Shenzhen Shichuangxinke Electronics Co.,Ltd
professional makes good quality, provide perfect product and service for every customer.
 |
| Place of Origin: | China(Mainland) |
| Brand Name: | SCXK |
| Certification: | CE,ISO,FCC,UL |
| Model Number: | SCXK-P10 |
| Minimum Order Quantity: | 5m² |
|---|---|
| Price: | 400-500USD/m² |
| Packaging Details: | Wooden and fligt cases,it's all up to you. |
| Delivery Time: | 12-15 working days after receiving your down payment. |
| Payment Terms: | T/T, Western Union |
| Supply Ability: | 1000M²/Month |
| Color: | Full Color | Pixel Pitch: | 10mm |
|---|---|---|---|
| Module Size: | 320*160mm | Cabinet Size: | 960*960mm |
| Module Resolution: | 32*16 | Brightness: | ≥1000cd/m² |
| Pixel Density: | 10000dots/m² | Waterproof: | IP65 |
| Control System: | Nova | Application Place: | Outdoor |
| Highlight: | full color led signs outdoor,outdoor full color led screen |
||
HD Outdoor Full Color LED Display P10 High Resolution 1/4 Scan Mode IP65
Description:
P10 full color LED Display is better used for the outside installation,for the pixel pitch is oppisite
big,so the screen size needs a little large,the mininum area 30m² will be better.You can use it in
the commercial centure for advertising purpose,and the best viewing distance is 10m,by the time,
the viewing distance is also depended on the viewing angle.
So,before buying,you'd better well know the details,and tell them to our sales engineers,so that we
can help you to make the best decision.
Thank you for your support and hope we can make the cooperation!!!
Specifications:
| Resolution/mm | 10 |
| Pixel configuration | 1R1G1B |
| Pixel density/pixels/m² | 10000/square meter |
| Module resolution | 32*16 |
| Module size/mm | 320*160 |
| View distance | ≥10m |
| Single point brightness adjust | Can be added |
| Single point color adjust | Can be added |
| White balance brightness | >5000cd/square meter |
| Color temperature | 6500K-9500K |
| Horizontal view angle | 120(degrees) |
| Vertical view angle | 60(degrees) |
| Signal Process bit | 10 or 16bit |
| Grey process | 1024x1024x1024 16834x16834x16834 65536x65536x65536 |
| Control distances | Internet cable:100m, multimembrane:500m, monofilm:2km |
| Driving mode | Constant driving current |
| Scanning mode | (1/4) |
| Frame rate | 60Hz |
| Refresh frequency | >1000Hz |
| Control mode | Computer synchronous |
| Brightness adjusted range | Manual, automatic operation, stepless continuous adjusted |
| 255 steps. No grey loss | |
| Out of control point | <1/10000 |
| Working hours | ≥72hours |
| Mean Time Between Failure | >5000hours |
| Life time | 100000hours |
| Life-all-white(brightness halving) | 50000hours |
| Environment temperature range | Operating temperature range: -20-45℃ |
| Maximum power:/square meter | <600W |
| Average power:/square meter | <200W |
| Self-check technology | LED spot self-check, communications check, power check, |
| temperature monitor(need customization) | |
| Remote monitoring | Remote supervision and control, record potential fault, |
| send out warning signs to the operators.(need customization) | |
| Software environment | WindowsNT,Windows1999,WindowsXP |
| Luminous point width between centres | Deviation<3% |
| Waterproof | IP65 |
| Brightness uniformity | <10% |
| Color uniformity(chromaticity coordinate) | ±0.003 |
| Power supply request | AC220V/60HZ |
| Contrast | (1000:1) |
| System protection | Moistureproof,dustproof,high temperature protection,anti-corrosion,anti-burning,anti-static,anti-vibration |
| Humidity(working) | working:10-95% |
| Humidity(storing) | storing:10-95% |
