Shenzhen Shichuangxinke Electronics Co.,Ltd
professional makes good quality, provide perfect product and service for every customer.
 |
| Place of Origin: | China（Mainland） |
| Brand Name: | SCXK |
| Certification: | CE，ISO，FCC，UL |
| Model Number: | SCXK-P4.81 |
| Minimum Order Quantity: | 5 sqms |
|---|---|
| Price: | 900-1000USD/sqm |
| Packaging Details: | Wooden and flight cases,it's up to you. |
| Delivery Time: | 12-15 working days after receiving your down payment. |
| Payment Terms: | T/T, Western Union |
| Supply Ability: | 5000sqms/month |
| Type: | Full Color Led Display | Kind Of Cabinets: | Iron/Die Casting Cabinet |
|---|---|---|---|
| Module Size: | 250*250MM | Cabinet Size: | 500*1000MM |
| Waterproof: | IP65 | Application Place: | Outdoor |
| Resolution: | 52*52 | Brightness: | 7500cd/sqm |
| Pixel Pitch: | 4.81MM | Pixel Density: | 43222dots/sqm |
| Highlight: | led stage display,stage led display |
||
Full Color Stage LED Screen P4.81 Video Display HD 1/13 Scan Mode Outdoor IP65
Introduction of the cabinets:
We have two kinds of cabinets, one is iron cabinet and the other is die-cast cabinet.
Maybe you will be confused about this, then let me tell you.
Iron cabinet is used for fixed installation and is heavier. You can use it indoors and outdoors; die-cast cabinet is used for rental installation and is relatively light,
You can also use it indoors and outdoors, such as wedding parties, concerts, etc.
Therefore, for indoor use, you should pay attention to brightness, resolution, especially
scanning mode, because the viewing distance is close and the video needs to be vivid; for outdoor use,
waterproof is obviously important because of weather and some other uncertain situations.
Then the application place is also important, for your reference, if you use it on the road, then
the spacing can be large, which is enough. If you use it for concerts, then the spacing needs to be relatively small, but not too small, about 5mm is fine.
First of all, you should understand 3 points before buying: indoor or outdoor, fixed or rental, and the picture effect you want. Then you can tell us these, and we will recommend the most suitable product for you.
Thank you for your time, waiting for your online consultation!
Specifications of product:
| Outdoor P4.81 LED screen Display | |||||
| Resolution/mm | 4.81 | ||||
| Pixel configuration | 1R1G1B | ||||
| Pixel density/pixels/m² | 43222/square meter | ||||
| Module resolution | 52*52mm | ||||
| Module size/mm | 250*250mm | ||||
| View distance | 5-100m | ||||
| Single point brightness adjust | Can be added | ||||
| Single point color adjust | Can be added | ||||
| White balance brightness | >7500cd/square meter | ||||
| Color temperature | 6500K-9500K | ||||
| Horizontal view angle | 120(degrees) | ||||
| Vertical view angle | 60(degrees) | ||||
| Signal Process bit | 10 or 16bit | ||||
| Grey process | 1024x1024x1024 16834x16834x16834 65536x65536x65536 | ||||
| Control distances | Internet cable:100m, multimembrane:500m, monofilm:2km | ||||
| Driving mode | Constant driving current | ||||
| Scanning mode | 1/13 | ||||
| Fresh rate | 60Hz | ||||
| Refresh frequency | >3000Hz | ||||
| Control mode | Computer synchronous | ||||
| Brightness adjusted range | Manual, automatic operation, stepless continuous adjusted | ||||
| 255 steps. No grey loss | |||||
| Out of control point | <1/10000 | ||||
| Working hours | ≥72hours | ||||
| Mean Time Between Failure | >5000hours | ||||
| Life time | 100000hours | ||||
| Life-all-white(brightness halving) | 50000hours | ||||
| Environment temperature range | Operating temperature range: -20-45℃ | ||||
| Self-check technology | LED spot self-check, communications check, power check, | ||||
| temperature monitor(need customization) | |||||
| Remote monitoring | Remote supervision and control, record potential fault, | ||||
| send out warning signs to the operators.(need customization) | |||||
| Software environment | WindowsNT,Windows1999,WindowsXP | ||||
| Luminous point width between centres | Deviation<3% | ||||
| Brightness uniformity | <10% | ||||
| Waterproof | IP65 | ||||
| Color uniformity(chromaticity coordinate) | ±0.003 | ||||
| Power supply request | AC85-264V(50Hz-60Hz) | ||||
| Contrast | (1000:1) | ||||
| System protection | Moistureproof,dustproof,high temperature protection,anti-corrosion,anti-burning,anti-static,anti-vibration | ||||
| Humidity(working) | working:10-95% | ||||
| Humidity(storing) |
storing:10-95% |
||||
The payment details:
1.We can accept the T/T,Western Union,30% in advance,balance 70% paied before the delivery.
2.Delivery time(lead time): 12-15 working days after we receive down payment.
3.Warranty: Guaranty period for free maintenance within 2 years after delivery.
4..Free training: You can send engineers to our factory for training who have knowledge of electronics. We will provide free training about how to run, maintain and repair LED display.
5.Technical Support: We can send our engineer to your city for guidance,but you must help us to get visa and pay related cost such as round-trip fly ticket,hotel,food other cost when our engineer arrive at your city.You also pay our engineer USD100.00/day/person.
RFQ:
|
Q1: What's the warranty of your LED Display Screen ? |
|
Q2: What about your pre-sale service and post-sale service? |
|
Q3: Whats your payment term? How long it takes to delivery? |
|
Q4: What's the control system? |
|
Q5: How can you ensure the led display product quality? |
FAQ
Q. Can this LED display be installed permanently outside? ---A. A series LED panel is for events use. It has no problem to be used outdoor for events. But if need long time used outdoor, such as install on truck or trailer, it is better to buy fixed LED display.
Q. How long time is needed to produce? ---A. Our production time is 7-15 working days. We have 500sqm indoor P3.91 led display stock now, delivery time is 3 days.
Q. How long does shipping take? ---A. Express and air shipping usually take 5-10 days. Sea shipping takes about 15-55 days according to different country.
Q. What trade terms do you support? ---A. We usually do FOB, CIF, DDU, DDP, EXW terms.
Q. This is the first time to import, I don’t know how to do. ---A. We offer DDP door to door service, you just need to pay us, then wait to receive order.
Q. Do I need to buy other equipment to install LED screen? ---A. You just need to prepare power distribution box, truss and installation tool. We also offer one stop purchase if you want. We can also offer stage lights and speaker.
Q.What is LED screen common size? --A. 16:9 and 4:3 aspect ratio is popular.
Welcome to visit our website and inquire us more info,waiting for you all the time!!!
