P3.91/P4.81 Outdoor Full Color LED Display Rental Screen 500x1000mm Cabinet

P3.91/P4.81 Outdoor Full Color LED Display Rental Screen 500x1000mm Cabinet

    • P3.91/P4.81 Outdoor Full Color LED Display Rental Screen 500x1000mm Cabinet
    • P3.91/P4.81 Outdoor Full Color LED Display Rental Screen 500x1000mm Cabinet
    • P3.91/P4.81 Outdoor Full Color LED Display Rental Screen 500x1000mm Cabinet
    • P3.91/P4.81 Outdoor Full Color LED Display Rental Screen 500x1000mm Cabinet
  • P3.91/P4.81 Outdoor Full Color LED Display Rental Screen 500x1000mm Cabinet

    Product Details:

    Place of Origin: CHINA
    Brand Name: SCXK
    Certification: CE/ROHS/FCC/ISO/UL
    Model Number: P3.91

    Payment & Shipping Terms:

    Minimum Order Quantity: 1sqm
    Price: negotiation
    Packaging Details: plywood case,flight case, you choose what you like.
    Delivery Time: 7-10 working days
    Payment Terms: T/T, Western Union, MoneyGram
    Supply Ability: 5000sqm per month
    Contact Now
    Detailed Product Description
    Pitch: 3.91mm Module Size: 250*250mm
    Cabinet Size: 500*1000mm Display Function: Video
    Mode Driving: 1/8S Pixel Density: 65410/m2
    Pixels: 64*64dots Brightness: ≥6500cd
    High Light:

    full color led signs outdoor

    ,

    full color outdoor led display

    P3.91/P4.81 Outdoor Full Color LED Display Rental Screen 500x1000mm Cabinet





    Module Parameter:

    Pixel pitch 3.91mm
    Pixel configuration 1R1G1B
    LED type 3-in-1 SMD 2121
    Module size 250x250mm
    Module weight 0.35kg
    Module resolution 64x64dots
    Module quantity per cabinet 8pcs


    Cabinet Parameter:

    Cabinet size 500x1000mm
    Cabinet material die- casting aluminum
    Cabinet weight 12.5kg
    Cabinet resolution 128x256 dots
    Ingress protection Front/Rear IP65/IP54


    Whole Screen Parameter

    Pixel density 65410dots/m²
    Brightness ≥6500 cd/m²
    Viewing angle H≥120° V≥120°
    Min.viewing distance 4m
    Max.power consumption 900W/m²
    Avg.power consumption 330 W/m²
    Working voltage 110~220VAC±15%
    Interface HUB75
    Colors 16.7millon colors
    Gray level 14-16bits
    Frame frequency ≥1000frames/s
    Refresh rate ≥1920Hz
    MTBF ≥50000 hours
    Lifespan ≥100000 hours
    Operating temperature -10℃ ~ +60℃
    Storage temperature -20℃ ~ +60℃


    Control System Parameter:

    Video signal (with video processor) AV, S-video,VGA, DVI, YPbPr, HDMI, SDI, DP
    Color temperature Adjustable by software
    Brightness level 256 levels, automatic adjustment by software
    Control way Computer, video-synchronous, real-time, off-line, internet etc.





    Buying Guides

    In order to offer you a suitable solution, please follow the guides bellowing :
    1,Dimension (Width and Height)
    2,Location of installation. (picture is best)
    3,Purpose. ( what are you going to do with the LED Curtain)

    4,Star effect or video effect which you need.

    After-Sale Service
    1. Three year warranty , Lifetime free maintenance.
    2. Complaint respond period not exceed 24 hours; maintenance guidance and problem solution supplied in 48 hours.
    3. Customer satisfaction tracking report.
    4. Free technician training.
    5. Full set of documents free of charge, which including installation guidance, software operation manual, easy maintenance manual and control system software CD and so on
    6. Special service for big project, such as stadium, exhibitions, squares and so on.



    company profile

    Shenzhen SCXK Electronic Co.,Ltd established in 2009 and has the standard new factory, about 100 employees. We have outstanding R&D department and after-sell service workers, and separately design ability. Our product mainly included led indoor full color display, led outdoor full color display,led indoor full color display, led wireless car usd screen, poster screen,transparent screen etc.It can be used on the shopping mall, bank, bus station, train station, center of downtown, airport,school,factory,bus,taxi and so on. We adapt many methods and very good after-sell service to sell our product all over the world. Whenever and wherever we are, we always take the principle that is: professional makes good quality,good price product market to price product market to provide perfect product and service for our customers.
    P3.91/P4.81 Outdoor Full Color LED Display Rental Screen 500x1000mm Cabinet 0


    Certificate
    P3.91/P4.81 Outdoor Full Color LED Display Rental Screen 500x1000mm Cabinet 1


    Packaging and shipping
    Packing:1.wooden case packing for ironed steel cabinet.
    2.flight case packing for die casting aluminum cabinet.
    Delivery:Shipping by sea,air or DHL,multiple shipping ways for your choice.
    P3.91/P4.81 Outdoor Full Color LED Display Rental Screen 500x1000mm Cabinet 2
    P3.91/P4.81 Outdoor Full Color LED Display Rental Screen 500x1000mm Cabinet 3
