Shenzhen Shichuangxinke Electronics Co.,Ltd
professional makes good quality, provide perfect product and service for every customer.
 |
| Place of Origin: | China(Mainland) |
| Brand Name: | SCXK |
| Certification: | CE,ISO,DCC,UL |
| Model Number: | SCXK-P4 |
| Minimum Order Quantity: | 5sqm |
|---|---|
| Price: | 600USD/sqm |
| Packaging Details: | Wooden and flight cases. |
| Delivery Time: | 12-15 working days |
| Payment Terms: | T/T, Western Union |
| Supply Ability: | 5000sqm /month |
| Installation Place: | Indoor | Pixel Pitch: | 4mm |
|---|---|---|---|
| Scan Mode: | 1/16 | Module Size: | 256*128mm |
| Brightness: | 800cd/sqm | Cabinet Size: | 512*512mm |
| Weight: | 6.7KG | Warranty: | 2 Years |
| High Light: | led digital billboards,led advertising billboards |
||
RGB LED Billboards P4 Indoor Screen Brightness 800cd Video Vivid Epistar
Normal questions:
1.What's your advantages?
①Good price for high quality.
②Quick delivery after receiving your down payment.
③2 years free warranty.
2.How to make an order?
You just need to look through the catalog,and tell us the item you interested,
and then we will discuss with you about the details.----just contact us,everything will be solved!
3.How to prove ?
For this,you don't worry,we will provide you our certification,business lincence,
Factory Lease Contract and other which have the legal effect to let you trust us.
Specifications of products:
| Indoor P4 LED Display Screen | |||||
| Resolution/mm | 4 | ||||
| Pixel configuration | 1R1G1B | ||||
| Pixel density/pixels/m² | 62500/square meter | ||||
| Module resolution | 64x32 | ||||
| Module size/mm | 256x128 | ||||
| View distance | 4-30m | ||||
| Single point brightness adjust | Can be added | ||||
| Single point color adjust | Can be added | ||||
| White balance brightness | 800cd/square meter | ||||
| Color temperature | 6500K-9500K | ||||
| Horizontal view angle | 120(degrees) | ||||
| Vertical view angle | 60(degrees) | ||||
| Signal Process bit | 10 or 16bit | ||||
| Grey process | 1024x1024x1024 16834x16834x16834 65536x65536x65536 | ||||
| Control distances | Internet cable:100m, multimembrane:500m, monofilm:2km | ||||
| Driving mode | Constant driving current | ||||
| Scanning mode | 1/16 SCANNING | ||||
| Frame rate | 60Hz | ||||
| Refresh frequency | 1000Hz | ||||
| Control mode | Computer synchronous | ||||
| Brightness adjusted range | Manual, automatic operation, stepless continuous adjusted | ||||
| 255 steps. No grey loss | |||||
| Out of control point | <1/10000 | ||||
| Working hours | ≥72hours | ||||
| Mean Time Between Failure | >5000hours | ||||
| Life time | 100000hours | ||||
| Life-all-white(brightness halving) | 50000hours | ||||
| Environment temperature range | Operating temperature range: -20-45℃ | ||||
| Self-check technology | LED spot self-check, communications check, power check, | ||||
| temperature monitor(need customization) | |||||
| Remote monitoring | Remote supervision and control, record potential fault, | ||||
| send out warning signs to the operators.(need customization) | |||||
| Software environment | WindowsNT,Windows1999,WindowsXP | ||||
| Luminous point width between centres | Deviation<3% | ||||
| Brightness uniformity | <10% | ||||
| Color uniformity(chromaticity coordinate) | ±0.003 | ||||
| Power supply request | AC85-264V(50Hz-60Hz) | ||||
| Contrast | (1000:1) | ||||
| System protection | Moistureproof,dustproof,high temperature protection,anti-corrosion,anti-burning,anti-static,anti-vibration | ||||
| Humidity(working) | working:10-95% | ||||
| Humidity(storing) | storing:10-95% | ||||
Short introduction of us:
Our company was founded in 2005,It has been more than ten years since then.
During this period, our technology has matured, we have professional equipment,
strict quality control, responsible team.
Our customers come from all over the world, as well as specialized suppliers.
At the same time, we are constantly expanding our customer base and striving to win customers with quality.
Our company is located in Shenzhen and has its own factory,
If you come to China, we sincerely invite you to visit our factory and the production
process of our products. I believe you will trust us more.
