TV Full Color Outdoor Advertising Led Display Background Screen Indoor 3mm Pitch

TV Full Color Outdoor Advertising Led Display Background Screen Indoor 3mm Pitch

  • TV Full Color Outdoor Advertising Led Display Background Screen Indoor 3mm Pitch
  • TV Full Color Outdoor Advertising Led Display Background Screen Indoor 3mm Pitch
TV Full Color Outdoor Advertising Led Display Background Screen Indoor 3mm Pitch
Product Details:
Place of Origin: China
Brand Name: SCX
Certification: CE/ROHS/FCC/ISO/UL
Model Number: SMD P3
Payment & Shipping Terms:
Minimum Order Quantity: negotiation
Price: negotiation
Packaging Details: flight case, wooden case, carton, it is up to you.
Delivery Time: 3-5 working days after receive your payment
Payment Terms: T/T, Western Union, MoneyGram
Supply Ability: 5000sqm per month
Contact Now
Detailed Product Description
Product Name: Indoor P3 Led Tv Advertising Displays Large Led Background Screen Service: Front Side
Face: 4 Face Cube Shape: Cubic Pillar
Pitch Size: 3 Mm Warranty: 5 Years
High Light:

advertising led display board

,

outdoor advertising led display

                                                     Indoor P3 led tv advertising displays large led background screen

Advantages
1) High Definition and can be adjusted, can showing DVD, TV, Dynamic images, VCRS, graphs, letters and animations for 24 hours. Sharp, colorful, synchronized with computer monitor. Waterproof, Sun-screen, antistatic, damp proof, anti-freeze, anti-thundering etc.
2) Best equality, commendably solve the problem of the mosaic, have the excellent consistency of light
3) To pictures and character, have clear, exquisite and real display effect of led sign.
4) Big viewing angle to horizontal line and vertical line, can see at every angle at this range, no picture change, no color excursion.
5) Can repair each led lamps, so the cost of maintain is lower, and easy to repair for led sign!


Features:
1. Ultrathin and lightweight: Each cabinet weighs only 8kg, easy to install and transport.
2. Noiseless: Die-casting Aluminum cabinets, fanless design with noiseless power supply.
3. Seamless: High precision CNC machining, precision up to 0.1mm
4. Fast Installation and disassembling: connection lock between cabinets are patented, closely combined, safe, reliable and adjustable, 50 cabinets can be installed in one hour.
5. Real white, brilliant colors, breathtaking grayscale.


♦ Product specification

indoor  SMD P3
Lamp size2121
Resolution/mm3
Pixel configurationRGB  3 in 1
Pixel density/pixels/m²111111/m²
Module resolution64x64
Module size/mm192x192mm
View distance≥3m
Single point brightness adjustCan be added
Single point color adjustCan be added
White balance brightness>2000cd/㎡
Color temperature6500K-9500K
Horizontal view angle120(degrees)
Vertical view angle60(degrees)
Signal Process bit10 or 14 bit
Grey process1024x1024x1024 16834x16834x16834 65536x65536x65536
Control distancesInternet cable:100m, multimembrane:500m, monofilm:5km
Driving modeConstant driving current
Scanning mode1/8
Frame rate60Hz
Refresh frequency>3000Hz
Control modeComputer synchronous
Brightness adjusted range

Manual, automatic operation, stepless continuous adjusted
255 steps. No grey loss

Out of control point<1/10000
Working hours≥72hours
Mean Time Between Failure>5000hours
Life time100000hours
Life-all-white(brightness halving)50000hours
Environment temperature rangeOperating temperature range: -20-45℃ Storing temperature range: -30-65℃
Maximum power:/㎡<900W
Average power:/㎡<300W
Self-check technology

LED spot self-check, communications check, power check,
temperature monitor(need customization)

Remote monitoring

Remote supervision and control, record potential fault,
send out warning signs to the operators.(need customization)

Software environmentWindowsNT,Windows1999,WindowsXP
Luminous point width between centresDeviation<3%
Brightness uniformity<10%
Color uniformity(chromaticity coordinate)±0.003
Power supply requestAC85-264V(50Hz-60Hz)
Contrast(1000:1)
System protectionMoistureproof,dustproof,high temperature protection,anti-corrosion,anti-burning,anti-static,anti-vibration
Humidity(working)working:10-95%
Humidity(storing)storing:10-95%


TV Full Color Outdoor Advertising Led Display Background Screen Indoor 3mm Pitch 0
♦ Production process:
1) Incoming Inspection→2) SMD→3) Plug-in
→4) Wave Soldering→5) After Welding→6) Testing
→7) Semi Finished Aging→8) Module Assembly
→9) Gluing→10) Finished Aging→11) Detection Finishing Warehousing

♦ Packaging and shipping
Wooden case or flight case package are available.
Shipping by sea,air or DHL,multiple shipping ways for your choice.

♦ Why choose us:
Continues Quality
With more than 10 years experience in led display producing,equipments are updated regularly.What’s
more,unique standardized and module production ensure our products continuous quality.

Competitive Price
With large scale production capacity and professional production technology,our company have built
effective modular production.We always stick to promote the technical innovation and reduce cost to
benefit customers.

Fast Delivery
Once we promise the delivery date,we will try our best to fulfill it.Special procedures such as emergency
inventory will be used to maintain your uninterrupted supply of the products.

Perfect Service
Pre-sales:Your purchasing requirements will be highly valued and we’ll recommend suitable products to
you.
After-sales:We will track the products usage and then constantly perfect our products.


TV Full Color Outdoor Advertising Led Display Background Screen Indoor 3mm Pitch 1
