Shenzhen Shichuangxinke Electronics Co.,Ltd
professional makes good quality, provide perfect product and service for every customer.
 |
| Place of Origin: | China(Mainland) |
| Brand Name: | SCXK |
| Certification: | CE,ISO,FCC,UL |
| Model Number: | SCXK-P5 |
| Minimum Order Quantity: | 5sqms |
|---|---|
| Price: | 470-600USD/sqm |
| Packaging Details: | Wooden and flight cases,it's all up to you. |
| Delivery Time: | 12-15 working days after receiving your down payment. |
| Payment Terms: | T/T, Western Union |
| Supply Ability: | 5000sqms/month |
| Color: | RGB Full Color | Cabinet Type: | Iron/Die-cast Aluminum |
|---|---|---|---|
| Pixel Pitch: | 6MM | Resolution: | 64*32 |
| Scan Mode: | 1/16 | Application Place: | Indoor |
| Waterproof: | IP43 | Brightness: | 1500cd/sqm |
| Pixel Density: | 40000dots/sqm | Control System: | Nova,Linsn |
| Highlight: | led video screen rental,led rental screen |
||
High Quality Full Color Rental LED Display Light Weight P5 Indoor Big Screen
Our service:
1. We will provide you with a certain number of spare parts (details as above) along with the goods, including LED, power supply, module, cable, etc., which are enough for replacement within 2 years. 2. We will provide a two-year warranty for our products. This means two years of factory labor and parts are provided free of charge, but the customer should pay the round-trip freight for damaged parts. 3. For technical support, we will send installation drawings, user manuals after order confirmation, and we can provide free training for your technicians in our factory until he can manage well. 4. For installation, if you need, we can send an engineer to your country to help and guide the installation, but you need to pay for the round-trip air tickets and accommodation. 5. For future service, if you encounter any problems, our overseas engineers will provide you with service online or by phone within 7x24 hours.
Specifications:
| Resolution/mm | 5 |
| Pixel configuration | 1R1G1B |
| Pixel density/pixels/m² | 40000/square meter |
| Module resolution | 64x32 |
| Module size/mm | 320x160 |
| View distance | 5-150m |
| White balance brightness | 1500cd/square meter |
| Color temperature | 6500K-9500K |
| Horizontal view angle | 120(degrees) |
| Vertical view angle | 120(degrees) |
| Signal Process bit | 10 or 16bit |
| Control distances | Internet cable:100m, multimembrane:500m, monofilm:2km |
| Driving mode | Constant driving current |
| Scanning mode | (1/16) |
| Frame rate | 60Hz |
| Refresh frequency | >3000Hz |
| Control mode | Computer synchronous |
| Brightness adjusted range | Manual, automatic operation, stepless continuous adjusted |
| 255 steps. No grey loss | |
| Out of control point | <1/10000 |
| Aging hours | ≥72hours |
| Mean Time Between Failure | >5000hours |
| Life time | 100000hours |
| Life-all-white(brightness halving) | 50000hours |
| Environment temperature range | Operating temperature range: -20-45℃ |
| Maximum power:/square meter | <950W |
| Average power:/square meter | <350W |
| Self-check technology | LED spot self-check, communications check, power check, |
| temperature monitor(need customization) | |
| Remote monitoring | Remote supervision and control, record potential fault, |
| send out warning signs to the operators.(need customization) | |
| Software environment | WindowsNT,Windows1999,WindowsXP |
| Luminous point width between centres | Deviation<3% |
| Brightness uniformity | <10% |
| Waterproof | IP43 |
| Color uniformity(chromaticity coordinate) | ±0.003 |
| Power supply request | AC85-264V(50Hz-60Hz) |
| Contrast | (1000:1) |
| System protection | Moistureproof,dustproof,high temperature protection,anti-corrosion,anti-burning,anti-static,anti-vibration |
| Humidity(working) | working:10-95% |
| Humidity(storing) | storing:10-95% |
Application Places:
Widely used in Advertising media,Concert, TV SHOW,Super mall, Entertainment,School,Government,Trading conversation,Commodity fair,Exhibition,Cinema,News conferences, Meeting room,Airport,Hotel,Station Hall and other Public Places.
___________________________________FAQ_______________________________________
Q1: What is the payment method?
A5:The mininum order is 5 sqms,and we also provide a series of after-sales service.
Our company is always ready for cooperating with you!!!
Contact Person: Lillian seori
Tel: +8619386814677
