Stage Screen High Refresh Rate Outdoor Full Color LED Display P8 Fixed/Rental IP65 Waterproof

Stage Screen High Refresh Rate Outdoor Full Color LED Display P8 Fixed/Rental IP65 Waterproof

  • Stage Screen High Refresh Rate Outdoor Full Color LED Display P8 Fixed/Rental IP65 Waterproof
  • Stage Screen High Refresh Rate Outdoor Full Color LED Display P8 Fixed/Rental IP65 Waterproof
  • Stage Screen High Refresh Rate Outdoor Full Color LED Display P8 Fixed/Rental IP65 Waterproof
  • Stage Screen High Refresh Rate Outdoor Full Color LED Display P8 Fixed/Rental IP65 Waterproof
Stage Screen High Refresh Rate Outdoor Full Color LED Display P8 Fixed/Rental IP65 Waterproof
Product Details:
Place of Origin: China(Mainland)
Brand Name: SCXK
Certification: CE,ISO,FCC,UL
Model Number: SCXK-P8
Payment & Shipping Terms:
Minimum Order Quantity: 5sqms
Price: negotiation
Packaging Details: Wooden and flight cases,it's up to you.
Delivery Time: 12-15 working days after receiving your down payment.
Payment Terms: T/T, Western Union, D/A, D/P, MoneyGram
Supply Ability: 5000sqms/month
Contact Now
Detailed Product Description
Application Places: Outdoor Cabinet Type: Fixed And Rental
Pixel Pitch: 8MM Module Size: 256*128MM
Cabinet Size: 512*512MM Refresh Rate: 1920HZ
Waterproof: IP65 Scan Mode: 1/4
Resolution: 32*16 Control System: Nova,Linsn
Highlight:

full color led signs outdoor

,

full color outdoor led display

1920HZ Refresh Rate Outdoor Full Color LED Display P8 Fixed and Rental

The outdoor series is popular in many countries and is widely used. In recent years, LED displays have become increasingly popular due to their energy-saving and environmentally friendly features. The government also actively encourages the public to use LED displays instead of other power-consuming products. With the development of technology, the development trend of LED displays is inevitable, not only in China, but also in many other countries.
LED displays have a variety of uses, such as advertising, weddings, concerts, bank announcements, airport timetables...
Please contact us as soon as possible and consult for more information! ! !

Brief description:
1. High brightness, adjustable according to ambient light.
2. High waterproof system IP is 65, which can protect the screen well and will not affect the use.
3. High refresh rate can provide you with a high-effect picture, just like watching a movie.
4. Lamp beads We have Kinglight, Nationalstar. It is a very good variety in this field.

The parameter:

outdoor P8 LED screen Display
Resolution/mm 8
Pixel configuration 1R1G1B
Pixel density/pixels/m² 15625/square meter
Module resolution 32*16mm
Module size/mm 256*128mm
View distance 8-200m
Single point brightness adjust Can be added
Single point color adjust Can be added
White balance brightness >7500cd/square meter
Color temperature 6500K-9500K
Horizontal view angle 120(degrees)
Vertical view angle 60(degrees)
Signal Process bit 10 or 16bit
Grey process 1024x1024x1024 16834x16834x16834 65536x65536x65536
Control distances Internet cable:100m, multimembrane:500m, monofilm:2km
Driving mode Constant driving current
Scanning mode 1/4
Fresh rate 60Hz
Refresh frequency >3000Hz
Control mode Computer synchronous
Brightness adjusted range Manual, automatic operation, stepless continuous adjusted
255 steps. No grey loss
Out of control point <1/10000
Working hours ≥72hours
Mean Time Between Failure >5000hours
Life time 100000hours
Life-all-white(brightness halving) 50000hours
Environment temperature range Operating temperature range: -20-45℃
Self-check technology LED spot self-check, communications check, power check,
temperature monitor(need customization)
Remote monitoring Remote supervision and control, record potential fault,
send out warning signs to the operators.(need customization)
Software environment WindowsNT,Windows1999,WindowsXP
Luminous point width between centres Deviation<3%
Brightness uniformity <10%
Waterproof IP65
Color uniformity(chromaticity coordinate) ±0.003
Power supply request AC85-264V(50Hz-60Hz)
Contrast (1000:1)
System protection Moistureproof,dustproof,high temperature protection,anti-corrosion,anti-burning,anti-static,anti-vibration
Humidity(working) working:10-95%
Humidity(storing) storing:10-95%


Stage Screen High Refresh Rate Outdoor Full Color LED Display P8 Fixed/Rental IP65 Waterproof 0
Stage Screen High Refresh Rate Outdoor Full Color LED Display P8 Fixed/Rental IP65 Waterproof 1

Stage Screen High Refresh Rate Outdoor Full Color LED Display P8 Fixed/Rental IP65 Waterproof 2
Stage Screen High Refresh Rate Outdoor Full Color LED Display P8 Fixed/Rental IP65 Waterproof 3
Stage Screen High Refresh Rate Outdoor Full Color LED Display P8 Fixed/Rental IP65 Waterproof 4
Stage Screen High Refresh Rate Outdoor Full Color LED Display P8 Fixed/Rental IP65 Waterproof 5
FAQ

Q1: What is the control system? How is it?
A: We use Nova Taurus Series asynchronous control system. Support cluster play and management. Support APP/Phone/ WIFI/ Ipad/ Laptop/ PC/ Cloud control. It’s very easy and convenient to control.
Q2: Can I have a sample order for led screen?
A: Yes, we welcome sample order to test and check quality. Mixed samples areacceptable.
Q3:Is it OK to print my logo on product?
A: Yes. Please inform us formally before our production and confirm the design firstly based on our sample.
Q4: What is your best service?
1: One to one sales engineer to customer responsibility system;
2. Know your project and provide the best solution for it;
3. Track your order and let you know each step and detail of it;
4. Teach you how to install and use the screen;
5. Care the subsequent use of your screen and ensure your after - sales service be well.
Q5. How about your delivery time?
A: Generally, it will take 7-15 days after receiving your deposit. The specific delivery time depends on the items and the quantity of your order.
Q6:How about your Warranty Term?
A: 2-year warranty. Structure design, installation problem, system problem, how to use the screen…don’t worry, we have professional after-sale team to solve your any questions after you placed an order. And your exclusive sales engineer will also help you get over any problems.
