Shenzhen Shichuangxinke Electronics Co.,Ltd
professional makes good quality, provide perfect product and service for every customer.
 |
| Place of Origin: | China(Mainland) |
| Brand Name: | SCXK |
| Certification: | CE,ISO,FCC,UL |
| Model Number: | SCXK-P2 |
| Minimum Order Quantity: | 3 sqms |
|---|---|
| Price: | 1200-1300USD/sqm |
| Packaging Details: | Wooden and flight case,it's all up to you. |
| Delivery Time: | 12-15 working days after receiving your down payment. |
| Payment Terms: | T/T, Western Union, MoneyGram |
| Supply Ability: | 5000sqms/month |
| Brand Name: | SCXK | Pixel Pitch: | 2MM |
|---|---|---|---|
| Usage: | Rental/Fixed | Module Size: | 128*128MM |
| Cabinet Size: | 512*512MM | Resolution: | 64*64 |
| Scan Mode: | 1/32 | Working Voltage: | DC5V |
| Certificate: | CE,ISO,FCC,UL | ||
| Highlight: | led display smd,smd led display |
||
Indoor SMD LED Screen P2 Small Pixel Pitch for High Resolution Ip43
Some details about the rental led display:
At present, LED rental screen is widely used in stage performances, concerts, theaters, parties and other entertainment activities as a background, can be played back and playback on site, its large size so that the audience away from the stage can also clearly see the performance on the stage, to create a gorgeous, highly infectious atmosphere, combined with high-quality sound effects, to bring a perfect visual feast.
Specifications:
| Indoor SMD LED Screen P2 | |||||
| Resolution/mm | 2 | ||||
| Pixel configuration | 1R1G1B | ||||
| Pixel density/pixels/m² | 250000/square meter | ||||
| Module resolution | 64x64mm | ||||
| Module size/mm | 128x128mm | ||||
| View distance | 2-150m | ||||
| Single point brightness adjust | Can be added | ||||
| Single point color adjust | Can be added | ||||
| White balance brightness | >1500cd/square meter | ||||
| Color temperature | 6500K-9500K | ||||
| Horizontal view angle | 120(degrees) | ||||
| Vertical view angle | 120(degrees) | ||||
| Signal Process bit | 10 or 16bit | ||||
| Grey process | 1024x1024x1024 16834x16834x16834 65536x65536x65536 | ||||
| Control distances | Internet cable:100m, multimembrane:500m, monofilm:2km | ||||
| Driving mode | Constant driving current | ||||
| Scanning mode | 1/32 SCANNING | ||||
| Frame rate | 60Hz | ||||
| Refresh frequency | >3000Hz | ||||
| Control mode | Computer synchronous | ||||
| Brightness adjusted range | Manual, automatic operation, stepless continuous adjusted | ||||
| 255 steps. No grey loss | |||||
| Out of control point | <1/10000 | ||||
| Working hours | ≥72hours | ||||
| Mean Time Between Failure | >5000hours | ||||
| Life time | 100000hours | ||||
| Life-all-white(brightness halving) | 50000hours | ||||
| Environment temperature range | Operating temperature range: -20-45℃ | ||||
| Self-check technology | LED spot self-check, communications check, power check, | ||||
| temperature monitor(need customization) | |||||
| Remote monitoring | Remote supervision and control, record potential fault, | ||||
| send out warning signs to the operators.(need customization) | |||||
| Software environment | WindowsNT,Windows1999,WindowsXP | ||||
| Luminous point width between centres | Deviation<3% | ||||
| Brightness uniformity | <10% | ||||
| Waterproof | IP43 | ||||
| Color uniformity(chromaticity coordinate) | ±0.003 | ||||
| Power supply request | AC85-264V(50Hz-60Hz) | ||||
| Contrast | (1000:1) | ||||
| System protection | Moistureproof,dustproof,high temperature protection,anti-corrosion,anti-burning,anti-static,anti-vibration | ||||
| Humidity(working) | working:10-95% | ||||
| Humidity(storing) | storing:10-95% | ||||
What we do?
Established in 2005, Shenzhen Shixinke Electronics Co., Ltd. is a manufacturer of indoor and outdoor full color LED displays.
With high quality products, excellent sales service and perfect after-sales service, SCXK enjoys a great reputation in the world, with products spreading over six continents.LAMP's LED video displays are all over the world, with a large number of representative cases in Hong Kong, Marco, South Asia, Africa and America.
You are welcome to visit our website to select the products you need, and we will promise you good value for money!
Technical service:
(1)System and product training in the pre construction, in order to have a thorough understanding of products;
(2)Provide installation training, be able to achieve the system installation and maintenance;
(3)After the project will be application training, make users grasp the use of the systematic hardware skillfully
(4)Users change , free training for new staff
(5)We are responsible for the training of your staff's use;
The shipping and package:
We use the wooden and flight cases to pack the goods,normally the iron cabinet for wooden case,and the die-cast aluminum cabinet for flight case;then the way of shipping we have air and sea,also,if you want to take other ways,we will try our best to satisfy your requirements.
Welcome to inquiry us for more info!!!
