High Brightness Outdoor Full Color LED Display 4mm Pixel Pitch HD Waterproof

Brand Name:	SCXK
Model Number:	SCXK-P4
MOQ:	5sqm
Price:	800-1000USD/sqm
Payment Terms:	T/T, Western Union
Supply Ability:	3000sqm/month

Detail Information

Product Description

Detail Information

Place of Origin:

China(Mainland)

Certification:

CE,ISO.UL

Pixel Pitch:

4mm

Color:

Full Color

Module Size:

256*128mm

Cabinet Size:

512*512mm

Brightness:

5500cd/sqm

Resolution:

64*32

Packaging Details:

Wooden and flight case.

Highlight:

full color led signs outdoor

full color outdoor led display

Product Description

Good Price Outdoor Full Color LED Display P4 256*128mm 1920HZ HD

Control system:Linsn and Nova;

LED lamp:Epistar,Kinglight,Nationstar;

Power supply:Chuanglian,Meanwell,Souren,E-energy

Video processor:LVP605,605S,SCX818;(you also can provide the brand you want)

Refresh rate 3840,1920HZ

Specifications :

outdoor P4 LED screen Display
Resolution/mm	4
Pixel configuration	1R1G1B
Pixel density/pixels/m²	62500/square meter
Module resolution	64*32mm
Module size/mm	256*128mm
View distance	4-50m
Single point brightness adjust	Can be added
Single point color adjust	Can be added
White balance brightness	5500cd/square meter
Color temperature	6500K-9500K
Horizontal view angle	120(degrees)
Vertical view angle	60(degrees)
Signal Process bit	10 or 16bit
Grey process	1024x1024x1024 16834x16834x16834 65536x65536x65536
Control distances	Internet cable:100m, multimembrane:500m, monofilm:2km
Driving mode	Constant driving current
Scanning mode	static full color SCANNING
Fresh rate	60Hz
Refresh frequency	1920Hz
Control mode	Computer synchronous
Brightness adjusted range	Manual, automatic operation, stepless continuous adjusted
	255 steps. No grey loss
Out of control point	<1/10000
Working hours	≥72hours
Mean Time Between Failure	>5000hours
Life time	100000hours
Life-all-white(brightness halving)	50000hours
Environment temperature range	Operating temperature range: -20-45℃
Self-check technology	LED spot self-check, communications check, power check,
	temperature monitor(need customization)
Remote monitoring	Remote supervision and control, record potential fault,
	send out warning signs to the operators.(need customization)
Software environment	WindowsNT,Windows1999,WindowsXP
Luminous point width between centres	Deviation<3%
Brightness uniformity	<10%
Color uniformity(chromaticity coordinate)	±0.003
Power supply request	AC85-264V(50Hz-60Hz)
Contrast	(1000:1)
System protection	Moistureproof,dustproof,high temperature protection,anti-corrosion,anti-burning,anti-static,anti-vibration
Humidity(working)	working:10-95%
Humidity(storing)	storing:10-95%

High Brightness Outdoor Full Color LED Display 4mm Pixel Pitch HD Waterproof 0

Payment:

1. We can accept T/T payment, 30% deposit is used to secure the order and we will ship the goods,

After 70% down payment, we will ship the goods.

2. Delivery time (lead time): 12-15 working days after receiving the deposit.

3. Warranty: Warranty period is 2 years after delivery for free repair.

4. 24 hours online service, you can check any information!

Our company is located in Shenzhen, China and has been in the RGB LED display business since 2005.

We have our own factory with professional equipment and strict quality requirements,

We respect our customers and protect their data.

You choose to trust us, we will double back!!!!

If you have any questions ,just type down and send to me!
