Shenzhen Shichuangxinke Electronics Co.,Ltd
professional makes good quality, provide perfect product and service for every customer.
 |
| Place of Origin: | China (Mainland) |
| Brand Name: | SCXK |
| Certification: | CE ,RoHS, FCC.CCC,SAA ,TUV ,UL |
| Model Number: | SCXK-P6 |
| Minimum Order Quantity: | Negotiations |
|---|---|
| Price: | Negotiations |
| Packaging Details: | Wooden and flight cases,it's up to you. |
| Delivery Time: | 7Working days after payment |
| Payment Terms: | T/T, Western Union |
| Supply Ability: | negotiation |
| Brand Name: | SCXK-RGB LED Display | Pitch: | 6mm |
|---|---|---|---|
| Working Voltage: | DC5V | LED Chip: | Epistar |
| Module Size: | 192*192mm | Cabinet Size: | 576*576mm |
| Application Places: | Dance Floor,stadium,airport,Shopping Mall Advertising | Cabinet Material: | Iron |
| Waterproof: | IP65 | Pixel Density: | 27778dots/sq |
| Brightness: | ≥7500cd/sq | Certifications: | CE ,RoHS, FCC.CCC,SAA ,TUV ,UL |
| Warranty: | 3-5years | Outdoor Options: | P3.91,P4,P4.81,P5,P5.95,P6,P6.67,P8,P10,P12,P16,P20,P25.P31.25... |
| Highlight: | led display rgb,rgb led screen |
||
Waterproof Fixed P6 RGB LED Display Statium Video Movies Epistar Chip SMD
Info about us:
SCXK has been specialized in LED field since 2005. We are a leading manufacturer and provider of technical solution of full color indoor an outdoor ledisplay,rental LED display, led modules where in Shenzhen ctiy,Guangdong province,China.
Applications:
1. Airport Full Color Indoor LED displays
2. Train station Indoor Full Color LED Displays
3. Entertainment Bar Indoor Full Color LED Screen
4. Stadium Indoor Full Color LED Display
5. Museum Full Color Indoor LED display
6. Car exhibition LED display
7. Conference room Indoor Full Color LED Video Display
8. Shopping Mall Indoor Full Color LED display
Specifications :
| outdoor SMD P6 | |||||
| Resolution/mm | 6 | ||||
| Pixel configuration | 1R1G1B | ||||
| Pixel density/pixels/m² | 27778/square meter | ||||
| Module resolution | 32x32mm | ||||
| Module size/mm | 192x192mm | ||||
| View distance | 14-300m | ||||
| Single point brightness adjust | Can be added | ||||
| Single point color adjust | Can be added | ||||
| White balance brightness | >7500cd/square meter | ||||
| Color temperature | 6500K-9500K | ||||
| Horizontal view angle | 120(degrees) | ||||
| Vertical view angle | 60(degrees) | ||||
| Signal Process bit | 10 or 16bit | ||||
| Grey process | 1024x1024x1024 16834x16834x16834 65536x65536x65536 | ||||
| Control distances | Internet cable:100m, multimembrane:500m, monofilm:2km | ||||
| Driving mode | Constant driving current | ||||
| Scanning mode | 1/8 SCANNING | ||||
| Frame rate | 60Hz | ||||
| Refresh frequency | >3000Hz | ||||
| Control mode | Computer synchronous | ||||
| Brightness adjusted range | Manual, automatic operation, stepless continuous adjusted | ||||
| 255 steps. No grey loss | |||||
| Out of control point | <1/10000 | ||||
| Working hours | ≥72hours | ||||
| Mean Time Between Failure | >5000hours | ||||
| Life time | 100000hours | ||||
| Life-all-white(brightness halving) | 50000hours | ||||
| Environment temperature range | Operating temperature range: -20-45℃ | ||||
| Self-check technology | LED spot self-check, communications check, power check, | ||||
| temperature monitor(need customization) | |||||
| Remote monitoring | Remote supervision and control, record potential fault, | ||||
| send out warning signs to the operators.(need customization) | |||||
| Software environment | WindowsNT,Windows1999,WindowsXP | ||||
| Luminous point width between centres | Deviation<3% | ||||
| Brightness uniformity | <10% | ||||
| Color uniformity(chromaticity coordinate) | ±0.003 | ||||
| Power supply request | AC85-264V(50Hz-60Hz) | ||||
| Contrast | (1000:1) | ||||
| System protection | Moistureproof,dustproof,high temperature protection,anti-corrosion,anti-burning,anti-static,anti-vibration | ||||
| Humidity(working) | working:10-95% | ||||
| Humidity(storing) | storing:10-95% | ||||
♦ Why choose us
Continuous quality assurance
We have more than 10 years of experience in the production of LED displays and our equipment is regularly updated.
In addition, the unique standardized and modular production ensures the continuous quality of our products.
Competitive pricing
With large-scale production capacity and professional production technology, our company has established effective modular production.
We consistently promote technological innovation and cost reduction to benefit our customers.
Fast Delivery
Once we commit to a delivery date, we will do our best to fulfill it.
Special procedures such as emergency stock to maintain uninterrupted supply of products.
Perfect service
Pre-sale: we will pay great attention to your purchasing needs and recommend you the right products.
products.
After-sale:
we will track the use of our products and continuously improve our products. And 24 hours to solve your questions and help one-to-one to complete the problems that will arise.
Translated with DeepL.com (free version)
Welcome to visit our website and inquire us more info ,waiting for you all the time!!!
