Shenzhen Shichuangxinke Electronics Co.,Ltd
professional makes good quality, provide perfect product and service for every customer.
 |
| Place of Origin: | China |
| Brand Name: | SCXK |
| Certification: | CE/ROHS/FCC/ISO/UL |
| Model Number: | P4 |
| Minimum Order Quantity: | negotiation |
|---|---|
| Price: | negotiation |
| Packaging Details: | flight case, wooden case, carton, it is up to you. |
| Delivery Time: | 7-10 working days after receive your payment |
| Payment Terms: | T/T or western Union |
| Supply Ability: | 5000sqm per month |
| Product Name: | P4 Rental Led Display | Module Size(W * H): | 256mm*128mm |
|---|---|---|---|
| Standard: | CE/ROHS/FCC/ISO2001 | Led Chip: | Epistar |
| Pixel Pitch: | 4mm | Resolution(W*H): | 64dots*32dots |
| High Light: | indoor led display screen,indoor led billboard |
||
indoor rental led video wall p4 videos hd led big screens photos high definition display
SHENZHEN SCXK ELECTRONICS CO., Ltd. is a professional and integrated manufactory of R&D different kinds of LED display products since 2005. We started from LEDs encapsulation, more than 10 years experience in LED industry. As a high-tech enterprise engaged in producing LED advertising screen, traffic sign, mobile screen,rental screen, front service screen, LED curtain/Grid display, Apple style LED advertising sign, LED outdoor full color modules, some creative products such as curved and column display etc.
1) Guidance service: We can guide on line if customers have questions about the installation and usage.
For large project, we provide your engineer a week free training, or if customer could bear the relevant cost,
our engineer can go to customer’s country for on-site guidance.
2) Warranty period: 2 years after shipment.
3) Maintenance principles: response in time, solve problems as soon as possible and ensure the use.
4) Maintenance terms: In the Maintenance period, free of all maintenance charges.
Under normal use and storage, our company will be responsible for the equipments.
Product Specifications
| LED tube chip parameters | ||||||
| Packaging | Color | Brand | Model | Brightness | Wave length | Quantity |
| 146 | R | Epistar | 9mil | 800-900 | 730-800 | 1 |
| G | Epistar | 8x10mil | 1000-1100 | 900-1000 | 1 | |
| B | Epistar | 8x10mil | 230-260 | 230-260 | 1 | |
| LED module parameters | |||
| Pixels pitch: | 4.0mm | Pixel density: | 62500dot/m2 |
| Pixel configuration: | 1R1G1B | Module pixels: | 64x32=2048 dots |
| Module size: | 256x128x20mm | Module weight: | 0.3KG |
| Configuration feature: | Integrated Light/Driver | Frame material: | Polycarbonate(PC) |
| Input voltage: | AC 4.8-5.5V | Max current: | 6.0A±0.1A |
| Module power consumption: | 30W | Driver mode: | 1/16 scan |
| LED cabinet parameters | |
| Standard cabinet size: | 512x512x95 mm |
| Cabinet pixel: | 128x128=16384 dots |
| Cabinet square: | 0.26214m2 |
| Cabinet weight: | 40KG |
| Max power consumption: | 450W |
| Average power consumption: | 250W |
| LED display parameters | |||
| Brightness: | ≥1200cd/m2 | Brightness homogeneity: | ≥0.95 |
| Best horizontal view angle: | 100±8° | Best vertical view angle: | 70±5° |
| Best view distance: | ≥4.0m | Blind spot rate: | ≤0.0003 |
| Max power consumption: | 600W/m2 | Application condition: | intdoor |
| System control parameters | |||
| Gray scale: | each R, G, B - 65536 | Color | 16777216 kinds |
| Repetition rate: | ≥60 frame/second | Refresh rate: | ≥1400Hz |
| Control method: |
PC control, video synchronization |
Brightness adjusting: | 256 auto/manual |
| Input signal: | DVI/VGA, RGBHV, S-VIDEO, HDTV and so on | ||
| System working features | |||
| Lifespan: | ≥100,000 hours | MTBF: | ≥10,000 hours |
| Attenuation rate: | ≤15% 3 years working | Out of control dots: | 0 |
| Discrete control dot: | 0 (before shipment) | Blind spot rate: | 0 (before shipment) |
| Working temperature: | -20 ~50 °C | Working humidity: | 10%~90%RH |
| Protection feature: |
over-heat, over-load, image complement, overcurrent, overvoltage, anti- thunder (optional) |
||
Packaging Detail: Fumigation-free plywood box, airflight case, Carton, etc.
Note: different payment methods can be provided according to different countries.
♦ Why choose us:
Continues Quality
With more than 10 years experience in led display producing,equipments are updated regularly.What’s
more,unique standardized and module production ensure our products continuous quality.
Competitive Price
With large scale production capacity and professional production technology,our company have built
effective modular production.We always stick to promote the technical innovation and reduce cost to
benefit customers.
Fast Delivery
Once we promise the delivery date,we will try our best to fulfill it.Special procedures such as emergency
inventory will be used to maintain your uninterrupted supply of the products.
Perfect Service
Pre-sales:Your purchasing requirements will be highly valued and we’ll recommend suitable products to
you.
After-sales:We will track the products usage and then constantly perfect our products.
♦ FAQ
What kind of payment terms you can accept ?
We can accept T/T and Western Union.
What about your Led Display quality ?
Checking in the whole manufacturing process&100% inspection before shipment ensure the quality of
our products continuity.
What is your delivery time ?
Within 7-35 days according to your area and quantity.
Is your LED display competitive ?
Yes,we are led display manufacturer for more than 10 years.Mass and professional production ensure
our led display’s competitiveness.
