Indoor Full Color LED Display
Created with Pixso.

SMD3535 P2.5 Indoor Die-Casting Aluminum Cabinet Full Color LED Display DC5V Advertising Module 160*160mm

SMD3535 P2.5 Indoor Die-Casting Aluminum Cabinet Full Color LED Display DC5V Advertising Module 160*160mm

Brand Name: SCXK-P2.5
Model Number: P2.5
MOQ: Negotiation
Price: 1200-1400 USD /sq
Payment Terms: Western Union, T/T
Supply Ability: 3000 square metres/month
Detail Information
Place of Origin:
China(Mainland)
Certification:
CE ,RoHS, FCC.CCC,SAA ,TUV ,UL
Brand Name:
Indoor Full Color Rental Led Dispaly
Module Size:
160*160mm
Cabinet Size:
480*480mm
Brightness:
≥1500
Pixel Density:
160000dots/sq
Control System:
LSN
Working Voltage:
DC5V
Waterproof:
IP34
Module Resolution:
64*64mm
Cabinet Material:
Die-cast Alnminum
Packaging Details:
Wooden and flight case,it's up to you!
Highlight:

indoor led billboard

,

led full color screen

Product Description



SMD P2.5 Indoor Full Color LED Display for Advertising Module Size 160*160mm



What we do?



We are a professional led manufacturer,specialized in this field for 10 years,item mainly cover

led displays both indoor and outdoor,OEM and a chain service are all available,quality good and perfect service,you deserve it.



Applications:



Stage,Sports,advertising,traffic,events,stadium,shopping center,airport,exhibitions, car shows, fashion

shows, concerts, ceremonies, entertainment,etc.



Product description:

Resolution/mm 2.5
Pixel configuration 1R1G1B
Pixel density/pixels/m² 160000/square meter
Module resolution 64*64
Module size/mm 160*160
View distance 9-500m
Single point brightness adjust Can be added
Single point color adjust Can be added
White balance brightness >1500cd/square meter
Color temperature 6500K-9500K
Horizontal view angle 120(degrees)
Vertical view angle 60(degrees)
Signal Process bit 10 or 16bit
Grey process 1024x1024x1024 16834x16834x16834 65536x65536x65536
Control distances Internet cable:100m, multimembrane:500m, monofilm:2km
Driving mode Constant driving current
Scanning mode 1/32
Frame rate 60Hz
Refresh frequency >3000Hz
Control mode Computer synchronous
Brightness adjusted range Manual, automatic operation, stepless continuous adjusted
255 steps. No grey loss
Out of control point <1/10000
Working hours ≥72hours
Mean Time Between Failure >5000hours
Life time 100000hours
Life-all-white(brightness halving) 50000hours
Environment temperature range Operating temperature range: -20-45℃
Maximum power:/square meter <950W
Average power:/square meter <350W
Self-check technology LED spot self-check, communications check, power check,
temperature monitor(need customization)
Remote monitoring Remote supervision and control, record potential fault,
send out warning signs to the operators.(need customization)
Software environment WindowsNT,Windows1999,WindowsXP
Luminous point width between centres Deviation<3%
Brightness uniformity <10%
Color uniformity(chromaticity coordinate) ±0.003
Power supply request AC85-264V(50Hz-60Hz)
Contrast (1000:1)
System protection Moistureproof,dustproof,high temperature protection,anti-corrosion,anti-burning,anti-static,anti-vibration
Humidity(working) working:10-95%
Humidity(storing) storing:10-95%



Our factory:



SMD3535  P2.5 Indoor Die-Casting Aluminum Cabinet Full Color LED Display DC5V Advertising Module 160*160mm 0

♦ Why choose us?



1) Continues Quality

With more than 10 years experience in led display producing,equipments are updated regularly.What’s

more,unique standardized and module production ensure our products continuous quality.



2) Competitive Price

With large scale production capacity and professional production technology,our company have built

effective modular production.We always stick to promote the technical innovation and reduce cost to

benefit customers.



3) Fast Delivery

Once we promise the delivery date,we will try our best to fulfill it.Special procedures such as emergency

inventory will be used to maintain your uninterrupted supply of the products.



4) Perfect Service

Pre-sales:Your purchasing requirements will be highly valued and we’ll recommend suitable products to

you.

After-sales:We will track the products usage and then constantly perfect our products.





♦ Frequently Asked Questions



What kind of payment terms you can accept ?

We can accept T/T and Western Union.



What about your Led Display quality ?

Checking in the whole manufacturing process&100% inspection before shipment ensure the quality of

our products continuity.



What is your delivery time ?

Within 7-35 days according to your area and quantity.



Is your LED display competitive ?

Yes,we are led display manufacturer for more than 10 years.Mass and professional production ensure

our led display’s competitiveness.





The Module:

SMD3535  P2.5 Indoor Die-Casting Aluminum Cabinet Full Color LED Display DC5V Advertising Module 160*160mm 1SMD3535  P2.5 Indoor Die-Casting Aluminum Cabinet Full Color LED Display DC5V Advertising Module 160*160mm 2SMD3535  P2.5 Indoor Die-Casting Aluminum Cabinet Full Color LED Display DC5V Advertising Module 160*160mm 3SMD3535  P2.5 Indoor Die-Casting Aluminum Cabinet Full Color LED Display DC5V Advertising Module 160*160mm 4









The cabinet:



SMD3535  P2.5 Indoor Die-Casting Aluminum Cabinet Full Color LED Display DC5V Advertising Module 160*160mm 5SMD3535  P2.5 Indoor Die-Casting Aluminum Cabinet Full Color LED Display DC5V Advertising Module 160*160mm 6

The figure of us:



SMD3535  P2.5 Indoor Die-Casting Aluminum Cabinet Full Color LED Display DC5V Advertising Module 160*160mm 7SMD3535  P2.5 Indoor Die-Casting Aluminum Cabinet Full Color LED Display DC5V Advertising Module 160*160mm 8SMD3535  P2.5 Indoor Die-Casting Aluminum Cabinet Full Color LED Display DC5V Advertising Module 160*160mm 9



Shipping details:



SMD3535  P2.5 Indoor Die-Casting Aluminum Cabinet Full Color LED Display DC5V Advertising Module 160*160mm 10





Welcome to visit our company website and inquire more details!!!
