration
Humidity(working)	working:10-95%
Humidity(storing)	storing:10-95%

Product Overview

Items	Details
Indoor LED display	P1.5 P2, P2.5, P3, P3.91, P4,P4.81, P5, P6, P10
Outdoor LED display	P2, P2.5, P3, P3, P3.91, P4, P4.81, P5, P6, P8, P10, P12, P16
Specialty displays	Dance floor LED display, DJ LED screen, Transparent LED display
Material	Steel, Iron, Die casting aluminum
Certificates	CE, FCC, RoHS, CCC, UL
Payment terms	30% deposit before production, 70% balance before shipping T/T Western Union
Packing	Standard Export Carton with fully Polyfoam or Pearl Wool Flight case Anti-shaking wooden case
Shipping	5 to 7 working days upon receiving deposit payment
After-Sales-Service	Lifetime with professional engineer support for free. Within 5 year, supply spare parts for free if has quality problem (not by man-made damage)
Using Range	Shopping mall, bank, bus station, train station, center of downtown, airport, school, factory, bus, taxi, and more

Production Process

Incoming Inspection
SMD
Plug-in
Wave Soldering
After Welding
Testing
Semi Finished Aging
Module Assembly
Gluing
Finished Aging
Detection Finishing Warehousing

Our Advantages

Professional Manufacturer of LED display
OEM service, No MOQ
Easy installation, regular items in Stocks
Offering free design drawing as requested
Remote controlling and adjusting are available
Wooden case or flight case packaging options
Your reply will be replied within 24 hours
Fast delivery: Usually 6-8 working days
Excellent R&D team, factory price and assure you quality goods

Packaging and Shipping

Wooden case or flight case package are available. Shipping by sea, air or DHL, multiple shipping ways for your choice.

Why Choose Us

Continuous Quality

With more than 10 years experience in LED display production, our equipment is regularly updated. Our unique standardized and modular production ensures consistent product quality.

Competitive Price

With large scale production capacity and professional production technology, we maintain effective modular production. We continuously promote technical innovation to reduce costs and benefit customers.

Fast Delivery

We commit to promised delivery dates and implement special procedures like emergency inventory to maintain uninterrupted product supply.

Perfect Service

Pre-sales: Your purchasing requirements are highly valued, and we recommend suitable products.
After-sales: We track product usage to continuously improve our products.

Our Workshop
