Wide Viewing Angle RGB LED Display HD P3.91 Outdoor Screen Dustproof For Activities

Wide Viewing Angle RGB LED Display HD P3.91 Outdoor Screen Dustproof For Activities

    • Wide Viewing Angle RGB LED Display HD P3.91 Outdoor Screen Dustproof For Activities
    • Wide Viewing Angle RGB LED Display HD P3.91 Outdoor Screen Dustproof For Activities
    • Wide Viewing Angle RGB LED Display HD P3.91 Outdoor Screen Dustproof For Activities
  • Wide Viewing Angle RGB LED Display HD P3.91 Outdoor Screen Dustproof For Activities

    Product Details:

    Place of Origin: CHINA
    Brand Name: SCXK
    Certification: CE/ROHS/FCC/ISO/UL
    Model Number: P3.91

    Payment & Shipping Terms:

    Minimum Order Quantity: negotiation
    Price: negotiation
    Packaging Details: flight case, wooden case, carton, it is up to you.
    Delivery Time: 7-10 working days
    Payment Terms: L/C, T/T, MoneyGram
    Supply Ability: 5000 sqm per month
    Contact Now
    Detailed Product Description
    Lamp Size: 2121 Esolution/mm: 3.91
    Pixel Configuration: RGB 3 In 1 Pixel Density/pixels/m²: 65410/m²
    Module Size/mm: 250x250 Scanning Mode: 1/13
    Refresh Frequency: >3000Hz Display Function: Video

    HD P3.91 outdoor LED screen for activities, LED full color screen, high resolution 3840hz



    Main feature

    1) Super-light weight panels with 14 kg per single cabinet

    2) Ultra-thin: only 75mm thickness

    3) The appearance is very simple and elegant;

    4) With special designed mask and plastic frame , the surface is very smooth and viewing angle is very large .

    5) With high end IC of MBI 5124 from Taiwan, it's of high refresh rate and flicker free video quality

    6) With fast lock system, easy to install and dismantle;

    7) Can be stacked on floor or hung on truss;

    8) The same panel is compatible with P3.91, P5.95 and P6.25 outdoor LED display . Besides 500x1000mm , we also get small 500x500mm panel optional .


    ♦ Packaging and shipping

    1. Wooden case or flight case package

    2. Shipping by sea,air or DHL,multiple shipping ways



    ♦ Product specification

    indoor SMD 3.91
    Lamp size 2121
    Resolution/mm 3.91
    Pixel configuration RGB 3 in 1
    Pixel density/pixels/m² 65410/m²
    Module resolution 64x64
    Module size/mm 250x250
    View distance ≥3m
    Single point brightness adjust Can be added
    Single point color adjust Can be added
    White balance brightness >2500cd/㎡
    Color temperature 6500K-9500K
    Horizontal view angle 120(degrees)
    Vertical view angle 60(degrees)
    Signal Process bit 10 or 14 bit
    Grey process 1024x1024x1024 16834x16834x16834 65536x65536x65536
    Control distances Internet cable:100m, multimembrane:500m, monofilm:5km
    Driving mode Constant driving current
    Scanning mode 1/13
    Frame rate 60Hz
    Refresh frequency >3000Hz
    Control mode Computer synchronous
    Brightness adjusted range

    Manual, automatic operation, stepless continuous adjusted

    255 steps. No grey loss

    Out of control point <1/10000
    Working hours ≥72hours
    Mean Time Between Failure >5000hours
    Life time 100000hours
    Life-all-white(brightness halving) 50000hours
    Environment temperature range Operating temperature range: -20-45℃ Storing temperature range: -30-65℃
    Maximum power:/㎡ <1100W
    Average power:/㎡ <280W
    Self-check technology

    LED spot self-check, communications check, power check,

    temperature monitor(need customization)

    Remote monitoring

    Remote supervision and control, record potential fault,

    send out warning signs to the operators.(need customization)

    Software environment WindowsNT,Windows1999,WindowsXP
    Luminous point width between centres Deviation<3%
    Brightness uniformity <10%
    Color uniformity(chromaticity coordinate) ±0.003
    Power supply request AC85-264V(50Hz-60Hz)
    Contrast (1000:1)
    System protection Moistureproof,dustproof,high temperature protection,anti-corrosion,anti-burning,anti-static,anti-vibration
    Humidity(working) working:10-95%
    Humidity(storing) storing:10-95%



    Product overviews
    Items Indoor Led display:
    P1.5 P2, P2.5, P3, P3.91, P4,P4.81, P5, P6, P7.62, P10
    Outdoor Led display:
    P4, P4.81, P5, P6, P8, P10, P12, P16,P20,P25,P31.25
    Dance floor led display
    Material steel,aluminum ,die casting aluminum
    Certificates CE, FCC,RoHS, CCC, UL
    Payment
    terms
    30% deposit before production, 70% balance before shipping
    T/T
    Western Union
    Packing: Standard Export Carton with fully Polyfoam or Pearl Wool
    Flight case;
    Anti-shaking wooden case
    Shipping: 5 to 7 working days upon receiving deposit payment
    After-Sales-Service: Lifetime with professional engineer support for free.
    Within 5 year, supply spare parts for free if has quality problem
    ( not by man-made damage)
    Using Range Shopping mall,bank,bus station, train station,
    center of downtown, airport, school, factory, bus, taxi,and so on.



    About us:

    Established in 2005, clients cover more than 50 cuntries, Mainly USA, Europe, dubai, north and mid america, south america, asia. As a high-tech enterprise integrated with scientific research, design, production, maintenance, sales and system integration, we have a professional high-quality technical R & D team,rich experienced engineers and professional product development and design engineers,excellent marketing team, pre and after-sales 24 hours service. Even face with harshest environment,we can carefully choose different suitable materials and make the best offer.



    Small Pixel LED Screen for Clearer Pictures



    The Small Pixel LED Display features small pixel modules which presents clearer and vivid images even in low brightness and dark days. The display is suitable for various applications including security monitoring center, scheduling command platform, smart city, television studio and high-end meetings.



    Production process:

    1) Incoming Inspection→2) SMD→3) Plug-in

    →4) Wave Soldering→5) After Welding→6) Testing

    →7) Semi Finished Aging→8) Module Assembly

    →9) Gluing→10) Finished Aging→11) Detection Finishing Warehousing

    Wide Viewing Angle RGB LED Display HD P3.91 Outdoor Screen Dustproof For Activities
