Shenzhen Shichuangxinke Electronics Co.,Ltd
professional makes good quality, provide perfect product and service for every customer.
 |
| Place of Origin: | China(Mainland) |
| Brand Name: | SCX |
| Certification: | CE,ISO,FCC,UL |
| Model Number: | SCX-P3.91 |
| Minimum Order Quantity: | 3 sqm |
|---|---|
| Price: | 859-1100USD/sqm |
| Packaging Details: | Carton,wooden and flight cases. |
| Delivery Time: | 12-15 working days. |
| Payment Terms: | T/T, Western Union |
| Supply Ability: | 5000sqm/month |
| Function: | Play Video | Pixels: | 3.91mm |
|---|---|---|---|
| Tube Chip Color: | Full Color | Brightness: | 6000nit |
| Usage: | Outdoor | Application: | Competition/Advertising,Indoor Led Floor Screen |
| Cabinet Size: | 500x500x65mm Die Casting Aluminum | Pixel Density: | 65410dots/m2 |
| Highlight: | full color led signs outdoor,full color outdoor led display |
||
Outdoor Full Color LED Display P3.91 Brightness 6000nits Advertising Hot Sale
Good after-sales service
1. Except for human factor and force majeure, the whole system is guaranteed for two years
2. Quality warranty for one year, lifelong maintenance, and guaranteed maintenance time as specified in the contract.
3. During the warranty period: solve problems for users by telephone, fax or E-Mail. Free software updates.
4. Product quality problems caused by design, manufacture, installation process,
materials, etc. are replaced and repaired free of charge. Due to force majeure
(floods, fires, earthquakes, wars, etc.) and the user's artificial interference (construction, cleaning)
, caused by the system damage, the two sides to coordinate the solution.
5. Your inquiries about our products or prices will be replied within 24 hours
6. OEM&ODM, any of your customized lamps and lanterns we can help you to design and put into the product
7. Provide agency rights for your unique design and some of our current models
8. Protect your sales area, design concepts and all private information
9. First-class quality + reasonable price + responsible after-sales service = success and victory! Victory
| Resolution/mm | 3.91 |
| Pixel configuration | 1R1G1B |
| Pixel density/pixels/m² | 65410dots/square meter |
| Module size/mm | 500x500 |
| View distance | 4-50m |
| Single point brightness adjust | Can be added |
| Single point color adjust | Can be added |
| White balance brightness | 6000cd/square meter |
| Color temperature | 6500K-9500K |
| Horizontal view angle | 120(degrees) |
| Vertical view angle | 60(degrees) |
| Signal Process bit | 10 or 16bit |
| Grey process | 1024x1024x1024 16834x16834x16834 65536x65536x65536 |
| Control distances | Internet cable:100m, multimembrane:500m, monofilm:2km |
| Driving mode | Constant driving current |
| Scanning mode | 1/8 |
| Frame rate | 60Hz |
| Refresh frequency | 1200Hz |
| Control mode | Computer synchronous |
| Brightness adjusted range | Manual, automatic operation, stepless continuous adjusted |
| 255 steps. No grey loss | |
| Out of control point | <1/10000 |
| Working hours | ≥72hours |
| Mean Time Between Failure | >5000hours |
| Life time | 100000hours |
| Life-all-white(brightness halving) | 50000hours |
| Environment temperature range | Operating temperature range: -20-45℃ |
| Maximum power:/square meter | <1200W |
| Average power:/square meter | <380W |
| Self-check technology | LED spot self-check, communications check, power check, |
| temperature monitor(need customization) | |
| Remote monitoring | Remote supervision and control, record potential fault, |
| send out warning signs to the operators.(need customization) | |
| Software environment | WindowsNT,Windows1999,WindowsXP |
| Luminous point width between centres | Deviation<3% |
| Brightness uniformity | <10% |
| Color uniformity(chromaticity coordinate) | ±0.003 |
| Power supply request | AC85-264V(50Hz-60Hz) |
| Contrast | (1000:1) |
| System protection | Moistureproof,dustproof,high temperature protection,anti-corrosion,anti-burning,anti-static,anti-vibration |
| Humidity(working) | working:10-95% |
| Humidity(storing) | storing:10-95% |
