| Brand Name: | SCXK |
| Model Number: | SCXK-P10 |
| MOQ: | 5 sqms |
| Price: | negotiation |
| Payment Terms: | T/T, Western Union, D/A, D/P, MoneyGram |
| Supply Ability: | 3000sqms/month |
HD Outdoor Full Color LED Display P10 DIP for Fixed Installation IP 65
Product description:
1) Reliable quality, advanced and mature technology, in line with industry standards and technological development trends.
2) Good heat dissipation, good waterproof performance, and stable performance.
3) The system has audio and video interfaces, which can provide vivid, complete, and high-quality LED display screens for TV broadcast signals.
4) The screen image has high resolution, high definition, clear pictures, and no flicker.
5) Supports video and RF input, and the special structure can be freely assembled.
![]()
![]()
![]()
![]()
![]()
![]()
![]()
Specification :
| outdoor P10 DIP LED screen Display | |||||
| Resolution/mm | 10 | ||||
| Pixel configuration | 1R1G1B | ||||
| Pixel density/pixels/m² | 10000/square meter | ||||
| Module resolution | 16*16mm | ||||
| Module size/mm | 320*160mm | ||||
| View distance | 10-150m | ||||
| Single point brightness adjust | Can be added | ||||
| Single point color adjust | Can be added | ||||
| White balance brightness | >7500cd/square meter | ||||
| Color temperature | 6500K-9500K | ||||
| Horizontal view angle | 120(degrees) | ||||
| Vertical view angle | 120(degrees) | ||||
| Signal Process bit | 10 or 16bit | ||||
| Grey process | 1024x1024x1024 16834x16834x16834 65536x65536x65536 | ||||
| Control distances | Internet cable:100m, multimembrane:500m, monofilm:2km | ||||
| Driving mode | Constant driving current | ||||
| Scanning mode | static full color SCANNING | ||||
| Fresh rate | 60Hz | ||||
| Refresh frequency | >3000Hz | ||||
| Control mode | Computer synchronous | ||||
| Brightness adjusted range | Manual, automatic operation, stepless continuous adjusted | ||||
| 255 steps. No grey loss | |||||
| Out of control point | <1/10000 | ||||
| Working hours | ≥72hours | ||||
| Mean Time Between Failure | >5000hours | ||||
| Life time | 100000hours | ||||
| Life-all-white(brightness halving) | 50000hours | ||||
| Environment temperature range | Operating temperature range: -20-45℃ | ||||
| Self-check technology | LED spot self-check, communications check, power check, | ||||
| temperature monitor(need customization) | |||||
| Remote monitoring | Remote supervision and control, record potential fault, | ||||
| send out warning signs to the operators.(need customization) | |||||
| Software environment | WindowsNT,Windows1999,WindowsXP | ||||
| Luminous point width between centres | Deviation<3% | ||||
| Brightness uniformity | <10% | ||||
| Waterproof | IP65 | ||||
| Color uniformity(chromaticity coordinate) | ±0.003 | ||||
| Power supply request | AC85-264V(50Hz-60Hz) | ||||
| Contrast | (1000:1) | ||||
| System protection | Moistureproof,dustproof,high temperature protection,anti-corrosion,anti-burning,anti-static,anti-vibration | ||||
| Humidity(working) | working:10-95% | ||||
| Humidity(storing) |
storing:10-95% |
||||
Spare parts warranty period Configuration Guidelines:
(1)Adequacy: With the specific equipment, spare parts allocation adequate, ensure replacement in the first time of equipment failure;
(2)Necessity: On the basis of previous maintenance experience, we configure the spare parts are the key parts of the equipment, so as to ensure the economic allocation;
(3)Economic practicality: In order to deal with the fault in the shortest time, we configure the spare parts are complete module or unit, through our training, the owners can easily replace the spare parts, so as to ensure the normal operation of the system.
FAQ
Q1: Can you provide OEM or ODM service?
Yes, our company specializes in OEM and ODM services with excellent R&D team, perfect quality and lighting solutions, just tell us what you think.
Q2: What kind of packaging is usually used for this product?
Usually we provide air box packaging (wooden box and flight case are available)
Q3: Can I print my logo on the lamps?
A: Yes, we can print your logo on the lamps for free.
Q 4: Do you offer a warranty on your products?
A: We offer a three-year warranty. The defective rate of our products is less than 0.2%.
Q 5: How long does it take to produce after an order is placed?
A: It depends on the quantity of the order. Most online wholesale orders are shipped within 3-5 days after payment is received.
Q 6: What payment methods do you accept for full orders?
We offer a variety of payment methods including PayPal, Visa, MasterCard, Alibaba Trade Assurance, Western Union, and Wire Transfer (T/T).
