Shenzhen Shichuangxinke Electronics Co.,Ltd
professional makes good quality, provide perfect product and service for every customer.
 |
| Place of Origin: | China |
| Brand Name: | SCX |
| Certification: | CE,ROHS,FCC,SASO |
| Model Number: | P2.5 |
| Minimum Order Quantity: | 1 SQM |
|---|---|
| Price: | USD 1000-10000 |
| Packaging Details: | Wooden Case , Size: 60x62x50cm, Wooden Case, Size:70x65x55cm |
| Delivery Time: | 7 working days |
| Payment Terms: | L/C, D/A, D/P, T/T, Western Union, MoneyGram |
| Supply Ability: | 3000 sqm per month |
| Led Module: | 250*250mm | Module Power Consumption: | 25W |
|---|---|---|---|
| Pixel Format: | 1R1G1B | Module Pixles: | 4096dots |
| Module Resolution: | 64dots × 64dots | Display Function: | Video,animation,graphics |
| Warranty: | 3~5 Years | Module Size: | 250x250mm |
| Highlight: | led video screen rental,led rental screen |
||
High resolution HD Indoor P2.5 led rental Full Color Rental LED Display Panel /LED Video Wall
Features
1) High-precision die-cast aluminum cabinet design, suitable for 2K/4K standard size screen, compatible with P1.875/P1.935/P2/P2.4/P2.5. The module magnet installation adopts front maintenance design. 2) Standard 240 x 180mm module size, 4:3 ratio, low current and heat, high contrast, high brightness, refresh 3840Hz, true 16-bit grayscale. 3) Adopt pure black 1515 LED, perfect color consistency, point-to-point matching 1920 x 1080/3840 x 2160 2K/4K resolution for the best display effect. 4) Use TG (170℃) immersion gold S1000-2 substrate to ensure that the PCB board does not deform. 5) The back of the cabinet adopts high-quality thermal conductive material, and the ventilation and heat dissipation design is excellent, which improves the stability and service life of the screen. 6) 1515 high standard pure black light, color contrast reaches 9000:1, true 16bit grayscale, wide viewing angle surface luminescence, to ensure the best color performance. 7) Pure black light has no reflection under strong light, and can achieve the best display effect in different environments. 8) 100% new material plastic shell, Japanese original patented glue, long life, failure rate <10PPM. 9) Pure black light, color contrast reaches 9000:1, much higher than 5000:1 deep black light and 3000:1 ordinary black light. 10) Pure black light can show more details and delicate pictures than deep black light and ordinary black light. √ Private die-cast aluminum box and customized frame, no professional installation is required. √ Provide vertical, mobile, wall-mounted or hanging installation methods. √ Adopt pure black 1515 LED, good color consistency, point-to-point matching 1920*1080/ 3840*2160 2k/4k resolution, get the best display effect. √ Adopt TG (170°) immersion gold S1000-2 substrate to ensure that the PCB board does not deform. √ 240*180mm large size module design to ensure that there is enough power supply and wire space when the magnet is installed on the module. √ 480mm (width) * 540mm (height) die-cast aluminum cabinet design, suitable for 2k/4k standard size screens, compatible with P1.875/ P1.935/ P2/ P2.4/ P2.5 module magnet installation, adopts front maintenance design.
Specification
| Item | Parameters |
| Model | P2.5 |
| Pixel Pitch(mm) | 2.5 |
| Physical Density (dot/sqm) | 173,611 |
| LED Configuration | 1RGB |
| LED Type | SMD1515 |
| Module Size (mmxmm) | 240x180 |
| Module Resolution (PXxPX) | 96 x 72 |
| Scanning mode | 1/25 |
| Brightness(cd/sqm) | 400-1200 |
| Grey Scale | 16bit |
| Refresh Rate(Hz) | 3840Hz |
| Drive Mode | Constant Current Drive |
| Module Mask Structure | N/A |
| Horizontal Viewing Angle(Deg) | 140 |
| Vertical Viewing Angle(Deg) | 120 |
| Cabinet Resolution(PXxPX) | 192x216 |
| Module Power Consumption(w) | 23 |
| Cabinet Max Power Consumption(w) | 140 |
| Cabinet Average Power Consumption(w) | 40 |
| Cabinet Size(mmxmm) | 480x540 |
| Cabinet Weight(kg) | 8.8 |
| Cabinet Thickness(mm) | 85 |
| Cabinet Material | Die-casting Aluminum |
| Color(M) | 16.7 |
| Input Voltage | AC110V-220V +/-10% |
| Refresh Frame Frequency(Hz) | 50-60 |
| Protection Level | IP45 |
| Working Environment | Indoor |
| Working Temperature(℃) | -40°-+60° |
| Storage Humidity(RH) | 40%-60% |
| Life Span(H) | 100,000 |
Product Details
| Payment terms: |
35% deposit before production, 65% balance before shipping -T/T: -Paypal -Western Union -Escrow |
| Packing: |
-Standard Export Carton with fully Polyfoam or Pearl Wool -Flight case; -Anti-shaking wooden case |
| Shipping: |
LED module: 3 to 5 working days upon receiving deposit payment LED display: 5 to 8 working days upon receiving deposit payment |
| After-Sales-Service: |
-Lifetime with professional engineer support for free. has quality problem |
