Shenzhen Shichuangxinke Electronics Co.,Ltd
professional makes good quality, provide perfect product and service for every customer.
 |
| Place of Origin: | China(Mainland) |
| Brand Name: | SCXK |
| Certification: | CE,ISO,FCC,UL |
| Model Number: | SCXK-P8 |
| Minimum Order Quantity: | 3 m² |
|---|---|
| Price: | 500-600USD/M² |
| Packaging Details: | Wooden and flight cases,it's all up to you. |
| Delivery Time: | 10-12 working days after receiving your down payment. |
| Payment Terms: | T/T, Western Union |
| Supply Ability: | 5000M/²/Month |
| Product Brand: | SCXK-RGB LED Display | Popuse: | Renatl/Fixed |
|---|---|---|---|
| Application Place: | Indoor/Outdoor | Pixel Pitch: | 8MM |
| Module Size: | 256*128MM | Cabinet Size: | 512*512MM |
| Resolution: | 32*16 | Scan Mode: | 1/4 |
| Type Of Cabinet: | Die-cast Aluminum/Iron | Brightness: | ≥5000cd/m² |
| Highlight: | full color led signs outdoor,outdoor full color led screen |
||
Advertising Outdoor Full Color LED Display P8 Fixed High Waterproof IP65
Our service:
1. Before purchase, our sales engineer will recommend suitable products according to your needs.
2. During the purchase process, we will provide all product information so that you can have a general understanding of the product.
3. After receiving your 30% advance payment, we will arrange production, and we will send you product pictures and videos so that you can understand the progress of the project.
4. After receiving your balance, we will ship it for you. During the warranty period,
Any quality problems, we will solve them for you free of charge.
Any technical problems, we will answer online within 24 hours. If you need a quick answer, we can communicate by phone, or send technicians to your country to provide support, but you need to pay the relevant fees. For more details, please contact us!
Specifications of product:
| outdoor P8 LED screen Display | |||||
| Resolution/mm | 8 | ||||
| Pixel configuration | 1R1G1B | ||||
| Pixel density/pixels/m² | 15625/square meter | ||||
| Module resolution | 32*16mm | ||||
| Module size/mm | 256*128mm | ||||
| View distance | ≥8m | ||||
| Single point brightness adjust | Can be added | ||||
| Single point color adjust | Can be added | ||||
| White balance brightness | >5000cd/square meter | ||||
| Color temperature | 6500K-9500K | ||||
| Horizontal view angle | 120(degrees) | ||||
| Vertical view angle | 60(degrees) | ||||
| Signal Process bit | 10 or 16bit | ||||
| Grey process | 1024x1024x1024 16834x16834x16834 65536x65536x65536 | ||||
| Control distances | Internet cable:100m, multimembrane:500m, monofilm:2km | ||||
| Driving mode | Constant driving current | ||||
| Scanning mode | 1/4 | ||||
| Fresh rate | 60Hz | ||||
| Refresh frequency | >1000Hz | ||||
| Control mode | Computer synchronous | ||||
| Out of control point | <1/10000 | ||||
| Aging hours | ≥72hours | ||||
| Mean Time Between Failure | >5000hours | ||||
| Life time | 100000hours | ||||
| Life-all-white(brightness halving) | 50000hours | ||||
| Environment temperature range | Operating temperature range: -20-45℃ | ||||
| Self-check technology | LED spot self-check, communications check, power check, | ||||
| temperature monitor(need customization) | |||||
| Remote monitoring | Remote supervision and control, record potential fault, | ||||
| send out warning signs to the operators.(need customization) | |||||
| Software environment | WindowsNT,Windows1999,WindowsXP | ||||
| Luminous point width between centres | Deviation<3% | ||||
| Brightness uniformity | <10% | ||||
| Color uniformity(chromaticity coordinate) | ±0.003 | ||||
| Power supply request | AC85-264V(50Hz-60Hz) | ||||
| Contrast | (1000:1) | ||||
| System protection | Moistureproof,dustproof,high temperature protection,anti-corrosion,anti-burning,anti-static,anti-vibration | ||||
| Humidity(working) | working:10-95% | ||||
| Humidity(storing) | storing:10-95% | ||||
FAQ
1.Q:Are you a factory or trading company?
A:We are a factory,located in Dalang,Longhua District .
2.Q:What kind of payment terms you accept?
A:We accept T/T,Western Union,MoneyGram etc.
3.Q:What's packaging?
A:1.Flight case packaging
2.Wooden case packaging
3.36pcs in one case packaging
4.Customized packaging
4.Q:Does you have CE/ROHS certificates?
A:Yes, we offer the CE & ROHS certificates .
5.Q:What's the shipping method,shipping time?
A:Our products could be shipped by Sea, by Air, and by Express.
by sea:20-40days; by air:5-10days ;by express:3-6days
