Waterproof P10 SMD 1R1G1B LED Screen Module Size 320*160mm 1/4 Scanning

Waterproof P10 SMD 1R1G1B LED Screen Module Size 320*160mm 1/4 Scanning

  • Waterproof P10 SMD 1R1G1B LED Screen Module Size 320*160mm 1/4 Scanning
  • Waterproof P10 SMD 1R1G1B LED Screen Module Size 320*160mm 1/4 Scanning
  • Waterproof P10 SMD 1R1G1B LED Screen Module Size 320*160mm 1/4 Scanning
  • Waterproof P10 SMD 1R1G1B LED Screen Module Size 320*160mm 1/4 Scanning
  • Waterproof P10 SMD 1R1G1B LED Screen Module Size 320*160mm 1/4 Scanning
  • Waterproof P10 SMD 1R1G1B LED Screen Module Size 320*160mm 1/4 Scanning
Waterproof P10 SMD 1R1G1B LED Screen Module Size 320*160mm 1/4 Scanning
Product Details:
Place of Origin: CHINA
Brand Name: SCXK
Certification: CB/CE/ROHS/FCC/ISO/UL
Model Number: SMD P10
Payment & Shipping Terms:
Minimum Order Quantity: negotiation
Price: negotiation
Packaging Details: flight case, wooden case, carton, it is up to you.
Delivery Time: 7-10 working days
Payment Terms: L/C, D/A, D/P, T/T, Western Union, MoneyGram
Supply Ability: 5000 sqm month
Contact Now
Detailed Product Description
High Light:

led screen module

,

led sign module

Advertising LED Display Module Outdoor P10 1R1G1B size 320*160mm

The detailed parameter as follows.

1, Item Name waterproof P10 SMD 1R1G1B LED Display Module size 320*160mm 1/4 scanning
2, pixel tube: pixel pitch:10mm; primary colors: pure red+pure green+pure blue ,
color composing: 1R1G1B
Density:3906dots/sq m; smd3535
3 , unit box module size:320mm×160mm; Module resolution:32X16
cabinet thickness:(cold-roll steel sheet)150mm+(maintain)600mm;
4, whole screen: the optimum viewing angel :horizontal 110°, vertical 50°
viewing distance:>15m;working temperature:-20°C~+45°C(-30°C ~+50°C optional) relative humidity:≤95%RH; Drive IC ET6024
5, operating voltage AC220V±10% or 110V±10% ,average consumption:500 W/sq m
max consumption:≤650 W/ sq m
6, main parameter 1) driving mode: 1/4 scanning
2) refreshing rate:≥400Hz/s
3) frame frequency:≥60Hz/s
4) gray scale/color:≥16.7Mcolors(Synchronized)
5) manage gray:≥72bit
6) brightness:≥7000cd/sq m
7) color temperature condition:3500K~9500K,be adjustable
8) adjusting style of brightness: hand movement/auto
9) video signal: RF,S-Video,RGB,RGBHV,YUV,YC,COMPOSITION etc. managing ability of signal:≥12bit.against Y revised curve: owns 3pcs above Y curve that can adjustable.
10) average trouble-free time:≥5000hours
11) evenness: between random adjacent pixel ≤0.5mm,module splicing space<1mm
12) switch power loading:5V/40A
13) display mode of computer:1024×768



Waterproof P10 SMD 1R1G1B LED Display Module Size 320*160mm 1/4 Scanning


Competitive Advantage:
1. 2 years’ warranty with free repair service
2. 24/7 Hours online Remote Support
3. Solution and PCB design
4. Free factory training
5. On site installation instruction and regular inspection
6, Small order accepted.

The epistar Led chip. with SMD and DIP Technology .
we adopt the epistar led chip from Taiwan,DIP and SMD led display module will be available
The wire or wireless controll system are available .( 3g and wifi controll will be welcome)


The steel consturction is very stable for led display,and you can purchase from your local market .



Methods for Quality Assurance
a. Aging
1. 100% fully test

  1. Condition: 72 hours with 256 gray level

b. Vibration Testing
Condition: 3-5 min up and down in 5mm range


Company information

Order Procedure
Negotiation---First solution recommended---Finalize all the details---30%deposit in advance or full deposit---
Start production---Pay the balance---shipment by DHL--provide tracking number---feedback.

Parking and Shipping




A. Flight case Packing
1)150KG Per flight case
2)3 cabinets in one case
3)Flight case size: 1010mm*560mm*1175mm=39inch*22inch*46inch

B. Plywood case
1)180KG per plywood case
2)3 cabinets in one case
3)Plywood case size: 1120mm*585mm*930mm= 44inch*23inch*36inch

C.customized packing is acceptable
D. 20"FT container loading of 100sq.m


1) T/T, 30% deposit, 70% before shippment.
2) 100% Western Union in advance.

Production Flo
