Wedding Planning Led Video Wall Stage Display P2 P3 P4 Small Pitch High Resolution

Product Details:

Place of Origin:	CHINA
Brand Name:	SCXK
Certification:	CE,ROHS,FCC,SASO
Model Number:	P2

Payment & Shipping Terms:

Minimum Order Quantity:	1 sqm
Price:	USD 1000-10000
Packaging Details:	wooden case ，flight case，it is up to you
Delivery Time:	7-10 working days
Payment Terms:	L/C, T/T, Western Union, MoneyGram
Supply Ability:	5000 sqm month

Contact Now

Detailed Product Description

Screen Refresh Frequency:	≥3840Hz	Cabinet Size:	512MM*512MM
Module Size:	256mm*128mm	LED Shape:	2mm Smd2121
Driver Mode:	1/32	Display Color:	1.07 Billion
Protection Level:	IP34
High Light:	rental led display screen , led rental screen

Wedding planning Led video wall stage display P2 P3 P4 small pitch high resolution

Production Description

1. Classical and stable structure and performance.
2. Two patent protected strong locks design, realizing combination of reliability and security.
3. Die-casting aluminum body, light weight for easy transportation and high accuracy installation.
4. Perfectly be compatible with any existing controller and without screen shaking/quick flashing/mosaic problems.
5. Supporting installation of hanging/ground mounting, for stage/TV show/studio, and other event applications.
6. Tool free assembly and disassembly.

Value	P2.6	P2.9	P3.9	P3.9	p4.8
Pixel pitch (mm)	2.6	2.9	3.91	3.91	4.81
Pixel configuration	SMD	SMD2121	SMD2020	SMD2020	SMD2020
Brightness (nits)	1000	1000	1000	1000	1000
Pixel Matrix Per Panel	192 x 192	172 x 172	128 x 128	128 x 256	104 x 208
Pixel Matrix Per Sq.m	147929	118906	65536	65536	43264
Viewing Angle (H/V)	120/120	120/120	120/120	120/120	120/120
Refresh rate (Hz)	≥1920	≥1920	≥1920	≥1920	≥1920
IP grade ( F / R)	IP40 / IP40	IP40 / IP40	IP40 / IP40	IP40 / IP40	IP40 / IP40
Input voltage ( V )	AC220V ± 10%	AC220V ± 10%	AC220V ± 10%	AC220V ± 10%	AC220V ± 10%
Power Consumption (Max / Avg)	460/ 160 w/sq.m	600/180 w/sq.m	460/ 160 w/sq.m	260/ 100 w/sq.m	580/ 230 w/sq.m
Size (L x W x D mm)	50050082.5	50050082	500x500*82.5	500x1000*75	500x1000x75
Panel weight (Kgs)	6.8 (Die-casting Al.)	8.4 (Die-casting Al.)	6.8 (Die-casting Al.)	13.5 (Die-casting Al.)	15.7 (Die-casting Al.)
Curved	yes	yes	yes	no	no

SCX Hot Selling

Wedding Planning Led Video Wall Stage Display Screen P2 P3 P4 128*64 Resolution

Our Service

Pre-sale service

1. Reply enquiries in 24 hours.

2. Market research and forecast for customer.

3. Provide professional solutions based on customer's requirement.

4. Offer sample and all document as customers required.

5. Other services, such as factory visiting and so on.

In-sale service

1. Tracking report of production.

2. Quality test report for every order.

3. Photos and videos as per customer's requirement.

After-sale service

1. Lifetime maintenance and software upgrade.

2. Complaint respond period not exceed 24 hours, maintenance guidance and problem solution supplied in 48 hours.

3. Free technician training.

4. Full set of documents free of charge, which including installation guidance, software operation manual, easy maintenance manual and control system software CD and so on.

5. Engineer guide installation onsite if needed.
