Outdoor P10 Led Video Wall Display RGB LED Screen with High Refresh Rate

Outdoor P10 Led Video Wall Display RGB LED Screen with High Refresh Rate

    • Outdoor P10 Led Video Wall Display RGB LED Screen with High Refresh Rate
    • Outdoor P10 Led Video Wall Display RGB LED Screen with High Refresh Rate
  • Outdoor P10 Led Video Wall Display RGB LED Screen with High Refresh Rate

    Product Details:

    Place of Origin: China
    Brand Name: SCXK
    Certification: CE/ROHS/FCC/ISO/UL
    Model Number: P10

    Payment & Shipping Terms:

    Minimum Order Quantity: negotiation
    Price: negotiation
    Packaging Details: flight case, wooden case, carton, it is up to you.
    Delivery Time: 7-10 working days after receive your payment
    Payment Terms: T/T, Western Union, MoneyGram
    Supply Ability: 5000sqm per month
    Contact Now
    Detailed Product Description
    Product Name: Outdoor P10 RGB Led Video Wall Display With High Refresh Rate Pitch Size: 10mm
    Brightness: 7000nits IP Rating: IP65/IP54
    Screen Dimension:: Customized Working Tem./Hum.: -20-50℃

    Outdoor P10 RGB Led Video Wall Display with High Refresh Rate



    The features of outdoor energy saving led display:



    1.Uniform color, high contrast, the picture is beautiful and natural.

    2. Low power consumption, low heat, energy saving and environmental protection.

    3. Ultra wide Angle design, expanding the scope of the audience.

    4. Anti UV, anti deformation module suite to protect the screen body deformation.

    5. Dual channel heat sink design, small attenuation, long life.

    6. Patent mask design, dust-proof and waterproof, protection level up to IP65.

    7. Signal, power supply stability, safe and reliable use.



    ♦ Product specification

    outdoor  SMD P10
    Resolution/mm 10
    Pixel configuration 1R1G1B
    Pixel density/pixels/m² 10000/m²
    Module resolution 32*16
    Module size/mm 320*160
    View distance 9-400m
    Single point brightness adjust Can be added
    Single point color adjust Can be added
    White balance brightness >8000cd/㎡
    Color temperature 6500K-9500K
    Horizontal view angle 120(degrees)
    Vertical view angle 60(degrees)
    Signal Process bit 10 or 16bit
    Grey process 1024x1024x1024 16834x16834x16834 65536x65536x65536
    Control distances Internet cable:100m, multimembrane:500m, monofilm:2km
    Driving mode Constant driving current
    Scanning mode (1/4)
    Frame rate 60Hz
    Refresh frequency >3500Hz
    Control mode Computer synchronous
    Brightness adjusted range

    Manual, automatic operation, stepless continuous adjusted

    255 steps. No grey loss

    Out of control point <1/10000
    Working hours ≥72hours
    Mean Time Between Failure >5000hours
    Life time 100000hours
    Life-all-white(brightness halving) 50000hours
    Environment temperature range Operating temperature range: -20-45℃
    Maximum power:/㎡ <900W
    Average power:/㎡ <350W
    Self-check technology

    LED spot self-check, communications check, power check,

    temperature monitor(need customization)

    Remote monitoring

    Remote supervision and control, record potential fault,

    send out warning signs to the operators.(need customization)

    Software environment WindowsNT,Windows1999,WindowsXP
    Luminous point width between centres Deviation<3%
    Brightness uniformity <10%
    Color uniformity(chromaticity coordinate) ±0.003
    Power supply request AC85-264V(50Hz-60Hz)
    Contrast (1000:1)
    System protection Moistureproof,dustproof,high temperature protection,anti-corrosion,anti-burning,anti-static,anti-vibration
    Humidity(working) working:10-95%
    Humidity(storing) storing:10-95%



    Product overviews
    Items Indoor Led display:
    P1.5 P2, P2.5, P3, P3.91, P4,P4.81, P5, P6, P7.62, P10
    Outdoor Led display:
    P4, P4.81, P5, P6, P8, P10, P12, P16,P20,P25,P31.25
    Dance floor led display
    DJ led screen
    Transparent led display
    Material steel,aluminum ,die casting aluminum
    Certificates CE, FCC,RoHS, CCC, UL
    Payment
    terms
    30% deposit before production, 70% balance before shipping
    T/T
    Western Union
    Packing: Standard Export Carton with fully Polyfoam or Pearl Wool
    Flight case;
    Anti-shaking wooden case
    Shipping: 5 to 7 working days upon receiving deposit payment
    After-Sales-Service: Lifetime with professional engineer support for free.
    Within 5 year, supply spare parts for free if has quality problem
    ( not by man-made damage)
    Using Range Shopping mall,bank,bus station, train station,
    center of downtown, airport, school, factory, bus, taxi,and so on.



    ♦ Production process:

    1) Incoming Inspection→2) SMD→3) Plug-in

    →4) Wave Soldering→5) After Welding→6) Testing

    →7) Semi Finished Aging→8) Module Assembly

    →9) Gluing→10) Finished Aging→11) Detection Finishing Warehousing



    ♦ Packaging and shipping

    Wooden case or flight case package are available.

    Shipping by sea,air or DHL,multiple shipping ways for your choice.



    ♦ Description:

    •With sensitive control system, it can adjust screen brightness automatically according to the lighting change of indoor and outdoor, saving energy to reduce your operating costs greatly.
    •High refresh rate and high gray make the picture more realistic, which meets the demand of high visual quality of commercial usage.
    •The advertising contents can be changed at any time, for different customers and various advertisements.
    •you can know the display operation anytime, anywhere.
    • it can turn on and turn off the screen by software timing or manually at any time, achieving unattended function.
