Shenzhen Shichuangxinke Electronics Co.,Ltd
professional makes good quality, provide perfect product and service for every customer.
 |
| Place of Origin: | China ,Guang Dong |
| Brand Name: | Shichuangxinke |
| Certification: | CE RoHS FCC CCC TUV UL |
| Model Number: | SCXK-P4.81 |
| Minimum Order Quantity: | 1 square meters |
|---|---|
| Price: | USD 400-750 square meters |
| Packaging Details: | wooden box flight case, wooden case, carton, it is up to you. |
| Delivery Time: | 7-10 working days after deposit payment received |
| Payment Terms: | L/C, T/T, Western Union |
| Supply Ability: | 5000sqm per month |
| Pixel Pitch: | 4.81mm | Pixel Configuration: | 1R1G1B |
|---|---|---|---|
| Scanning Mode: | Static Full Color | Module Size: | 250*250mm |
| Cabinet Size: | 500*500mm | Certificates: | CE RoHS FCC CCC UL |
| Material: | Aluminum | Warranty: | 2-3 Years |
| Highlight: | indoor led billboard,indoor led display screen |
||
P4.81 Indoor Full Color LED Display Advertising Convenient HD Model250*250mm
Main features:
Adopt Jingyuan brand LED chips, MBI5024 driver IC and Mean Well power supply, all of which are well-known brand materials
Images and videos are realistic, with rich color details
High brightness ≥1500 cd/m2, which can automatically adjust the brightness according to the ambient brightness, IP65 protection level and working temperature range design to meet your indoor use needs
Signal and power automatic timing function, fully automatic operation
Remote control, error detection, control center management function, error feedback via SMS
Support DOT-DOT correction function
A. Excellent quality, adjustable brightness
B. Wide viewing angle
C. Pure white balance, good consistency
D. Service life exceeds 100,000 hours
E. Easy to learn and operate
F. Our engineers help install and adjust the display screen free of charge
Display screens are widely used in concerts, stages, sports events, fashion shows, exhibitions and other occasions.
Basic data:
There are DIP, SMD and dot matrix LED display screens for customers to choose from.
This module can be changed to the following pixels to meet various needs: P4, P4.75, P6, P7.62, P10, P12, P14, P16, P20, P25, P31.5, P40, P80.
Application of LED display screens:
Widely used in stadiums, advertising, banks, stock exchanges, stations, shopping malls
Post offices, schools, monitoring, restaurants, entertainment, enterprises, etc...
Specifications :
| outdoor DIP P25 | |||||
| Resolution/mm | 4.81 | ||||
| Pixel configuration | 1R1G1B | ||||
| Pixel density/pixels/m² | 43222/m² | ||||
| Module resolution | 64*64 | ||||
| Module size/mm | 500*500MM | ||||
| View distance | 14-300m | ||||
| Single point brightness adjust | Can be added | ||||
| Single point color adjust | Can be added | ||||
| White balance brightness | >7500cd/㎡ | ||||
| Color temperature | 6500K-9500K | ||||
| Horizontal view angle | 120(degrees) | ||||
| Vertical view angle | 60(degrees) | ||||
| Signal Process bit | 10 or 16bit | ||||
| Grey process | 1024x1024x1024 16834x16834x16834 65536x65536x65536 | ||||
| Control distances | Internet cable:100m, multimembrane:500m, monofilm:2km | ||||
| Driving mode | Constant driving current | ||||
| Scanning mode | 1/13SCANNING | ||||
| Frame rate | 60Hz | ||||
| Refresh frequency | >3000Hz | ||||
| Control mode | Computer synchronous | ||||
| Brightness adjusted range | Manual, automatic operation, stepless continuous adjusted | ||||
| 255 steps. No grey loss | |||||
| Out of control point | <1/10000 | ||||
| Working hours | ≥72hours | ||||
| Mean Time Between Failure | >5000hours | ||||
| Life time | 100000hours | ||||
| Life-all-white(brightness halving) | 50000hours | ||||
| Environment temperature range | Operating temperature range: -20-45℃ | ||||
| Self-check technology | LED spot self-check, communications check, power check, | ||||
| temperature monitor(need customization) | |||||
| Remote monitoring | Remote supervision and control, record potential fault, | ||||
| send out warning signs to the operators.(need customization) | |||||
| Software environment | WindowsNT,Windows1999,WindowsXP | ||||
| Luminous point width between centres | Deviation<3% | ||||
| Brightness uniformity | <10% | ||||
| Color uniformity(chromaticity coordinate) | ±0.003 | ||||
| Power supply request | AC85-264V(50Hz-60Hz) | ||||
| Contrast | (1000:1) | ||||
| System protection | Moistureproof,dustproof,high temperature protection,anti-corrosion,anti-burning,anti-static,anti-vibration | ||||
| Humidity(working) | working:10-95% | ||||
| Humidity(storing) | storing:10-95% | ||||
Trade Terms:
1. Payment method: T/T, 35% deposit before production, 65% balance before shipment (Western Union or MoneyGram are welcome)
2. Production lead time for 100~500 pieces: 10 days, 500~1000 pieces: 15 days
3. Samples can be delivered within 3 days
4. Freight is quoted according to your requirements
5. Port of shipment: Shenzhen, Mainland China
6. Discounts are available based on order quantity
7. Minimum order quantity: 1 piece
Our service:
1. Your inquiry related to our products or prices will be replied in 24hrs.
2. Well-trained and experienced staffs to answer all your enquires in fluent English.
3. OEM&ODM, any your customized screen we can help you to design and put into product.
4. Distributoer ship are offered for your unique design and some our current models.
5. Protection of your sales area, ideas of design and all your private information.
FAQ
Q1: How can I select your product?
Firstly you need to tell us your requirement such as the viewing distance, size, installation height, and some other details for the LED screen that you want. And then we will give you a recommendation.
Q2:What if I don't know how to install the screen?
1. We will provide your details drawing for installation led screen, But you need provide us on-site picture for installation
place, and we can guide on line.
2. Training 2 people in the factory.
3. We can send our engineers to your country to guide how to install the screen.
Q3:What is the minimum order quantity?
Qty: 1 unit. Different order quantity different price.
Q4:I would like to ask you if it's possible to have my logo on the product.
Logo printing service is available for mass order based on our M.O.Q
Q5:What if I don't know how to maintain the screen?
We will provide you the operation manual, software when you place the order and also we can remote to help you to adjust the software by teamviwer.
Q6: How to deliver the my goods?
It denpens on your budget and time you need the led screen. Regularly, if the quantity is less, we guggest to deliver by air, otherwise by sea to save the costs.
Q7: How about your warranty?
We provide 3 year warranty for all of our products and supply life-time maintenance.
Q8: What kind of packaging do you provide?
We provide flight case, wooden case and carton.
Q9: How long will it take me to get the product?
We will send the goods as quick as possible, but oftenly it will take 1-2 weeks to get the goods according to the distance ,and some other necessary processes.
Q9: What kind of certification do you get?
We have ISO9001 Quality Control certification. Also CE/ROHS/FCC/CCC etc for different countries’ market.
