P6 Waterproof Big Outdoor Full Color LED Display 1/4 Scan Driving Mode

P6 Waterproof Big Outdoor Full Color LED Display 1/4 Scan Driving Mode

  • P6 Waterproof Big Outdoor Full Color LED Display 1/4 Scan Driving Mode
  • P6 Waterproof Big Outdoor Full Color LED Display 1/4 Scan Driving Mode
P6 Waterproof Big Outdoor Full Color LED Display 1/4 Scan Driving Mode
Product Details:
Place of Origin: China
Brand Name: SCXK
Certification: CE/ROHS/FCC/ISO/UL
Model Number: P6
Payment & Shipping Terms:
Minimum Order Quantity: 1sqm
Price: negotiation
Packaging Details: wooden case.
Delivery Time: 7-15 working days
Payment Terms: T/T, Western Union
Supply Ability: 5000sqm per month
Contact Now
Detailed Product Description
Pitch: 6mm Pixel Configuration: Rgb 3in1
Module Size: 192x192mm Pixel Density: 27778dots/sqm
Cabinet Size: 960x960mm Driving Mode: 1/4 Scan
Brightness: ≥5500cd/m2 Warranty: 3 Years
High Light:

full color led signs outdoor

,

outdoor full color led screen

Outdoor led screen P6 waterproof big led tv display screen billboard



We adopt the advanced production line, and employed180-200 skill workers. They are good at all kinds of the led display product. With DIP AND SMD production machine, the delivery time is very quick. Every production line with the own quality control workers. We can guarantee every production can meet your requirements.



Our engineer will take parts in all project design and they will be responbilbe all the detailed work. When the led display product finished, they will check the quality and test them directly. So the quality will be up to all the standard.


Module Parameter

Pixel pitch 6mm
Pixel configuration 1R1G1B
LED type 3-in-1 SMD 3535
Module size 192x192mm
LED lamp KingLight or Nationstar
Module resolution 32x32dots


Cabinet Parameter

Cabinet size 960x960mm
Cabinet material Ironed steel cabinet
Cabinet weight 32.5kg
Ingress protection Front/Rear IP65/IP54


Whole Screen Parameter

Pixel density 27778 dots/m²
Brightness ≥5500 cd/m²
Viewing angle H≥120° V≥60°
Min.viewing distance 6m
Max.power consumption 900W/m²
Avg.power consumption 330 W/m²
Working voltage 110~220VAC±15%
Interface HUB75
Colors 16.7millon colors
Gray level 65536
Refresh rate ≥1920Hz
MTBF ≥100,000 hours
Lifespan ≥100,000 hours
Protective function Over-heat/Over-load /Power-down /Power-leakage
/Lightning-protection etc.
Operating temperature -10℃ ~ +60℃
Storage temperature -20℃ ~ +60℃


Control System Parameter

Video signal (with video processor) AV, S-video,VGA, DVI, YPbPr, HDMI, SDI, DP
Color temperature Adjustable by software
Brightness level 256 levels, automatic adjustment by software
Control way Computer, video-synchronous, real-time, off-line, wireless, internet etc.


Company profile


Shenzhen SCXK Electronic Co.,Ltd established in 2009 and has the standard new factory, about 100 employees. We have outstanding R&D department and after-sell service workers, and separately design ability. Our product mainly included led indoor full color display, led outdoor full color display,led indoor full color display, led wireless car usd screen, poster screen,transparent screen etc.It can be used on the shopping mall, bank, bus station, train station, center of downtown, airport,school,factory,bus,taxi and so on. We adapt many methods and very good after-sell service to sell our product all over the world. Whenever and wherever we are, we always take the principle that is: professional makes good quality,good price product market to price product market to provide perfect product and service for our customers.


P6 Waterproof Big Outdoor Full Color LED Display 1/4 Scan Driving Mode 0


Certificate
P6 Waterproof Big Outdoor Full Color LED Display 1/4 Scan Driving Mode 1


Packaging and shipping


Packing:1.wooden case packing for ironed steel cabinet.
               2.flight case packing for die casting aluminum cabinet.
Delivery:Shipping by sea,air or DHL,multiple shipping ways for your choice.
