P2 Die-Cast Aluminum SMD Indoor Full Color LED Display High Resolution 256*128mm Module

P2 Die-Cast Aluminum SMD Indoor Full Color LED Display High Resolution 256*128mm Module

Brand Name: SCXK
Model Number: SCXK-P2
MOQ: 1 sqm or more
Price: Negotiations
Payment Terms: Western Union, T/T
Supply Ability: 5000sqs/month
Detail Information
Place of Origin:
China(Mianland)
Certification:
CE,RoHS,FCC,CCC,SAA,TUV,UL
Brand Name:
RGB LED Display
Brightness:
≥1200cd/sq
Certifications:
CE,RoHS,FCC,CCC,SAA,TUV,UL
LED Chip:
Epistar
Waterproof:
IP34
Operation Power:
220V 60HZ
Module Size:
256*128mm
Cabinet Size:
512*512mm
Control System:
LSN
Pixel Density:
250000dots/sq
Resolution:
128*64
Scan Mode:
1/32
LED Type:
SMD2121
Indoor Options:
P1.667,P1.923,P2,P2.5,P3,P3.91,P4,P5,P6,P10...
Packaging Details:
Wooden and flight cases,it's up to you.
Highlight:

indoor led billboard

,

led full color screen

Product Description


Indoor Full Color LED Display P2 SMD High Resolution 256*128mm Module 1/32 Scan Ip34


Specifications :

Indoor P2 LED Display
Resolution/mm 2
Pixel configuration 1R1G1B
Pixel density/pixels/m² 250000/square meter
Module resolution 128x64
Module size/mm 256x128
View distance 14-300m
Single point brightness adjust Can be added
Single point color adjust Can be added
White balance brightness >1200cd/square meter
Color temperature 6500K-9500K
Horizontal view angle 120(degrees)
Vertical view angle 60(degrees)
Signal Process bit 10 or 16bit
Grey process 1024x1024x1024 16834x16834x16834 65536x65536x65536
Control distances Internet cable:100m, multimembrane:500m, monofilm:2km
Driving mode Constant driving current
Scanning mode 1/32 SCANNING
Frame rate 60Hz
Refresh frequency >3000Hz
Control mode Computer synchronous
Brightness adjusted range Manual, automatic operation, stepless continuous adjusted
255 steps. No grey loss
Out of control point <1/10000
Working hours ≥72hours
Mean Time Between Failure >5000hours
Life time 100000hours
Life-all-white(brightness halving) 50000hours
Environment temperature range Operating temperature range: -20-45℃
Self-check technology LED spot self-check, communications check, power check,
temperature monitor(need customization)
Remote monitoring Remote supervision and control, record potential fault,
send out warning signs to the operators.(need customization)
Software environment WindowsNT,Windows1999,WindowsXP
Luminous point width between centres Deviation<3%
Brightness uniformity <10%
Color uniformity(chromaticity coordinate) ±0.003
Power supply request AC85-264V(50Hz-60Hz)
Contrast (1000:1)
System protection Moistureproof,dustproof,high temperature protection,anti-corrosion,anti-burning,anti-static,anti-vibration
Humidity(working) working:10-95%
Humidity(storing) storing:10-95%

P2 Die-Cast Aluminum SMD Indoor Full Color LED Display High Resolution 256*128mm Module 0P2 Die-Cast Aluminum SMD Indoor Full Color LED Display High Resolution 256*128mm Module 1P2 Die-Cast Aluminum SMD Indoor Full Color LED Display High Resolution 256*128mm Module 2

P2 Die-Cast Aluminum SMD Indoor Full Color LED Display High Resolution 256*128mm Module 3P2 Die-Cast Aluminum SMD Indoor Full Color LED Display High Resolution 256*128mm Module 4

P2 Die-Cast Aluminum SMD Indoor Full Color LED Display High Resolution 256*128mm Module 5

Our Services



Pre-sale service



1) Displaying video motion pictures in high definition
With 4,096 steps of brightness control for each RED, GREEN and BLUE color,

our system is designed to provide pictures quality similar to that of analog formula, without losing image data.
2) Displaying multi(natural) colors
With 4,096 color grades of each RED, GREEN and BLUE color, our system is designed to

display multi-colors amounting 68.7 billion on the screen.
3) Windows based operating software
Our system is designed to be operated with MS Windows.
4) Providing delicate brightness adjustment
Our system is designed to provide delicate brightness adjustment(by each 0.025% steps)
5) Providing automatic brightness adjustment
Our system is designed to provide automatic brightness adjustment according to

the change of ambiance brightness.
6) Screen size adjustment
Our system is designed to adjust screen size not only to the standard ratio of 4 : 3 or 16 : 9

but also specific size as you want to use



After service

Service 1: if the signs have any problems in 2 years, just take the photos show us, we will send the new items

to you free in 10 days. and we pay the freight.
Service 2 :if you are satisfied with our products and place your second/third/.....order from us , more discounts
are waiting for you.

P2 Die-Cast Aluminum SMD Indoor Full Color LED Display High Resolution 256*128mm Module 6

FAQ



1) Q: Are you a factory or trading company?

A:We are a company with our own factory,can accept OEM/ODM .

2) Q:What payment methods your company accept?

A:We accept most of the payment methods,but mainly accept T/T,Western Union.

3) Q:How long is the warranty time for your products?

A:Our officially promised warranty time is two whole years after delivery at best.

4) Q:I haven't done business with you guys before,how can i trust your company?

A:Our company has been in Alibaba.com for almost 7 years,which is longer than most of our fellow suppliers,we've been golden suppliers for years.what'smore,we've got quite a lot authority certificates,for example,CE,UL,RoHS,FCC ISO9001, BV, Alibaba onsite check certificate. I hope those above will be persuasive enough.
