Indoor Fixed Video Wall Panel P3.9 Advertising Led Display Screen For Shopping Mall Retail Store Church

Brand Name:	SCXK
Model Number:	SCXK-P4.81
MOQ:	Negotiations
Price:	Negotiations
Payment Terms:	T/T, Western Union
Supply Ability:	3000sqs/month

Detail Information

Product Description

Detail Information

Place of Origin:

China(Mainland)

Certification:

CE ,RoHS, FCC.CCC,SAA ,TUV ,UL

Brand Name:

Full Color Outdoor LED Display

Certifications:

CE ,RoHS, FCC.CCC,SAA ,TUV ,UL

Module Size:

250*250mm

Cabinet Size:

500*500mm

Resolution:

52*52

Brightness:

≥7500cd/sq

Pixel Density:

43222dots/sq

Warranty:

5years

Application Place:

Dance Floor,stadium,airport,Shopping Mall Advertising

Outdoor Options:

P3.91,P4,P4.81,P5,P6,P6.67,P8,P10,P12,P16,P20,P25,P31.25

Packaging Details:

Wooden and flight case ,it's up to you.

Highlight:

led display smd

smd led display

Product Description

Full Color SMD LED Screen P4.81 Outdoor for Statium Large Size for Good Price

The quick details:

1, 43222 pixels / square meter high resolution;
2, LED chip: Epistar high brightness;
3, Brightness up to 7000cd/square meter;
4, Power supply: 4, Power supply: Meanwell;
5, Control system: Linsn, Nova, etc..

Specifications :

outdoor SMD P4.81
Resolution/mm	4.81
Pixel configuration	1R1G1B
Pixel density/pixels/m²	43222/square meter
Module resolution	52x52
Module size/mm	250x250MM
View distance	14-300m
Single point brightness adjust	Can be added
Single point color adjust	Can be added
White balance brightness	>7500cd/square meter
Color temperature	6500K-9500K
Horizontal view angle	120(degrees)
Vertical view angle	60(degrees)
Signal Process bit	10 or 16bit
Grey process	1024x1024x1024 16834x16834x16834 65536x65536x65536
Control distances	Internet cable:100m, multimembrane:500m, monofilm:2km
Driving mode	Constant driving current
Scanning mode	1/13 SCANNING
Frame rate	60Hz
Refresh frequency	>3000Hz
Control mode	Computer synchronous
Brightness adjusted range	Manual, automatic operation, stepless continuous adjusted
	255 steps. No grey loss
Out of control point	<1/10000
Working hours	≥72hours
Mean Time Between Failure	>5000hours
Life time	100000hours
Life-all-white(brightness halving)	50000hours
Environment temperature range	Operating temperature range: -20-45℃
Self-check technology	LED spot self-check, communications check, power check,
	temperature monitor(need customization)
Remote monitoring	Remote supervision and control, record potential fault,
	send out warning signs to the operators.(need customization)
Software environment	WindowsNT,Windows1999,WindowsXP
Luminous point width between centres	Deviation<3%
Brightness uniformity	<10%
Color uniformity(chromaticity coordinate)	±0.003
Power supply request	AC85-264V(50Hz-60Hz)
Contrast	(1000:1)
System protection	Moistureproof,dustproof,high temperature protection,anti-corrosion,anti-burning,anti-static,anti-vibration
Humidity(working)	working:10-95%
Humidity(storing)	storing:10-95%

Shipping details:Wooden and flight case

Indoor Fixed Video Wall Panel P3.9 Advertising Led Display Screen For Shopping Mall Retail Store Church 0

Our results:

Indoor Fixed Video Wall Panel P3.9 Advertising Led Display Screen For Shopping Mall Retail Store Church 1

Indoor Fixed Video Wall Panel P3.9 Advertising Led Display Screen For Shopping Mall Retail Store Church 2

Our company has been in this field since 2005,has a professional team and technology,every year the products exported overseas and are popular among foriegn countries.

Well...in short,welcome to visit our website and inquire us about more info!!!
