Shenzhen Shichuangxinke Electronics Co.,Ltd
professional makes good quality, provide perfect product and service for every customer.
 |
| Place of Origin: | China(Mainland) |
| Brand Name: | SCXK |
| Certification: | CE,ISO,FCC,UL |
| Model Number: | SCXK-P4.81 |
| Minimum Order Quantity: | negotiation |
|---|---|
| Price: | negotiation |
| Packaging Details: | Wooden and flight cases,it's all up to you. |
| Delivery Time: | 12-15 working days after receiving your down payment. |
| Payment Terms: | T/T, Western Union, L/C, D/A, D/P, MoneyGram |
| Supply Ability: | 5000m²/month |
| Pixel Pitch: | 4.81mm | Module Size: | 250*250mm |
|---|---|---|---|
| Cabinet Size: | 500*500mm | Brightness: | ≥1000cd/m² |
| Pixel Density: | 43222dots/m² | Control System: | Nova/Linsn |
| Working Voltage: | DC5V | Scan Mode: | 1/13 |
| Module Resolution: | 52*52 | Application Place: | Indoor |
| Highlight: | rgb led curtain,led curtain screen |
||
Statium Large Screen Flexible Curtain LED Display P4.81 Indoor Fixed Installation
Specifications:
| Resolution/mm | 4.81 |
| Pixel configuration | 1R1G1B |
| Pixel density/pixels/m² | 43222/square meter |
| Module resolution | 52x52 |
| Module size/mm | 250x250 |
| View distance | ≥5m |
| Single point brightness adjust | Can be added |
| Single point color adjust | Can be added |
| White balance brightness | >1000cd/square meter |
| Color temperature | 6500K-9500K |
| Horizontal view angle | 120(degrees) |
| Vertical view angle | 60(degrees) |
| Signal Process bit | 10 or 16bit |
| Grey process | 1024x1024x1024 16834x16834x16834 65536x65536x65536 |
| Control distances | Internet cable:100m, multimembrane:500m, monofilm:2km |
| Driving mode | Constant driving current |
| Scanning mode | (1/13) |
| Frame rate | 60Hz |
| Refresh frequency | >1000Hz |
| Control mode | Computer synchronous |
| Brightness adjusted range | Manual, automatic operation, stepless continuous adjusted |
| 255 steps. No grey loss | |
| Out of control point | <1/10000 |
| Working hours | ≥72hours |
| Mean Time Between Failure | >5000hours |
| Life time | 100000hours |
| Life-all-white(brightness halving) | 50000hours |
| Environment temperature range | Operating temperature range: -20-45℃ |
| Maximum power:/square meter | <800W |
| Average power:/square meter | <280W |
| Self-check technology | LED spot self-check, communications check, power check, |
| temperature monitor(need customization) | |
| Remote monitoring | Remote supervision and control, record potential fault, |
| send out warning signs to the operators.(need customization) | |
| Software environment | WindowsNT,Windows1999,WindowsXP |
| Luminous point width between centres | Deviation<3% |
| Brightness uniformity | <10% |
| waterproof | IP34 |
| Color uniformity(chromaticity coordinate) | ±0.003 |
| Power supply request | AC85-264V(50Hz-60Hz) |
| Contrast | (1000:1) |
| System protection | Moistureproof,dustproof,high temperature protection,anti-corrosion,anti-burning,anti-static,anti-vibration |
| Humidity(working) | working:10-95% |
| Humidity(storing) | storing:10-95% |
Details of payment:
1.Payment terms: TT 30% in advance,balance 70% paied before the delivery.
2.Delivery time(lead time): 12-15 working days after we receive down payment.
3.Warranty: Guaranty period for free maintenance within 2 years after delivery.
4.Free training: You can send engineers to our factory for training
who have knowledge of electronics. We will provide free training about how to run,
maintain and repair LED display.
Production process:
1) Incoming material inspection → 2) SMT → 3) Plug-in
→ 4) Wave soldering → 5) After soldering → 6) Testing
→ 7) Aging of semi-finished products → 8) Module assembly
→ 9) Gluing → 10) Aging of finished products → 11) Inspection and storage
Packaging and shipping
Wooden case or flight case package are available.
Shipping by sea,air or DHL,multiple shipping ways for your choice.
FAQ
1.Q:Are you a factory or trading company?
A:We are a factory,located in Dalang,Longhua District .
2.Q:What kind of payment terms you accept?
A:We accept T/T,Western Union,MoneyGram etc.
3.Q:What's packaging?
A:1.Flight case packaging
2.Wooden case packaging
3.36pcs in one case packaging
4.Customized packaging
4.Q:Does you have CE/ROHS certificates?
A:Yes, we offer the CE & ROHS certificates .
5.Q:What's the shipping method,shipping time?
A:Our products could be shipped by Sea, by Air, and by Express.
by sea:20-40days; by air:5-10days ;by express:3-6days
Contact Person: Lillian seori
Tel: +8619386814677
