Stage Background LED Display Big Screen P3 P3.9 P4.81,500X500mm or 500x1000mm rental cabinet,1920hz refresh rate

Name: Stage Background LED Display Big Screen P3 P3.9 P4.81,500X500mm or 500x1000mm rental cabinet,1920hz refresh rate
Brand: Shenzhen ShiXin Display Technology Co.,Ltd
SKU: SMD P3
Price: 10000 USD
Availability: InStock

Brand Name:	SCXK
Model Number:	SMD P3
MOQ:	12sqm
Price:	negotiation
Payment Terms:	L/C, T/T, Western Union, MoneyGram
Supply Ability:	5000 sqm month

Detail Information

Product Description

Detail Information

Place of Origin:

CHINA

Certification:

CE,ROHS,FCC,SASO

Lamp Size:

2121

Resolution/mm:

Pixel Configuration:

RGB 3 In 1

Pixel Density/pixels/m²:

111111/m²

Module Size/mm:

192*192

View Distance:

≥0.5m

Scanning Mode:

1/4

Refresh Frequency:

>1920Hz

Cabinet Size:

500x500mm ，500x1000mm

Module Size:

250x250mm

Brightness:

5000 Nit

Led Chip:

Epistar

Packaging Details:

wooden case ,flight case, it is up to you.

Highlight:

led stage display

stage background led screen

Product Description

1R1G1B Indoor Full Color LED Display Stage Audio Visual Equipment P3 P3.9 P4.8

♦ Product specification

indoor SMD P3

Lamp size

2121

Resolution/mm

Pixel configuration

RGB 3 in 1

Pixel density/pixels/m²

111111/m²

Module resolution

64*64

Module size/mm

192*192

View distance

≥0.5m

Single point brightness adjust

Can be added

Single point color adjust

Can be added

White balance brightness

>2500cd/㎡

Color temperature

6500K-9500K

Horizontal view angle

120(degrees)

Vertical view angle

60(degrees)

Signal Process bit

10 or 14 bit

Grey process

1024x1024x1024 16834x16834x16834 65536x65536x65536

Control distances

Internet cable:100m, multimembrane:500m, monofilm:5km

Driving mode

Constant driving current

Scanning mode

1/4

Frame rate

60Hz

Refresh frequency

>4200Hz

Control mode

Computer synchronous

Brightness adjusted range

Manual, automatic operation, stepless continuous adjusted

255 steps. No grey loss

Out of control point

<1/10000

Working hours

≥72hours

Mean Time Between Failure

>5000hours

Life time

100000hours

Life-all-white(brightness halving)

50000hours

Environment temperature range

Operating temperature range: -20-45℃ Storing temperature range: -30-65℃

Maximum power:/㎡

<1000W

Average power:/㎡

<280W

Self-check technology

LED spot self-check, communications check, power check,

temperature monitor(need customization)

Remote monitoring

Remote supervision and control, record potential fault,

send out warning signs to the operators.(need customization)

Software environment

WindowsNT,Windows1999,WindowsXP

Luminous point width between centres

Deviation<3%

Brightness uniformity

<10%

Color uniformity(chromaticity coordinate)

±0.003

Power supply request

AC85-264V(50Hz-60Hz)

Contrast

(1000:1)

System protection

Moistureproof,dustproof,high temperature protection,anti-corrosion,anti-burning,anti-static,anti-vibration

Humidity(working)

working:10-95%

Humidity(storing)

storing:10-95%

Product Overviews

Items	Indoor Led display: p1.5, P2, P2.5, P3, P3.91, P4,P4.81, P5, P6, P7.62, P10 Outdoor Led display: P4, P4.81, P5, P6, P8, P10, P12, P16,P20,P25,P31.25
Material	steel,aluminum ,die casting aluminum
Payment terms	30% deposit before production, 70% balance before shipping
	T/T
	Western Union
Packing:	Standard Export Carton with fully Polyfoam or Pearl Wool
	Flight case;
	Anti-shaking wooden case
Shipping:	5 to 7 working days upon receiving deposit payment
After-Sales-Service:	Lifetime with professional engineer support for free.
After-Sales-Service:	Within 5 year, supply spare parts for free if has quality problem ( not by man-made damage)
Using Range	Shopping mall,bank,bus station, train station, center of downtown, airport, school, factory, bus, taxi,and so on.

Product Details

Stage Background LED Display Big Screen P3 P3.9 P4.81,500X500mm or 500x1000mm rental cabinet,1920hz refresh rate 0

Our Service

1. Warranty

1) We provide warranty of all components for 3 full years. During this time, we will replace or repair our goods for free if there is something wrong with them.

2) We will provide maintenance for a lifetime and charge for the raw materials only.

2. Technology Training

1) We provide the technology training for free, which contains the operation training and maintenance

2) training in the factory.

3) We will send our engineers to your country by negotiation.

3. Maintenance and Consultation

1) We provide full maintenance for a lifetime and charge for the raw materials only.

2) We also provide lifetime consultation by E-mail, Skype, WhatsApp or other ways for free.
