Shenzhen Shichuangxinke Electronics Co.,Ltd
professional makes good quality, provide perfect product and service for every customer.
 |
| Place of Origin: | China(Mainland) |
| Brand Name: | SCXK |
| Certification: | CE,ISO,FCC,UL |
| Model Number: | SCXK-P6.67 |
| Minimum Order Quantity: | negotiation |
|---|---|
| Price: | negotiation |
| Packaging Details: | Wooden and fligt cases,it's all up to you. |
| Delivery Time: | 12-15 working days after receiving your down payment. |
| Payment Terms: | T/T, Western Union, L/C, D/A, D/P, MoneyGram |
| Supply Ability: | 5000M²/Month |
| Color: | Full Color | Pixel Pitch: | 6.67mm |
|---|---|---|---|
| Module Size: | 320*160mm | Cabinet Size: | 640*640mm |
| Module Resolution: | 32*16 | Brightness: | ≥5000cd/m² |
| Pixel Density: | 22478dots/m² | Waterproof: | IP65 |
| Control System: | Nova | Application Place: | Outdoor |
| Highlight: | advertising led display board,outdoor advertising led display |
||
RGB Advertising LED Screens P6.67 Outdoor Series Resolution 48*24 Rental Display
Description:
There is only one type of this spacing, and the box is die-cast aluminum. It can be used for both rental and fixed installation. This product has a high cost performance in the outdoor series, not only with large spacing, but also affordable. If the screen size is around 20 square meters, this is a better choice. We will recommend the most suitable product for you, which is the purpose of our service. Choose us, we will not let you down!
About us
The company was founded in 2005 and has customers in more than 50 countries, mainly in the United States, Europe, Dubai, North America, Central America, South America and Asia. As a high-tech enterprise integrating scientific research, design, production, maintenance, sales and system integration, we have a professional high-quality technical R&D team, experienced engineers and professional product development and design engineers, an excellent marketing team, and provide 24-hour pre-sales and after-sales service. Even in the face of the harshest environment, we can carefully select the right materials and provide the best quotation.
Specifications:
| Resolution/mm | 6.67 |
| Pixel configuration | 1R1G1B |
| Pixel density/pixels/m² | 22478/square meter |
| Module resolution | 48*24 |
| Module size/mm | 320*160 |
| View distance | ≥6m |
| Single point brightness adjust | Can be added |
| Single point color adjust | Can be added |
| White balance brightness | >5000cd/square meter |
| Color temperature | 6500K-9500K |
| Horizontal view angle | 120(degrees) |
| Vertical view angle | 60(degrees) |
| Signal Process bit | 10 or 16bit |
| Grey process | 1024x1024x1024 16834x16834x16834 65536x65536x65536 |
| Control distances | Internet cable:100m, multimembrane:500m, monofilm:2km |
| Driving mode | Constant driving current |
| Scanning mode | (1/8) |
| Frame rate | 60Hz |
| Refresh frequency | >1000Hz |
| Control mode | Computer synchronous |
| Brightness adjusted range | Manual, automatic operation, stepless continuous adjusted |
| 255 steps. No grey loss | |
| Out of control point | <1/10000 |
| Working hours | ≥72hours |
| Mean Time Between Failure | >5000hours |
| Life time | 100000hours |
| Life-all-white(brightness halving) | 50000hours |
| Environment temperature range | Operating temperature range: -20-45℃ |
| Maximum power:/square meter | <650W |
| Average power:/square meter | <220W |
| Self-check technology | LED spot self-check, communications check, power check, |
| temperature monitor(need customization) | |
| Remote monitoring | Remote supervision and control, record potential fault, |
| send out warning signs to the operators.(need customization) | |
| Software environment | WindowsNT,Windows1999,WindowsXP |
| Luminous point width between centres | Deviation<3% |
| Waterproof | IP65 |
| Brightness uniformity | <10% |
| Color uniformity(chromaticity coordinate) | ±0.003 |
| Power supply request | AC220V/60HZ |
| Contrast | (1000:1) |
| System protection | Moistureproof,dustproof,high temperature protection,anti-corrosion,anti-burning,anti-static,anti-vibration |
| Humidity(working) | working:10-95% |
| Humidity(storing) |
storing:10-95% |
Packaging and shipping
Wooden case or flight case package are available.
Shipping by sea,air or DHL,multiple shipping ways for your choice.
FAQ
1.Q:Are you a factory or trading company?
A:We are a factory,located in Dalang,Longhua District .
2.Q:What kind of payment terms you accept?
A:We accept T/T,Western Union,MoneyGram etc.
3.Q:What's packaging?
A:1.Flight case packaging
2.Wooden case packaging
3.36pcs in one case packaging
4.Customized packaging
4.Q:Does you have CE/ROHS certificates?
A:Yes, we offer the CE & ROHS certificates .
5.Q:What's the shipping method,shipping time?
A:Our products could be shipped by Sea, by Air, and by Express.
by sea:20-40days; by air:5-10days ;by express:3-6days
