Shenzhen Shichuangxinke Electronics Co.,Ltd
professional makes good quality, provide perfect product and service for every customer.
 |
| Place of Origin: | China(Mainland) |
| Brand Name: | SCXK |
| Certification: | CE,RoHS,FCC,CCC,SAA,TUV,UL |
| Model Number: | SCXK-P3 |
| Minimum Order Quantity: | Negotiations |
|---|---|
| Price: | Negotiations |
| Packaging Details: | Wooden and flight cases,it's up to you. |
| Delivery Time: | 7-10 working days after payment |
| Payment Terms: | T/T, Western Union |
| Supply Ability: | 5000sqs/month |
| Pitch: | 3mm | Color: | Full Color,RGB 3In1 |
|---|---|---|---|
| LED Chip: | Epistar | System: | LSN |
| Module Size: | 192*192mm | Waterproof: | IP34 |
| Working Voltage: | DC5V | Certification: | CE,RoHS,FCC,ISO |
| Warranty: | 3-5 Years | Application: | Dance Floor,stadium,airport,Shopping Mall Advertising |
| Highlight: | indoor led billboard,led full color screen |
||
P3 Indoor Full Color LED Display for Concert 160000dots/sq Brightness IP34
Company Information
Shenzhen Shichuang Xinke Electronics Co., Ltd. was established in 2005.
We are a factory located in Shenzhen, Guangdong Province, China.
We have been engaged in the development and production of LCD digital signage for more than 10 years, and during these years, we have developed our own LCD product line, such as all-in-one infrared touch screen display, resistive touch screen display, indoor LED digital signage and card-type LCD advertising player, etc., with sizes ranging from 15 inches to 98 inches, etc.
Specifications :
| Indoor P3 LED Display | |||||
| Resolution/mm | 3 | ||||
| Pixel configuration | 1R1G1B | ||||
| Pixel density/pixels/m² | 111111/square meter | ||||
| Module resolution | 64x64 | ||||
| Module size/mm | 192x192mm | ||||
| View distance | 14-300m | ||||
| Single point brightness adjust | Can be added | ||||
| Single point color adjust | Can be added | ||||
| White balance brightness | >1200cd/square meter | ||||
| Color temperature | 6500K-9500K | ||||
| Horizontal view angle | 120(degrees) | ||||
| Vertical view angle | 60(degrees) | ||||
| Signal Process bit | 10 or 16bit | ||||
| Grey process | 1024x1024x1024 16834x16834x16834 65536x65536x65536 | ||||
| Control distances | Internet cable:100m, multimembrane:500m, monofilm:2km | ||||
| Driving mode | Constant driving current | ||||
| Scanning mode | 1/16 SCANNING | ||||
| Frame rate | 60Hz | ||||
| Refresh frequency | >3000Hz | ||||
| Control mode | Computer synchronous | ||||
| Brightness adjusted range | Manual, automatic operation, stepless continuous adjusted | ||||
| 255 steps. No grey loss | |||||
| Out of control point | <1/10000 | ||||
| Working hours | ≥72hours | ||||
| Mean Time Between Failure | >5000hours | ||||
| Life time | 100000hours | ||||
| Life-all-white(brightness halving) | 50000hours | ||||
| Environment temperature range | Operating temperature range: -20-45℃ | ||||
| Self-check technology | LED spot self-check, communications check, power check, | ||||
| temperature monitor(need customization) | |||||
| Remote monitoring | Remote supervision and control, record potential fault, | ||||
| send out warning signs to the operators.(need customization) | |||||
| Software environment | WindowsNT,Windows1999,WindowsXP | ||||
| Luminous point width between centres | Deviation<3% | ||||
| Brightness uniformity | <10% | ||||
| Color uniformity(chromaticity coordinate) | ±0.003 | ||||
| Power supply request | AC85-264V(50Hz-60Hz) | ||||
| Contrast | (1000:1) | ||||
| System protection | Moistureproof,dustproof,high temperature protection,anti-corrosion,anti-burning,anti-static,anti-vibration | ||||
| Humidity(working) | working:10-95% | ||||
| Humidity(storing) | storing:10-95% | ||||
Packaging & Shipping
Packaging
EPE protected, anti-pressure, anti-shock to ensure goods safety;
Compress volume reasonably, weight reduced, to save freight for customers;
High-quality thick wooden box used, anti-pressure, anti shock, moisture-proof, to effectively prevent damage during delivery.
Shipping
1. By Air ,by Sea ,by international express;
2. Customers specifying freight forwarders or negotiable shipping methods!
3. Delivery Time: 3-7 days for samples; 5-25 days for batch goods.
Our services
Before sales:
Our tachnicians will test the product before sending it to you,so that ensure it can well work and have no technical problems.
In sales:
We will offer installaiton steps and guidance based on the
detailed installation environment including temp. humidity, installation venue, etc.
If it is a big event,we can send our technicians to stay there with you to ensure everything goes well.
Romote control will help us build communications and debug the control software for you no matter where you are.
After sales:
2 years of free maintenance since the delivery of LED display; we will provide free technology support through phone and email in time.
FAQ
Q1.Can I have a sample order for the LED display?
A:Yes,we welcome sample orders to test and check quality.Both for the module or the whole screen.
Q2.What about the lead time?
A:Order less than 100 square meters lead time to take 15 working days
Q3.Do you have any MOQ limit for LED display orders?
A:Low MOQ,1 square meter or a module checking is available
Q4.How do you ship the goods and how long does it take to arrive?
A:We mostly accept EXW FOB CIF DDP and other shipping ways.It usually takes 20~30 days on the sea.a few days for customs clearance
Q5.How to proceed with an order for an LED display?
A:Firstly let us know your requirements or application.
Secondly,We quote according to your requirements or our suggestions.
Thirdly customer confirms the design document and places a deposit for the formal order.
Fourthly We arrange the production.
Q6.Is it OK to print my logo on the products?
A:Yes.Please inform us formally before our production and confirm the design firstly based on our sample.
Q7:Do you offer a guarantee for the products?
A:Yes,we offer 1-5 years warranty for our products
