P5 Outdoor Waterproof LED Digital Signage Full Color Brightness HD High Refresh Rate

Brand Name:	SCX
Model Number:	SCX-P5
MOQ:	5sqm
Price:	469-769USD/sqm
Payment Terms:	T/T, Western Union, L/C, D/A, D/P, MoneyGram
Supply Ability:	3000sqm/month

Detail Information

Product Description

Detail Information

Place of Origin:

China(Mainland)

Certification:

CE,ISO,UL,FCC

Tube Chip Color:

Full Color

Usage:

Outdoor,Indoor

Display Function:

Video

Pixels:

5mm

Screen Dimension:

Customized Size

Brightness:

5500cd/sqm

Warranty:

2 Years

Module Size:

320*160mm

Life Span:

100000hours

Application:

Adervertising

Packaging Details:

Carton,wooden and flight cases.

Highlight:

led digital billboards

led advertising billboards

Product Description

P5 Outdoor LED Billboards Full Color Brightness 5500nits High Refresh Rate

FAQ:

1.Except this model, are there any other models?
---yes, For indoor led screen we have p1.25,p1.56,p1.67,p1.87,p2, p2.5 p3 ,p3.91, p4 ,p4.81, p5 ,p6,p8,p10
For outdoor led screen we have p3,p3.91,p4,p4.81,p5, p5.95,p6,p6.67,p8, p10

2.Are you factory? and your warranty?
yes we are 10 years factory, 2 years warranty and lifetime maintenance

3.What's the function of your led screen?
It supports videos, flash, WAV/MIDI, PPT, images and so on

4.What's your delivery time?
Wthin 15-25 days after receiving deposit

5.What's your package and shipping way?
Goods are packed with wooden case or flight case; delivered by air or sea

Detailed description:

Resolution/mm	5
Pixel configuration	1R1G1B
Pixel density/pixels/m²	40000dots/quare meter
Module resolution	64x32
Module size/mm	320x160
View distance	5-100m
Single point brightness adjust	Can be added
Single point color adjust	Can be added
White balance brightness	5500cd/square meter
Color temperature	6500K-9500K
Horizontal view angle	120(degrees)
Vertical view angle	60(degrees)
Signal Process bit	10 or 16bit
Grey process	1024x1024x1024 16834x16834x16834 65536x65536x65536
Control distances	Internet cable:100m, multimembrane:500m, monofilm:2km
Driving mode	Constant driving current
Scanning mode	1/8
Frame rate	60Hz
Refresh frequency	1200Hz
Control mode	Computer synchronous
Brightness adjusted range	Manual, automatic operation, stepless continuous adjusted
Brightness adjusted range	255 steps. No grey loss
Out of control point	<1/10000
Working hours	≥72hours
Mean Time Between Failure	>5000hours
Life time	100000hours
Life-all-white(brightness halving)	50000hours
Environment temperature range	Operating temperature range: -20-45℃
Maximum power:/square meter	<900W
Average power:/square meter	<300W
Self-check technology	LED spot self-check, communications check, power check,
Self-check technology	temperature monitor(need customization)
Remote monitoring	Remote supervision and control, record potential fault,
Remote monitoring	send out warning signs to the operators.(need customization)
Software environment	WindowsNT,Windows1999,WindowsXP
Luminous point width between centres	Deviation<3%
Brightness uniformity	<10%
Color uniformity(chromaticity coordinate)	±0.003
Power supply request	AC85-264V(50Hz-60Hz)
Contrast	(1000:1)
System protection	Moistureproof,dustproof,high temperature protection,anti-corrosion,anti-burning,anti-static,anti-vibration
Humidity(working)	working:10-95%
Humidity(storing)	storing:10-95%
