HD Indoor Full Color Video Wall Rental 5mm Pixel Pitch Die Casting Cabinet

HD Indoor Full Color Video Wall Rental 5mm Pixel Pitch Die Casting Cabinet

    • HD Indoor Full Color Video Wall Rental 5mm Pixel Pitch Die Casting Cabinet
    • HD Indoor Full Color Video Wall Rental 5mm Pixel Pitch Die Casting Cabinet
  • HD Indoor Full Color Video Wall Rental 5mm Pixel Pitch Die Casting Cabinet

    Product Details:

    Place of Origin: China
    Brand Name: SCXK
    Certification: CE/ROHS/FCC/ISO/UL
    Model Number: P3

    Payment & Shipping Terms:

    Minimum Order Quantity: 1sqm
    Price: negotiation
    Packaging Details: wooden case or flight case are available.
    Delivery Time: 7-15 working days
    Payment Terms: T/T, Western Union, MoneyGram
    Supply Ability: 5000sqm per month
    Contact Now
    Detailed Product Description
    Pixel Pitch: 5mm Pixel Configuration: 1R1G1B
    Pixel Density: 111111dots/m2 Module Size: 192x192mm
    Driving Mode: 1/16 Scan Brightness: ≥1500cd/m2
    Cabinet Size: 576x576mm Cabinet Material: Die Casting Aluminum Cabinet
    Warranty: 3 Year

    Led Screen HD P3 Indoor Full Color Rental Led Display Die Casting Cabinet



    1. LED Chip: Supplied by Nichia of Japan & Cree of USA & Epistar of Taiwan or other high strictly

    selected LED chip, assure high definition show effect.

    2. Wide viewing angle 120/160°, perfect and impressive viewing effect.

    3. High quality IC selection: MBI5024/5035/5036/5039/5042/5124/5153, JXI5020, TLC59283 ,

    ICN2053BP/2083S or other types you require.

    4. Famous power supply selection: Meanwell, E-energy, Greatwall etc., CE, UL certified.

    5. Famous control system for optional: Synchronous: Nova, LINSN, Mooncell etc.;

    Aynchronous: Tianyi, Xixun or Betters etc.. They are stable, wide application, easy to operate,

    good refresh rate and grey scale, powerful functions to support your need.

    6. Skillful and strict assembly workmanship, can assure you high quality guaranteed products.

    7. All our products support 3 years warranty or more according to your requirements.

    8. Immediate, patient and considerated service is our principle.

    9. All products are CE, RoHS, FCC, TUV certified.

    Unit Module Specifications
    Item P3
    Pixel Pitch 3 mm
    Pixel Configuration 3in1 (1R1PG1B)
    Module Size(MM) 192*192
    Module Resolution(Dots) 64*64
    Module Weight(Kg) 0.3
    Package LED Mode SMD2121
    Max Power(Watt) 21
    Pixel Density(Dots/SQM) 111'111
    Driving Method Constant Current Driving
    Scan Method(Scan) 1/32
    Interface Way HUB 75
    Brightness(CD/SQM) ≥ 1500
    Safety Standard CCC,FCC,ROHS,TUV,CE,ETL,UL,BIS.....
    Unit Cabinet Specifications
    Cabinet Size(MM) 576*576
    Cabinet Composing(PCS) 9
    Power Supply Mode(Per Cabinet) 5V60A
    Cabinet Resolution(Dots) 192*192
    Optimal Viewing Distance(M) 3-300
    Optimal Viewing Angle Horizontal angle: 160 degree; Vertical angle: 140 degree
    Environment Temperature Storage: -40 degree ~ +85 degree; Work: -20 degree ~ +60 degree
    Relative Humidity 10% ~ 95%
    Power Supply Specifications
    Operating Voltage AC:100V~120V AC:220~240V
    Average Power(W/SQM) 150-350
    Max Power Consumption(W/SQM) ≤ 800
    Current ≤ 20mA (single LED)
    Control System Specifications
    Computer Pentium4 or above P4 or above
    Operate System Win7-11/2000/NT/XP
    Control Mode Synchronization with PC
    Main Technical Parameter Specifications
    Driving Device Constant Current Driving
    Refresh Rate ≥ 1900-3840Hz
    Gray/Color RGB each 256 grade, can display 16.7color
    Lifespan ≥ 100000hours
    Power Switch RGX Automatic Switch
    Display Mode 2048*10241024*7681280*960mm
    For more information please contact our sales.



    Die Casting Aluminum Cabinet Details, This Cabinet Is Light, Thin And Is Easy To Intall For

    Different Events.

    HD Indoor Full Color Video Wall Rental 5mm Pixel Pitch Die Casting Cabinet

    HD Indoor Full Color Video Wall Rental 5mm Pixel Pitch Die Casting Cabinet

    HD Indoor Full Color Video Wall Rental 5mm Pixel Pitch Die Casting Cabinet

    Company profile
    Shenzhen SCXK Electronic Co.,Ltd established in 2009 and has the standard new factory, about 100 employees. We have outstanding R&D department and after-sell service workers, and separately design ability. Our product mainly included led indoor full color display, led outdoor full color display,led indoor full color display, led wireless car usd screen, poster screen,transparent screen etc.It can be used on the shopping mall, bank, bus station, train station, center of downtown, airport,school,factory,bus,taxi and so on. We adapt many methods and very good after-sell service to sell our product all over the world. Whenever and wherever we are, we always take the principle that is: professional makes good quality,good price product market to price product market to provide perfect product and service for our customers.
    HD Indoor Full Color Video Wall Rental 5mm Pixel Pitch Die Casting Cabinet
    Certificate
    HD Indoor Full Color Video Wall Rental 5mm Pixel Pitch Die Casting Cabinet
    Packaging and shipping
    Packing:1.wooden case packing for ironed steel cabinet.
    2.flight case packing for die casting aluminum cabinet.
    Delivery:Shipping by sea,air or DHL,multiple shipping ways for your choice.
    HD Indoor Full Color Video Wall Rental 5mm Pixel Pitch Die Casting Cabinet
    HD Indoor Full Color Video Wall Rental 5mm Pixel Pitch Die Casting Cabinet


    Our service
    Warranty
    1.We guaratee all our display, modules, spare parts for TWO years.
    2.We provide technology training for free, which contains the operation and maintenance training of the LED screens in the factory.
    3.After warranty, we also can offer you the parts for replacement at our bottom price.
    4.After sales, if you have any problem about our product, you can inform us by E-mail, we will reply you at once
    when we get it and offer you a good solution to solve the problem.
    5.We also could solve problems for you antil it recovers well by remote control!
    Installation
    1.We can assist the training and technical support for the customer in the factory, if the customer require so.
    2.We could send our engineer to guide the installation to you. But the relavant cost should be paid by your esteemed company.
    3.Our technicians will offer CAD Drawing to show how to install the LED Display rightly and fast, of course, if you need.
