Shenzhen Shichuangxinke Electronics Co.,Ltd
professional makes good quality, provide perfect product and service for every customer.
 |
| Place of Origin: | China(Mainland) |
| Brand Name: | SCXK |
| Certification: | CE,FCC,ISO.UL |
| Model Number: | SCXK-P6 |
| Minimum Order Quantity: | negotiation |
|---|---|
| Price: | negotiation |
| Packaging Details: | Wooden and flight cases,it's all up to you. |
| Delivery Time: | 12-15 working days after receiving your down payment. |
| Payment Terms: | T/T, Western Union, L/C, D/A, D/P, MoneyGram |
| Supply Ability: | 5000sqms/month |
| Pixel Pitch: | 6MM | Color: | Full Color |
|---|---|---|---|
| Brightness: | 7500cd/sqm | Module Size: | 192*192MM |
| Control System: | Nova,Linsn | Aging Time: | ≥72 Hours |
| Pixel Density: | 27778dots/sqm | Working Voltage: | DC5V |
| Resolution: | 32*32 | Life Time: | 100000 Hours |
| Highlight: | led digital billboards,led advertising billboards |
||
Outside installation RGB LED Billboards SMD3528 Module Size 192*192MM IP68
1) Guidance service: If customers have any questions about installation and use, our company can provide online guidance. For large projects, our company can train engineers for one week free of charge. If the customer can bear the relevant expenses, our company can send engineers to the customer's country/region for on-site guidance.
2) Warranty period: two years after delivery.
3) Maintenance principle: timely response, solve problems as soon as possible, and ensure use.
4) Maintenance terms: During the maintenance period, all maintenance costs are waived. The equipment is under normal use and storage conditions, and is the responsibility of our company. If the product has quality failures, our company will repair and replace parts free of charge. After the maintenance period, only material costs will be charged, and no labor costs will be charged.
Sertifications:
| Large Screen RGB LED Display P8 | |||||
| Resolution/mm | 8 | ||||
| Pixel configuration | 1R1G1B | ||||
| Pixel density/pixels/m² | 15625/square meter | ||||
| Module resolution | 40*20mm | ||||
| Module size/mm | 256*128mm | ||||
| View distance | 14-300m | ||||
| Single point brightness adjust | Can be added | ||||
| Single point color adjust | Can be added | ||||
| White balance brightness | >7500cd/square meter | ||||
| Color temperature | 6500K-9500K | ||||
| Horizontal view angle | 120(degrees) | ||||
| Vertical view angle | 60(degrees) | ||||
| Signal Process bit | 10 or 16bit | ||||
| Grey process | 1024x1024x1024 16834x16834x16834 65536x65536x65536 | ||||
| Control distances | Internet cable:100m, multimembrane:500m, monofilm:2km | ||||
| Driving mode | Constant driving current | ||||
| Scanning mode | static full color SCANNING | ||||
| Fresh rate | 60Hz | ||||
| Refresh frequency | >3000Hz | ||||
| Control mode | Computer synchronous | ||||
| Brightness adjusted range | Manual, automatic operation, stepless continuous adjusted | ||||
| 255 steps. No grey loss | |||||
| Out of control point | <1/10000 | ||||
| Working hours | ≥72hours | ||||
| Mean Time Between Failure | >5000hours | ||||
| Life time | 100000hours | ||||
| Life-all-white(brightness halving) | 50000hours | ||||
| Environment temperature range | Operating temperature range: -20-45℃ | ||||
| Self-check technology | LED spot self-check, communications check, power check, | ||||
| temperature monitor(need customization) | |||||
| Remote monitoring | Remote supervision and control, record potential fault, | ||||
| send out warning signs to the operators.(need customization) | |||||
| Software environment | WindowsNT,Windows1999,WindowsXP | ||||
| Luminous point width between centres | Deviation<3% | ||||
| Brightness uniformity | <10% | ||||
| Waterproof | Ip68 | ||||
| Color uniformity(chromaticity coordinate) | ±0.003 | ||||
| Power supply request | AC85-264V(50Hz-60Hz) | ||||
| Contrast | (1000:1) | ||||
| System protection | Moistureproof,dustproof,high temperature protection,anti-corrosion,anti-burning,anti-static,anti-vibration | ||||
| Humidity(working) | working:10-95% | ||||
| Humidity(storing) | storing:10-95% | ||||
Outdoor LED Display series :
1. Automatic brightness control, super processing power, high color reproduction.
2. Support multiple interfaces and signal sources.
3. Advanced digital control technology, excellent effect.
4. Even in direct sunlight, high brightness ensures that you attract more audiences, thus quickly recovering the investment of full-color outdoor LED display.
5. Anti-corrosion and durable, can be used outdoors in various weather conditions.
The LED module has a simple and easy-to-use installation interface and user-friendly software, ensuring that the LED display system has a user-friendly interface.
HJY outdoor LED display adopts all-aluminum alloy structure, light weight and waterproof. It is a perfect outdoor multimedia LED display system designed for changeable and harsh outdoor environment.
