Outdoor Full Color Advertising Billboard Video Wall Screen P8 LED Display for fixed installation

Outdoor Full Color Advertising Billboard Video Wall Screen P8 LED Display for fixed installation

  • Outdoor Full Color Advertising Billboard Video Wall Screen P8 LED Display for fixed installation
  • Outdoor Full Color Advertising Billboard Video Wall Screen P8 LED Display for fixed installation
  • Outdoor Full Color Advertising Billboard Video Wall Screen P8 LED Display for fixed installation
  • Outdoor Full Color Advertising Billboard Video Wall Screen P8 LED Display for fixed installation
  • Outdoor Full Color Advertising Billboard Video Wall Screen P8 LED Display for fixed installation
Outdoor Full Color Advertising Billboard Video Wall Screen P8 LED Display for fixed installation
Product Details:
Place of Origin: CHINA
Brand Name: SCXK
Certification: CB/CE/ROHS/FCC/ISO/UL
Model Number: SMD P8
Payment & Shipping Terms:
Minimum Order Quantity: 10sqm
Price: negotiation
Packaging Details: wooden case,flight case,it is up to you
Delivery Time: 7-10 working days
Payment Terms: L/C, D/A, D/P, T/T, Western Union, MoneyGram
Supply Ability: 6200 sqm month
Contact Now
Detailed Product Description
Pixel Density/pixels/m²: 15625/m² Module Size/mm: 256x128
View Distance: ≥6m Application: Outdoor Advertising, Shop, Building,high Way
Color:: Full Color Panel Size:: 960x960mm
Pixel Pitch:: 5mm,6mm,8mm,10mm Display Function:: Video
Brightness:: 7500nits Control System:: Linsn/Nova
Cabinet Material:: Iron
High Light:

advertising led display board

,

outdoor advertising led display

HD Outdoor Full Color P8 Led Advertising Digital Board Display Video Screen



♦ Wide view angle:

the perfect image can be enjoyed from any direction within the range of 160°.



♦ Unique Structure:

with 75°screen frame and fast installed connector, realize plane assembly, 15° inner or outer arc assembly, displacement assembly to accomplish arbitrary model.



♦ Fastly heat dissipation:

adopt the most advanced heat conducting technology, realizing the design of fan free, totally mute voice, high efficiency in heat dissipation.



♦ Product specification

outdoor P8
Lamp size 3535
Resolution/mm 8
Pixel configuration RGB 3 in 1
Pixel density/pixels/m² 15625/m²
Module resolution 32x16
Module size/mm 256x128
View distance ≥6m
Single point brightness adjust Can be added
Single point color adjust Can be added
White balance brightness >8000cd/㎡
Color temperature 6500K-9500K
Horizontal view angle 120(degrees)
Vertical view angle 60(degrees)
Signal Process bit 10 or 14 bit
Grey process 1024x1024x1024 16834x16834x16834 65536x65536x65536
Control distances Internet cable:100m, multimembrane:500m, monofilm:5km
Driving mode Constant driving current
Scanning mode constant driving static
Frame rate 60Hz
Refresh frequency >3000Hz
Control mode Computer synchronous
Brightness adjusted range

Manual, automatic operation, stepless continuous adjusted

255 steps. No grey loss

Out of control point <1/10000
Working hours ≥72hours
Mean Time Between Failure >5000hours
Life time 100000hours
Life-all-white(brightness halving) 50000hours
Environment temperature range Operating temperature range: -20-45℃ Storing temperature range: -30-65℃
Maximum power:/㎡ <650W
Average power:/㎡ <260W
Self-check technology

LED spot self-check, communications check, power check,

temperature monitor(need customization)

Remote monitoring

Remote supervision and control, record potential fault,

send out warning signs to the operators.(need customization)

Software environment WindowsNT,Windows1999,WindowsXP
Luminous point width between centres Deviation<3%
Brightness uniformity <10%
Color uniformity(chromaticity coordinate) ±0.003
Power supply request AC85-264V(50Hz-60Hz)
Contrast (1000:1)
System protection Moistureproof,dustproof,high temperature protection,anti-corrosion,anti-burning,anti-static,anti-vibration
Humidity(working) working:10-95%
Humidity(storing) storing:10-95%

Outdoor Full Color Advertising Billboard Video Wall Screen P8 LED Display for fixed installation 0

♦ Packaging and shipping

Wooden case or flight case package are available.

Shipping by sea,air or DHL,multiple shipping ways for your choice.

Outdoor Full Color Advertising Billboard Video Wall Screen P8 LED Display for fixed installation 1

♦ Why choose us:

Continues Quality

With more than 10 years experience in led display producing,equipments are updated regularly.What’s

more,unique standardized and module production ensure our products continuous quality.



Competitive Price

With large scale production capacity and professional production technology,our company have built

effective modular production.We always stick to promote the technical innovation and reduce cost to

benefit customers.

Outdoor Full Color Advertising Billboard Video Wall Screen P8 LED Display for fixed installation 2

Our Services

Pre-sale service:
1. Reply enquiries in 24 hours.
2. Market research and forecast for customer.
3. Provide unique and professional solutions based on customer's requirement.
4. Data sheet and samples offer.
5. Other services, such as special packing design, factory visiting and so on.

In-sale service:
1. Tracking report in producing.
2. Quality test report for every order.
3. Photos and videos as per customer's requirement.
4. Free spare parts.

After-sale service:
1. Lifetime free maintenance and upgrade.
2. Complaint respond period not exceed 24 hours; maintenance guidance and problem solution supplied in 48 hours.
3. Customer satisfaction tracking report.
4. Free technician training.
5. Full set of documents free of charge, which including installation guidance, software operation manual, easy maintenance manual and control system software CD and so on.
6. Special service for big project, such as stadium, exhibitions, squares and so on.

Our team will be forever here to offer you full supports



Outdoor Full Color Advertising Billboard Video Wall Screen P8 LED Display for fixed installation 3

FAQ

1. How to choose the led display most suitable for my project? And what is the best price you can offer?

First of all, youd better to know the application of the screen ( Indoor or Outdoor); the size of the screen would be ( Length & Height); what will the screen will be used for ( advertising, on live event, need to be installed somewhere permanently or for rental use). We will check out the best price and screen upon your conditions



2. What is your lead time?

Under the normal condition, sample order for 3-7 working days, regarding mass order, if we have available raw material,the lead time will around 15 working days, otherwise, would be 20-30 working days



3. What is your payment method?

Our usually practice for payment is by T/T for the mass order and also we do the trade assurance ( Provided by Alibaba and Gteak to make sure your payment, shipment, goods quality security and ensurance)



4. What is your shipping and packing way?

Our standard packing for modules are carton box and for the led cabinet, we do wood box or flight case as per customers requests. For the mass order ( fit for a container), we do shipment by Sea and for others usually by express or airlin



5. Can i place a sample order before i decide to do the mass production?

Yes, we acceptable sample orders, please let us know your detail request then we will send you the sample asap for confirmatio



6. Can i have a free sample?

We offer free sample for some models, please advise what you need to see if we have available free samples here to be sent
