Shenzhen Shichuangxinke Electronics Co.,Ltd
professional makes good quality, provide perfect product and service for every customer.
 |
| Place of Origin: | Made in china |
| Brand Name: | SCXK |
| Certification: | CE,ROHS, FCC.UL.CUL |
| Model Number: | P2 |
| Minimum Order Quantity: | 5 sqm or more |
|---|---|
| Price: | Negotiable |
| Packaging Details: | wooden box, flight case, paper box |
| Delivery Time: | within 7-10 woking days |
| Payment Terms: | D/A, L/C, D/A, D/P, T/T, Western Union, MoneyGram |
| Material: | Iron And Steel Cabinet | Cabinet Size: | 160mm X160mm |
|---|---|---|---|
| Module Size: | 480mm X480mm | Warranty: | 3 Years |
| Led Light: | SMD2121 | Led Chip: | Epistar |
| Color: | Full Color | Scan Way: | 1/32 Scan |
| Dot Density: | 250000dots/sqm | ||
| Highlight: | led stage display,stage background led screen |
||
P2 Full Color Sport Perimeter LED Display IP43 100000 Hours Life Span
The p2 module size is 128 x128mm ,and the fixing usage cabinet is 512mm x512mm
Specification as follows.
| LED Lamps | Type | SMD2121(High Brightness LEDs) | |||||
| LED Standard | Real Pixel(1R1G1B) | ||||||
| Red Wavelength | 625-630nm | ||||||
| Green Wavelength | 515-530nm | ||||||
| Blue Wavelength | 465-475nm | ||||||
| LED Module | Pixel Pitch | 2mm | |||||
| Module Size | 128mm x128mm | ||||||
| Module Resolution | 64*64dots | ||||||
| LED Cabinet | Cabinet Size | 512mmx512mm | |||||
| Cabinet Resolution | 256dotsx256dots | ||||||
| Cabinets Material | iron and steel cabinet | ||||||
| LED Display | Pixel Density | 250000ixels/sq.m | |||||
| Drive IC | MBI5024 | ||||||
| Power Supply | Series connection | ||||||
| Brightness | >2000cd/sqm | ||||||
| Display Color | 16.7million | ||||||
| Viewing Angle | 160°(Horizontal),110°(Vertical) | ||||||
| Best Viewing Distance | 2m~200m | ||||||
| Max Power Consumption | 600 w/sq.m | ||||||
| Average Power Consumption | 300 w/sq.m | ||||||
| Weight | 22kgs/sq.m | ||||||
| Refresh Rate | 2500hz | ||||||
| Input Voltage | AC220V/50H or AC110V/60H | ||||||
| Output Voltage | DC5V,40A | ||||||
| Grey Scale Levels | 16bit | ||||||
| Display Colors | R(1024) x G(1024) x B(1024) | ||||||
| MTBF | 10,000 hours | ||||||
| Life-span | 100,000 hours | ||||||
| Protection Level | IP43 | ||||||
| Failure percentage of leds | less than 0.0003 | ||||||
| Working Temperature | -25℃-60℃ | ||||||
| Drive Mode | 1/32 scaning | ||||||
| Working Humidity | 10%~99% | ||||||
| Control System | Control method | Synchronization & Asynchronization | |||||
| Control System | (software) Led studio | ||||||
| Software | LED studio | ||||||
| Input Signal | MPG/MPEG/MPV/MPA/AVI/VCD/SWF/RM/RA/RM/ASF/BMP/GIF/PCX/TXT/DOC.etc | ||||||
| PC Operating system | Microsoft Windows 7, 98, 2000, XP and Vista | ||||||
Competitive advantage
Q1. What's the warranty of your LED Display Screen ?
A1. We have a 3-years warranty for our led display screen, and 100,000 hours life span of the led lamps.
Q2. What about your pre-sale service and post-sale service?
A2. For pre-sale service. We have a professional sales team and a 8 years technical team who are willing to answer your question 24/7.
We can offer a whole complete solution for your project!
For post-sale service. We can instruct you how to use, adjust the screens, and change the boken modules with spare parts. For asynchronous control We use Onbon, or Xixun control system.
So far ,we have many different project for our oversea market. And the P2 is very high defintion .If you have any question or confusion, just feel free to contact us.We will give you all kinds of assistance and supports.
1.Can you visit our factory in China?
Usually except our staff,other persons are not allowed to visit the factory,as you know it is not good for workers to produce intently.But, of course,our factory is open to our customers,very welcome to visit us,and the person who is responsible will guide you to scan the workshop every step,you will know the rough producing situation,then you will be trustfull to us.Business is long time cooperation.Trust is the most important between each other. I think we can not only do business together,but also can be good friends.The future is belonging to both of you and us.
Fast Delivery
Once we promise the delivery date,we will try our best to fulfill it.Special procedures such as emergency
inventory will be used to maintain your uninterrupted supply of the products.
Perfect Service
Pre-sales:Your purchasing requirements will be highly valued and we’ll recommend suitable products to
you.After-sales:We will track the products usage and then constantly perfect our product
100% factory price,competitive and reasonable price.
2. Strict quality control:
100% testing before packing , make sure our quality before delivery.
3. Quality gurantee:
All our LED display screens is more than 100,000 hours life span.
