Shenzhen Shichuangxinke Electronics Co.,Ltd
professional makes good quality, provide perfect product and service for every customer.
 |
| Place of Origin: | China |
| Brand Name: | SCX |
| Certification: | CE,ROHS,FCC,SASO |
| Model Number: | P4.91 |
| Minimum Order Quantity: | 1 SQM |
|---|---|
| Price: | USD700-2000 |
| Packaging Details: | Flight Case , Size: 60x62x50cm, Wooden Case, Size:70x65x55cm |
| Delivery Time: | 7working days |
| Payment Terms: | L/C, D/A, D/P, T/T, Western Union, MoneyGram |
| Supply Ability: | 3000 sqm per month |
| Module Size: | 250mm X 250mm | Module Resolution: | 64mm X 64mm |
|---|---|---|---|
| Cabinet Size: | 500mm X 500mm | Cabinet Resolution: | 104 X 104 |
| Driving Method: | 1/13 | Warranty: | 5 Years |
| Brightness: | High Brightness | Color: | 1R1G1B |
| Highlight: | stage background led screen,stage led display |
||
Stage Background Super Thin P4.81 Church LED Video Wall Panel Display Events Wedding Planner
Product Features
1.Ultra-light and ultra-thin 8KG/panel with a depth of only 70mm, half the depth of a traditional LED screen, saving space and transportation costs.
2. High refresh rate Stunning visual effect.
3. No noise Fanless and air conditioning eliminates noise and reduces power consumption.
4. Detailed and smooth picture Adopting high refresh rate and high grayscale driver IC; the latest horizontal blurring circuit completely eliminates blurring and smearing.
5. Seamless splicing High picture consistency, no gaps, no information loss.
6. Quick installation and disassembly.
Company Information
Shenzhen ShiChuangXinKe Electronics Co.,Ltd
with its head office in Shenzhen, is a professional manufacturer specialized in the design, production and export of LED products. Our main products are: Small Pixel Led Screen, Glass Led Screen, Dancing Floor Led Screen and General LED Screen etc which are widely used in public places as well as transportation, security, household appliance and advertisement fields.
We have a high-quality and professional research and development team. All the products are in strict accordance with the standard of ISO9001:2000 Quality Management System.
"Good quality, reasonable price, excellent prestige and perfect service" is our philosophy. We hope to establish business relationships with you and become your loyal partner. Let's create a bright future together.
Related Products
Product Description
| Item | Specification | ||||||||
| LED Parameters |
Luminous Intensity | R:620-630, G:520-535, B:465-475 | |||||||
| Wavelength | R:400-500mcd, G:1800-2200mcd, B:350-450mcd | ||||||||
| Test Condition | R:25℃,20mA, G:25℃,20mA, B:25℃,20mA | ||||||||
| LED Module | Led Type | SMD 3 IN 1 | |||||||
| Pixel Pitch | 4.81 mm | ||||||||
| LED Shape & Size | 2mm SMD 2121 | ||||||||
| Encapsulation Type | 1R1G1B | ||||||||
| Module Dimension | 250mmx250mm | ||||||||
| Module Resolution | 64 × 64 | ||||||||
| Module Weight | 0.20 KG | ||||||||
| Pixel Density | 43222 | ||||||||
| Driving Mode | 1/13 | ||||||||
| Module Power Consumption | 20 W | ||||||||
| LED Cabinet | Cabinet Size | 500mm(W)x 500mm(H) | |||||||
| Cabinet Thickness | 70 mm | ||||||||
| Cabinet Resolution | 104x104 | ||||||||
| Cabinet Material | Die Casting Aluminum Cabinet | ||||||||
| Screen | Use | Rent | |||||||
| Cabinet Weight | 6.5 KG | ||||||||
| Optical parameters | Brightness | ≥6000 cd | |||||||
| Contrast Ratio | ≥3000:1 | ||||||||
| Single-point Brightness Correction | Available | ||||||||
| Single-point Color Correction | Available | ||||||||
| Surface Evenness | GAP< 1mm | ||||||||
| Color Temperature Condition | 3500K～9500K,(can be adjustable) | ||||||||
| Viewing angle | 140°(Horizontal),140°(Vertical) | ||||||||
| Gray Scale | 16 bit | ||||||||
| Minimum Viewing Distance | 4.81 m | ||||||||
| Brightness Adjustment | 0-100% 8 levels | ||||||||
| Power Supply |
Operation Power | AC90-260V 50-60HZ | |||||||
| Max Power Consumption | 700 W /m² | ||||||||
| Average Power Consumption | 350 W /m² | ||||||||
| Control System |
Control Mode | Synchronous Control by Linsn system | |||||||
| Frame Update Frequency | ≥600Hz | ||||||||
| Screen Refresh Frequency | ≥3840Hz | ||||||||
| Gamma Correction | (-0.5—5.0) | ||||||||
| Input Signal Support | Composite,S-Video,Component, VGA,DVI,HDMI,SDI,HD_SDI |
||||||||
| Control Distance | UTP CAT5E:100m;Multi-mode Fiber:500m; Single-mode Fiber:10km |
||||||||
| Video Signal | MPG ／MPEG／MPV／MPA／ AVI／SWF／RM／RA／RMJ／ASF |
||||||||
| Support VGA Mode | 800 x 600, 1024 x 768, 1280 x 1024, 1600 x 1200, |
||||||||
| Brightness Correction | Dot by Dot,module by module, cabinet by cabinet |
||||||||
| Operating Temp. | - 10° —+55° Celcius degree | ||||||||
| Operating Humidity | 10 - 90 % RH | ||||||||
| Operating Life | 100,000 Hours | ||||||||
| Protection Level | IP65 | ||||||||
| MTBF | 5000 Hours | ||||||||
| Out of Control Pixel Rate | 0.01% | ||||||||
Contact Person
Contact : Seori Zhou
Mob:+86-15073669571(Whatsapp/Wechat)
Email:ruby@scxled.cn
Contact Person: he
Tel: +8615019480880
