Shenzhen Shichuangxinke Electronics Co.,Ltd
professional makes good quality, provide perfect product and service for every customer.
 |
| Place of Origin: | China(Mainland) |
| Brand Name: | SCX |
| Certification: | CE,ISO,FCC,UL |
| Model Number: | SCX-P8 |
| Minimum Order Quantity: | 5sqm |
|---|---|
| Price: | 432-565 USD/sqm |
| Packaging Details: | Carton paper case,wooden and flight packing cases. |
| Delivery Time: | 12-15 working days. |
| Payment Terms: | T/T, Western Union |
| Supply Ability: | 5000sqm /month |
| Protection Level: | IP65 | Pixel Pitch: | 8mm |
|---|---|---|---|
| Working Voltage: | DC5V | Drive Mode: | 1/4 |
| LED Chip: | Epistar | Refresh Rate: | 1200HZ |
| Application Place: | Outdoor | Warranty: | 2 Years |
| Highlight: | full color led signs outdoor,outdoor full color led screen |
||
Outdoor Full Color LED Display P8 Fixed Screen for Football Statium IP65 HD
The stadium display screen breaks through the limitations of traditional advertising, making sports more colorful, passionate, and exciting. Not only athletes are excited, but also the audience can better integrate into it. 1. The upper part is protected by a mask, so you won’t get hurt even if you accidentally touch it, which is safe and secure. 2. The display effect is clear, natural and free of impurities. 3. The working voltage is DC5V, and the power supply is Meanwell. 4. We have LSN and Nova control systems for you to choose from, and you can also choose other solutions.
Specifications :
| Outdoor P8 LED Display Screen | |||||
| Resolution/mm | 8 | ||||
| Pixel configuration | 1R1G1B | ||||
| Pixel density/pixels/m² | 15625/square meter | ||||
| Module resolution | 32x16 | ||||
| Module size/mm | 256x128 | ||||
| View distance | 8-50m | ||||
| Single point brightness adjust | Can be added | ||||
| Single point color adjust | Can be added | ||||
| White balance brightness | >5000cd/square meter | ||||
| Color temperature | 6500K-9500K | ||||
| Horizontal view angle | 120(degrees) | ||||
| Vertical view angle | 60(degrees) | ||||
| Signal Process bit | 10 or 16bit | ||||
| Grey process | 1024x1024x1024 16834x16834x16834 65536x65536x65536 | ||||
| Control distances | Internet cable:100m, multimembrane:500m, monofilm:2km | ||||
| Driving mode | Constant driving current | ||||
| Scanning mode | 1/4 SCANNING | ||||
| Frame rate | 60Hz | ||||
| Refresh frequency | >1200Hz | ||||
| Control mode | Computer synchronous | ||||
| Brightness adjusted range | Manual, automatic operation, stepless continuous adjusted | ||||
| 255 steps. No grey loss | |||||
| Out of control point | <1/10000 | ||||
| Working hours | ≥72hours | ||||
| Mean Time Between Failure | >5000hours | ||||
| Life time | 100000hours | ||||
| Life-all-white(brightness halving) | 50000hours | ||||
| Environment temperature range | Operating temperature range: -20-45℃ | ||||
| Self-check technology | LED spot self-check, communications check, power check, | ||||
| temperature monitor(need customization) | |||||
| Remote monitoring | Remote supervision and control, record potential fault, | ||||
| send out warning signs to the operators.(need customization) | |||||
| Software environment | WindowsNT,Windows1999,WindowsXP | ||||
| Luminous point width between centres | Deviation<3% | ||||
| Brightness uniformity | <10% | ||||
| Color uniformity(chromaticity coordinate) | ±0.003 | ||||
| Power supply request | AC85-264V(50Hz-60Hz) | ||||
| Contrast | (1000:1) | ||||
| System protection | Moistureproof,dustproof,high temperature protection,anti-corrosion,anti-burning,anti-static,anti-vibration | ||||
| Humidity(working) | working:10-95% | ||||
| Humidity(storing) | storing:10-95% | ||||
Applications:
1.Airport Full Color Indoor LED displays
2.Train station Indoor Full Color LED Displays
3.Entertainment Bar Indoor Full Color LED Screen
4.Stadium Indoor Full Color LED Display
5.Museum Full Color Indoor LED display
6.Car exhibition LED display
7.Conference room Indoor Full Color LED Video Display
8.Shopping Mall Indoor Full Color LED display
FAQ
1.Q:Are you a factory or trading company?
A:We are a factory,located in Dalang,Longhua District .
2.Q:What kind of payment terms you accept?
A:We accept T/T,Western Union,MoneyGram etc.
3.Q:What's packaging?
A:1.Flight case packaging
2.Wooden case packaging
3.36pcs in one case packaging
4.Customized packaging
4.Q:Does you have CE/ROHS certificates?
A:Yes, we offer the CE & ROHS certificates .
5.Q:What's the shipping method,shipping time?
A:Our products could be shipped by Sea, by Air, and by Express.
by sea:20-40days; by air:5-10days ;by express:3-6days
