Stage LED Screens featuring 64 by 64 module resolution and 250 by 250 millimeter module size for flexible configuration

Brand Name:	SCXK
Model Number:	SMD-P4.81
MOQ:	6 sqm
Price:	negotiation
Payment Terms:	L/C,, D/A, D/P, T/T, Western Union, MoneyGram
Supply Ability:	3600 sqm month

Detail Information

Product Description

Detail Information

Place of Origin:

CHINA

Certification:

CB,CE,ROHS,FCC,SASO

Number Of Colors:

16.7 Trillion

Led Pixel:

3.91mm

Driving Ic:

MBI5124 Or ICN 2038S

Module Weight:

0.45kg

Lamp Size:

2121

Scan Way:

1/16scan

Pixel Configur:

1R1G1B

Cabinet Size:

500x500mm

Packaging Details:

wooden case，flight case，it is up to you.

Highlight:

led stage display

stage led display

Product Description

P4.81 Stage Led Screens Board , High Brightness Led Display Rental For Concert

1) Connector: Aerial grade brands ensure the stable transmission of power and signal.

2) PCB Board: adopt 4-layer design.

3) Easy installation:100 pieces of cabinets' installation can be finished in one hour by one person. The replacement of any cabinet can be done within 50 seconds.

Product specification

SMD P4.81

Lamp size

2121

Resolution/mm

4.81

Pixel configuration

RGB 3 in 1

Pixel density/pixels/m²

64510/m²

Module resolution

64x64

Module size/mm

250x250

View distance

≥2m

Single point brightness adjust

Can be added

Single point color adjust

Can be added

White balance brightness

>8000cd/㎡

Color temperature

6500K-9500K

Horizontal view angle

120(degrees)

Vertical view angle

60(degrees)

Signal Process bit

10 or 14 bit

Grey process

1024x1024x1024 16834x16834x16834 65536x65536x65536

Control distances

Internet cable:100m, multimembrane:500m, monofilm:5km

Driving mode

Constant driving current

Scanning mode

1/8

Frame rate

60Hz

Refresh frequency

>4200Hz

Control mode

Computer synchronous

Brightness adjusted range

Manual, automatic operation, stepless continuous adjusted
255 steps. No grey loss

Out of control point

<1/10000

Working hours

≥72hours

Mean Time Between Failure

>5000hours

Life time

100000hours

Life-all-white(brightness halving)

50000hours

Environment temperature range

Operating temperature range: -20-45℃ Storing temperature range: -30-65℃

Maximum power:/㎡

<1000W

Average power:/㎡

<280W

Self-check technology

LED spot self-check, communications check, power check,
temperature monitor(need customization)

Remote monitoring

Remote supervision and control, record potential fault,
send out warning signs to the operators.(need customization)

Software environment

WindowsNT,Windows1999,WindowsXP

Luminous point width between centres

Deviation<3%

Brightness uniformity

<10%

Color uniformity(chromaticity coordinate)

±0.003

Power supply request

AC85-264V(50Hz-60Hz)

Contrast

(1000:1)

System protection

Moistureproof,dustproof,high temperature protection,anti-corrosion,anti-burning,anti-static,anti-vibration

Humidity(working)

working:10-95%

Humidity(storing)

storing:10-95%

Product Overviews

Items	Indoor Led display: P2, P2.5, P3, P3.91, P4,P4.81, P5, P6, P7.62, P10 Outdoor Led display: P4, P4.81, P5, P6, P8, P10, P12, P16,P20,P25,P31.25
Material	steel,aluminum ,die casting aluminum
Payment terms	30% deposit before production, 70% balance before shipping
	T/T
	Western Union
Packing:	Standard Export Carton with fully Polyfoam or Pearl Wool
	Flight case;
	Anti-shaking wooden case
Shipping:	5 to 7 working days upon receiving deposit payment
After-Sales-Service:	Lifetime with professional engineer support for free.
After-Sales-Service:	Within 5 year, supply spare parts for free if has quality problem ( not by man-made damage)
Using Range	Shopping mall,bank,bus station, train station, center of downtown, airport, school, factory, bus, taxi,and so on.

Stage LED Screens featuring 64 by 64 module resolution and 250 by 250 millimeter module size for flexible configuration 0
Production process:
1) Incoming Inspection→2) SMD→3) Plug-in
→4) Wave Soldering→5) After Welding→6) Testing
→7) Semi Finished Aging→8) Module Assembly
→9) Gluing→10) Finished Aging→11) Detection Finishing Warehousing
Features
1. Seamless --- precision cabinet, light weight and more durable.
2. Quality LEDs --- with wide viewing angle to ensure vivid and sharp images and video.
3. High refresh rate and high gray scale --- to ensure color consistency and better images

Packaging and shipping
Wooden case or flight case package are available.
Shipping by sea,air or DHL,multiple shipping ways for your choice.
