Shenzhen Shichuangxinke Electronics Co.,Ltd
professional makes good quality, provide perfect product and service for every customer.
 |
| Place of Origin: | China(Mianland) |
| Brand Name: | SCXK |
| Certification: | CE,RoHS,FCC,CCC,SAA,TUV,UL |
| Model Number: | SCXK-P1.667 |
| Minimum Order Quantity: | Negotiations |
|---|---|
| Price: | Negotiations |
| Packaging Details: | Wooden and flight cases,it's up to you. |
| Delivery Time: | 10 working days after payment |
| Payment Terms: | Western Union, T/T |
| Supply Ability: | 5000sqs/month |
| Brand Name: | RGB LED Display | LED Chip: | Epistar |
|---|---|---|---|
| Waterproof: | IP34 | Operation Power: | 220V 60HZ |
| Module Size: | 200*150mm | Control System: | LSN |
| Scan Mode: | 1/30 | LED Type: | SMD2121 |
| Certifications: | CE,RoHS,FCC,CCC,SAA,TUV,UL | Indoor Options: | P1.667,P1.923,P2,P2.5,P3,P3.91,P4,P5,P6,P10... |
| Highlight: | rgb led screen,full color outdoor led display |
||
Indoor P1.667 RGB LED Display 200*150mm Module LSN System Epistar LED Chip
Our service:
1.Before sales:
According to your demands, we will provide a set of LED display project solutions for you to choose,and discuss the best solution,then start the technology making.
2.In sales:
We will provide installation steps and instructions based on the detailed installation environment, including temperature, humidity, installation location, etc.
Detailed installation environment, including temperature, humidity, mounting location, etc.
If it's a large event, we can be on site with you to make sure everything goes smoothly.
Wherever you are in the world, we are on call 24/7 to assist you with any issues that arise until they are satisfactorily resolved Romote Control can help you set up communications and debug your control software.
3.After sales:
2 years of free maintenance since the delivery of LED display; we will provide free technology support through phone and email in time.Also,we can send our technicians to your side and help solving the problems if you pay the expense through the trip.
Short Description:
| Specifictions | |||||||||
| LED Lamps | Type | 3mm smd2121 | |||||||
| LED Standard | Real Pixel(1R1G1B) | ||||||||
| Red Wavelength | 625-630nm | ||||||||
| Green Wavelength | 520-530nm | ||||||||
| Blue Wavelength | 465-475nm | ||||||||
| LED Module | Pixel Pitch | 1.667mm | |||||||
| Module Size | 200mmx150mm | ||||||||
| Module Resolution | 120*90dots | ||||||||
| LED Cabinet | Cabinet Size | 400mmX300mm | |||||||
| Cabinet Resolution | 240pixels * 180pixels | ||||||||
| Cabinets Material | Die-cast Aluminum Cabinet | ||||||||
| LED Display | Pixel Density | 360000pixels/sq.m | |||||||
| Drive IC | ET6024 | ||||||||
| Power Supply | Series connection | ||||||||
| Brightness | ≥1200cd/sqm | ||||||||
| Display Color | 16.7million | ||||||||
| Viewing Angle | 120°(Horizontal),60°(Vertical) | ||||||||
| Best Viewing Distance | 2m~150m | ||||||||
| Max Power Consumption | 800 w/sq.m | ||||||||
| Average Power Consumption | 300 w/sq.m | ||||||||
| Weight | 28Kgs/sq.m | ||||||||
| Refresh Rate | 480hz | ||||||||
| Input Voltage | AC220V/50H or AC110V/60H | ||||||||
| Output Voltage | DC5V,40A | ||||||||
| Grey Scale Levels | 10bits/1024levels | ||||||||
| Display Colors | R(1024) x G(1024) x B(1024) | ||||||||
| MTBF | 5,000 hours | ||||||||
| Life-span | 100,000 hours | ||||||||
| Protection Level | IP34 | ||||||||
| Failure percentage of leds | less than 0.0003 | ||||||||
| Working Temperature | -20℃~60℃ | ||||||||
| Drive Mode | 1/30 scan | ||||||||
| Working Humidity | 10%~99% | ||||||||
| Control System | Control method | Synchronization & Asynchronization | |||||||
| Control System |
LINSN Control System (sender,receiver,HUB with 75 interface,software) |
||||||||
| Software | LED Studio (LINSN) | ||||||||
| Input Signal |
MPG/MPEG/MPV/MPA/AVI/VCD/SWF/RM/RA/RM/AS F/BMP/GIF/PCX/TXT/DOC.etc |
||||||||
| PC Operating system | Microsoft Windows 7, 98, 2000, XP and Vista | ||||||||
Feature:
1. Light weight. Easy to transport and install, save labor cost, suitable for mobile performance.
2. Beautiful shape and simple structure.
3. Correctly connected, one person can install and dismantle it without tools.
4. Humanized operation interface with fault indicator, easy for maintenance.
5. debugging high brightness, gray scale without damage, realize the image beautiful debugging technology.
6. Simple operation, easy installation, one-on-one guidance to complete.
Application Places:
Commercial advertising, night club, entertainment events, business establishments, stock exchange centers, schools, telecommunications, stadiums, shopping malls, railways, airports, stages, activities etc.
If you have interest,please contact us!!!
Contact Person: Lillian seori
Tel: +8619386814677
