Iron Cabinet Outdoor Waterproof Full Color LED Display Pre-Maintenance P8 Lightweight IP65

Brand Name:	SCX
Model Number:	SCX-P8
MOQ:	5 M²
Price:	525 USD/M²
Payment Terms:	T/T, Western Union
Supply Ability:	3000M²/month

Detail Information

Product Description

Detail Information

Place of Origin:

China(Mainland)

Certification:

CE,ISO,FCC,UL

Brand:

SCX RGB Screen

Cabinet:

Iron

Pixel Pitch:

8mm

Module Size:

256*128mm

Cabinet Size:

1024*768mm

Miantance:

Pre-maintance

Warranty:

3 Years

Installation:

Outdoor

Packaging Details:

Wooden and flight cases.

Highlight:

full color led signs outdoor

full color outdoor led display

Product Description

Outdoor Full Color LED Display Pre-maintance P8 Light Weght IP65

Pre-maintance:

This type of installation is very easy for buyers to evaluate

, you don't need to remove the cabinet, just remove the module with a bolt driver.

This design can save labor, material and financial resources.

And the price is also very suitable, not very high, but very convenient, many customers have bought it to install in buildings.

Short introduction:

1. The cabinet is made of iron and the size is 960*960;

2. The waterproof level is IP65, which can protect the screen well;

3. The instructions are very simple, such as the control system and playback software;

Specifications :

Outdoor P8 Pre-maintance LED Display
Resolution/mm	8
Pixel configuration	1R1G1B
Pixel density/pixels/m²	15625/square meter
Module resolution	32x16
Module size/mm	256x128
View distance	8-100m
Single point brightness adjust	Can be added
Single point color adjust	Can be added
White balance brightness	5000cd/square meter
Color temperature	6500K-9500K
Horizontal view angle	120(degrees)
Vertical view angle	60(degrees)
Signal Process bit	10 or 16bit
Grey process	1024x1024x1024 16834x16834x16834 65536x65536x65536
Control distances	Internet cable:100m, multimembrane:500m, monofilm:2km
Driving mode	Constant driving current
Scanning mode	1/4 SCANNING
Frame rate	60Hz
Refresh frequency	1200Hz
Control mode	Computer synchronous
Brightness adjusted range	Manual, automatic operation, stepless continuous adjusted
	255 steps. No grey loss
Out of control point	<1/10000
Working hours	≥72hours
Mean Time Between Failure	>5000hours
Life time	100000hours
Life-all-white(brightness halving)	50000hours
Environment temperature range	Operating temperature range: -20-45℃
Self-check technology	LED spot self-check, communications check, power check,
	temperature monitor(need customization)
Remote monitoring	Remote supervision and control, record potential fault,
	send out warning signs to the operators.(need customization)
Software environment	WindowsNT,Windows1999,WindowsXP
Luminous point width between centres	Deviation<3%
Brightness uniformity	<10%
Color uniformity(chromaticity coordinate)	±0.003
Power supply request	AC85-264V(50Hz-60Hz)
Contrast	(1000:1)
System protection	Moistureproof,dustproof,high temperature protection,anti-corrosion,anti-burning,anti-static,anti-vibration
Humidity(working)	working:10-95%
Humidity(storing)	storing:10-95%

Iron Cabinet Outdoor Waterproof Full Color LED Display Pre-Maintenance P8 Lightweight IP65 0

Iron Cabinet Outdoor Waterproof Full Color LED Display Pre-Maintenance P8 Lightweight IP65 1

Competitive advantage:

1.Timely response rate;

2.Patient service；

3.Enjoy two-year free warranty service;

4.Payment for T/T,you just need to pay 30% deposit,we will produce the goods;

5.When the down payment complicated,we will send it right away;

Any other questions,you can write to us online or send the email,

we will reply you in 1 hour!
