Shenzhen Shichuangxinke Electronics Co.,Ltd
professional makes good quality, provide perfect product and service for every customer.
 |
| Place of Origin: | China(Mainland) |
| Brand Name: | SCX |
| Certification: | CE,ISO,FCC,UL |
| Model Number: | SCX-P1.6 |
| Minimum Order Quantity: | 3 sqm |
|---|---|
| Price: | 2858USD/sqm |
| Packaging Details: | Carton,wooden and flight cases. |
| Delivery Time: | 12-15 working days. |
| Payment Terms: | T/T, Western Union |
| Supply Ability: | 5000sqm/month |
| Tube Chip Color: | Full Color | Usage: | Indoor |
|---|---|---|---|
| Pixels: | 1.6mm | Display Function: | Video |
| Brightness: | 1000nit | Life Span: | 100000hours |
| Scan Mode: | 1/30 Scanning | Module Resolution: | 120*90dots |
| Highlight: | rgb led screen,full color outdoor led display |
||
Mobile Display P1.6 Indoor High Refresh Rate 3840HZ Easy Installation IP34
Main features:
1)Vivid and accurate picture, extremely low noise, advanced testing equipment, support any PC operating system, can play
video, text, Flash, music, clock, charts and other information.
2) High brightness, supports automatic brightness adjustment.
3), long life, up to more than 100,000 hours, while the power consumption is less than one-tenth of the bulb or neon lamp;
4), easy installation interface and user-friendly software, to ensure the user-friendly interface of the LED display system
5), a wealth of domestic and international engineering experience in indoor full-color LED display screen.
Specifications:
| SMD P1.6 | |||||
| Resolution/mm | 1.6 | ||||
| Pixel configuration | 1R1G1B | ||||
| Pixel density/pixels/m² | 360000dots/square meter | ||||
| Module resolution | 120x90mm | ||||
| Module size/mm | 200x150mm | ||||
| View distance | 2-30m | ||||
| Single point brightness adjust | Can be added | ||||
| Single point color adjust | Can be added | ||||
| White balance brightness | 1000cd/square meter | ||||
| Color temperature | 6500K-9500K | ||||
| Horizontal view angle | 120(degrees) | ||||
| Vertical view angle | 60(degrees) | ||||
| Signal Process bit | 10 or 16bit | ||||
| Grey process | 1024x1024x1024 16834x16834x16834 65536x65536x65536 | ||||
| Control distances | Internet cable:100m, multimembrane:500m, monofilm:2km | ||||
| Driving mode | Constant driving current | ||||
| Scanning mode | 1/30 SCANNING | ||||
| Frame rate | 60Hz | ||||
| Refresh frequency | 3840Hz | ||||
| Control mode | Computer synchronous | ||||
| Brightness adjusted range | Manual, automatic operation, stepless continuous adjusted | ||||
| 255 steps. No grey loss | |||||
| Out of control point | <1/10000 | ||||
| Working hours | ≥72hours | ||||
| Mean Time Between Failure | >5000hours | ||||
| Life time | 100000hours | ||||
| Life-all-white(brightness halving) | 50000hours | ||||
| Environment temperature range | Operating temperature range: -20-45℃ | ||||
| Self-check technology | LED spot self-check, communications check, power check, | ||||
| temperature monitor(need customization) | |||||
| Remote monitoring | Remote supervision and control, record potential fault, | ||||
| send out warning signs to the operators.(need customization) | |||||
| Software environment | WindowsNT,Windows1999,WindowsXP | ||||
| Luminous point width between centres | Deviation<3% | ||||
| Brightness uniformity | <10% | ||||
| Color uniformity(chromaticity coordinate) | ±0.003 | ||||
| Power supply request | AC85-264V(50Hz-60Hz) | ||||
| Contrast | (1000:1) | ||||
| System protection | Moistureproof,dustproof,high temperature protection,anti-corrosion,anti-burning,anti-static,anti-vibration | ||||
| Humidity(working) | working:10-95% | ||||
| Humidity(storing) | storing:10-95% | ||||
