High Brightness Full Colorstage Led Screens P3.91 With Die Casting Aluminum

High Brightness Full Colorstage Led Screens P3.91 With Die Casting Aluminum

  • High Brightness Full Colorstage Led Screens P3.91 With Die Casting Aluminum
  • High Brightness Full Colorstage Led Screens P3.91 With Die Casting Aluminum
  • High Brightness Full Colorstage Led Screens P3.91 With Die Casting Aluminum
High Brightness Full Colorstage Led Screens P3.91 With Die Casting Aluminum
Product Details:
Place of Origin: China
Brand Name: SCX
Certification: CE/ROHS/FCC/ISO/UL
Model Number: SMD P3.91
Payment & Shipping Terms:
Minimum Order Quantity: negotiation
Price: negotiation
Packaging Details: flight case, wooden case, carton, it is up to you.
Delivery Time: 7-10 working days after receive your payment
Payment Terms: T/T, Western Union, MoneyGram
Supply Ability: 5000sqm per month
Contact Now
Detailed Product Description
Product Name: Full Color LED Display P3.91 Stage LED Screen With Die-casting Aluminum Cabinet Material: Die Casting Aluminum
Colors: 16.7million Operating Humidity: 10% ~ 95%
IP Rating:: IP43 Screen Dimension:: Customized
High Light:

led stage display

,

stage background led screen

             High Brightness Full Colorstage Led Screens P3.91 With Die Casting Aluminum


Product Features

1, Outdoor high resolution and high brightness, smallest pixel in the world 3.91mm, unequalled image quality in outdoor environment.
2, Ingress protection being IP65, weather proof and dust proof.
3, High brightness uniformity and color uniformity(≥95%)
4, Super thin and light with die-casting aluminum cabinet design.
5, Good anti-UV and anti-oxidation performance.
6, Large viewing distance, 140° in horizontal, 140° in vertical.
7, Excellent flatness and no splicing gap between modules
8, Quick installation and removal with facile connection lock


Product specification

SMD P3.91

Lamp size2121
Resolution/mm3.91
Pixel configurationRGB  3 in 1
Pixel density/pixels/m²64510/m²
Module resolution64x64
Module size/mm250x250
View distance≥2m
Single point brightness adjustCan be added
Single point color adjustCan be added
White balance brightness>8000cd/㎡
Color temperature6500K-9500K
Horizontal view angle120(degrees)
Vertical view angle60(degrees)
Signal Process bit10 or 14 bit
Grey process1024x1024x1024 16834x16834x16834 65536x65536x65536
Control distancesInternet cable:100m, multimembrane:500m, monofilm:5km
Driving modeConstant driving current
Scanning mode1/8
Frame rate60Hz
Refresh frequency>4200Hz
Control modeComputer synchronous
Brightness adjusted range

Manual, automatic operation, stepless continuous adjusted
255 steps. No grey loss

Out of control point<1/10000
Working hours≥72hours
Mean Time Between Failure>5000hours
Life time100000hours
Life-all-white(brightness halving)50000hours
Environment temperature rangeOperating temperature range: -20-45℃ Storing temperature range: -30-65℃
Maximum power:/㎡<1000W
Average power:/㎡<280W
Self-check technology

LED spot self-check, communications check, power check,
temperature monitor(need customization)

Remote monitoring

Remote supervision and control, record potential fault,
send out warning signs to the operators.(need customization)

Software environmentWindowsNT,Windows1999,WindowsXP
Luminous point width between centresDeviation<3%
Brightness uniformity<10%
Color uniformity(chromaticity coordinate)±0.003
Power supply requestAC85-264V(50Hz-60Hz)
Contrast(1000:1)
System protectionMoistureproof,dustproof,high temperature protection,anti-corrosion,anti-burning,anti-static,anti-vibration
Humidity(working)working:10-95%
Humidity(storing)storing:10-95%


Product Overviews

ItemsIndoor Led display:
P2, P2.5, P3, P3.91, P4,P4.81, P5, P6, P7.62, P10
Outdoor Led display:
P4, P4.81, P5, P6, P8, P10, P12, P16,P20,P25,P31.25
Materialsteel,aluminum ,die casting aluminum
Payment
terms
30% deposit before production, 70% balance before shipping
T/T
Western Union
Packing:Standard Export Carton with fully Polyfoam or Pearl Wool
Flight case;
Anti-shaking wooden case
Shipping:5 to 7 working days upon receiving deposit payment
After-Sales-Service:Lifetime with professional engineer support for free.
Within 5 year, supply spare parts for free if has quality problem
( not by man-made damage)
Using RangeShopping mall,bank,bus station, train station,
center of downtown, airport, school, factory, bus, taxi,and so on.


Production process:
1) Incoming Inspection→2) SMD→3) Plug-in
→4) Wave Soldering→5) After Welding→6) Testing
→7) Semi Finished Aging→8) Module Assembly
→9) Gluing→10) Finished Aging→11) Detection Finishing Warehousing

Features
1. Seamless --- precision cabinet, light weight and more durable.
2. Quality LEDs --- with wide viewing angle to ensure vivid and sharp images and video.
3. High refresh rate and high gray scale --- to ensure color consistency and better images
Packaging and shipping
Wooden case or flight case package are available.
Shipping by sea,air or DHL,multiple shipping ways for your choice.
