Home ProductsIndoor Full Color LED Display

1/16 Scan 6mm SMD P3 P4 P5 P6 Led Video Display Screen Indoor 32x32 Dots Pixels

1/16 Scan 6mm SMD P3 P4 P5 P6 Led Video Display Screen Indoor 32x32 Dots Pixels

    • 1/16 Scan 6mm SMD P3 P4 P5 P6 Led Video Display Screen Indoor 32x32 Dots Pixels
    • 1/16 Scan 6mm SMD P3 P4 P5 P6 Led Video Display Screen Indoor 32x32 Dots Pixels
  • 1/16 Scan 6mm SMD P3 P4 P5 P6 Led Video Display Screen Indoor 32x32 Dots Pixels

    Product Details:

    Place of Origin: CHINA
    Brand Name: SCXK
    Certification: CE/ROHS/FCC/ISO/UL
    Model Number: P6

    Payment & Shipping Terms:

    Minimum Order Quantity: 1 sqm
    Price: negotation
    Packaging Details: plywood case, flight case, you choose what you like.
    Delivery Time: 7-10 days
    Payment Terms: T/T, Western Union, MoneyGram
    Supply Ability: 5000 sqm per month
    Contact Now
    Detailed Product Description
    Pitch: 6mm Tube Chip Color: 1R1G1B
    Module Size: 192x192mm Pixel Density: 27777/m2
    Pixels: 32x32dots Cabinet Dimension: 576x576mm
    Driving Mode: 1/16 Scan Warranty: 3 Year

    p6 LED HD Video Wall Screen, Indoor Meeting Room Rental Led Display

    LED display features:
    1) Reliable quality, advanced and mature technology, compliant with industrial standards and technology developing trend.
    2) Good heat emission, water proof and stable performance.
    3) Audio and video interface of the system can offer vivid, complete and high quality LED display to TV broadcasting signal.
    4) High resolution and definition of screen image, clear and non-flash screen image.
    5) Supports video and radio frequency input, special structure can be freely assembled.

    Module Parameter:

    Pixel pitch6mm
    Pixel configuration1R1G1B
    LED type3-in-1 SMD 3528
    Module size192x192mm
    Module resolution32*32dots


    Cabinet Parameter:

    Cabinet size576x576mm
    Cabinet materialdie casting aluminum
    Cabinet weight6.5kg
    Ingress protectionIP43


    Whole Screen Parameter

    Pixel density27778 dots/m²
    Brightness≥1500 cd/m²
    Viewing angleH≥140° V≥140°
    Min.viewing distance6m
    Max.power consumption750W/m²
    Avg.power consumption300W/m²
    Working voltage110~220VAC±15%
    InterfaceHUB75
    Colors16.7millon colors
    Gray level14-16bits
    Frame frequency>1000frames
    Refresh rate>1920Hz
    MTBF≥100,000 hours
    Lifespan≥100,000 hours
    Operating temperature-10℃ ~ +40℃
    Storage temperature-20℃ ~ +60℃


    Control System Parameter:

    Video signal (with video processor)AV, S-video,VGA, DVI, YPbPr, HDMI, SDI, DP
    Color temperatureAdjustable by software
    Brightness level256 levels, automatic adjustment by software
    Control wayComputer, video-synchronous, real-time, off-line, wireless, internet etc.


    Cabinet photo
    1/16 Scan 6mm SMD P3 P4 P5 P6 Led Video Display Screen Indoor 32x32 Dots Pixels
    1/16 Scan 6mm SMD P3 P4 P5 P6 Led Video Display Screen Indoor 32x32 Dots Pixels
    1/16 Scan 6mm SMD P3 P4 P5 P6 Led Video Display Screen Indoor 32x32 Dots Pixels
    Company profile
    Shenzhen SCXK Electronic Co.,Ltd established in 2009 and has the standard new factory, about 100 employees. We have outstanding R&D department and after-sell service workers, and separately design ability. Our product mainly included led indoor full color display, led outdoor full color display,led indoor full color display, led wireless car usd screen, poster screen,transparent screen etc.It can be used on the shopping mall, bank, bus station, train station, center of downtown, airport,school,factory,bus,taxi and so on. We adapt many methods and very good after-sell service to sell our product all over the world. Whenever and wherever we are, we always take the principle that is: professional makes good quality,good price product market to price product market to provide perfect product and service for our customers.
    1/16 Scan 6mm SMD P3 P4 P5 P6 Led Video Display Screen Indoor 32x32 Dots Pixels
    Certificate
    1/16 Scan 6mm SMD P3 P4 P5 P6 Led Video Display Screen Indoor 32x32 Dots Pixels
    Packaging and shipping
    Packing:1.wooden case packing for ironed steel cabinet.
                   2.flight case packing for die casting aluminum cabinet.
    Delivery:Shipping by sea,air or DHL,multiple shipping ways for your choice.

    1/16 Scan 6mm SMD P3 P4 P5 P6 Led Video Display Screen Indoor 32x32 Dots Pixels
    1/16 Scan 6mm SMD P3 P4 P5 P6 Led Video Display Screen Indoor 32x32 Dots Pixels


    Our service
    Warranty
    1.We guaratee all our display, modules, spare parts for TWO years.
    2.We provide technology training for free, which contains the operation and maintenance training of the LED screens in the factory.
    3.After warranty, we also can offer you the parts for replacement at our bottom price.
    4.After sales, if you have any problem about our product, you can inform us by E-mail, we will reply you at once
    when we get it and offer you a good solution to solve the problem.
    5.We also could solve problems for you antil it recovers well by remote control!

    Installation
    1.We can assist the training and technical support for the customer in the factory, if the customer require so.
    2.We could send our engineer to guide the installation to you. But the relavant cost should be paid by your esteemed company.
    3.Our technicians will offer CAD Drawing to show how to install the LED Display rightly and fast, of course, if you need.
