Stage LED Screens delivering high resolution and brightness with modular design for setup and transport during outdoor events

Brand Name:	SCXK
Model Number:	SMD-P4.81
MOQ:	6 sqm
Price:	negotiation
Payment Terms:	L/C, D/A, D/P, T/T, Western Union, MoneyGram
Supply Ability:	5200 sqm month

Detail Information

Product Description

Detail Information

Place of Origin:

CHINA

Certification:

CB/CE/ROHS/FCC/ISO/UL

Module Size/mm:

250x250

Scanning Mode:

1/8

Refresh Frequency:

>4200Hz

Frame Rate:

60Hz

Warranty:

3 Years

Viewing Angle:

160° Horizontal / 140° Vertical

Power Input:

AC100～240V

Cabinet Material:

Aluminum

Led Size:

2121

Colors:

16.7million

Pixels:

2R1G1B

Gray Scale:

16 Bit

Packaging Details:

wooden case，flight case，it is up to you.

Highlight:

led stage display

stage background led screen

Product Description

P4.81 p3.91 Outdoor stage event led screens flexible backdrop screen for stage

Features

Outdoor Rental LED Display

Pitch: 3.91/ 4.81 /5.95mm

led module Size: 500x125mm

Cabinet size: 500X500mm, 500X1000mm optional

Service

1) Reply your enquiry of led display in 24 working hours.

2) Experienced staffs answer all your query in fluent English,Spanish,French,etc

3) Customized design is available,OEM & ODM are welcomed.
4) Exclusive and unique solution can be provided to our customer by our well trained and professional engineers and staffs.
5) Special discount and protection of sales area provided to our distributor.
6) Warmly welcome your visit in our company if available.
7) Warranty: 24 months, a little investment for longer warranty time.

Product specification

SMD P4.81

Lamp size

2727

Resolution/mm

4.81

Pixel configuration

RGB 3 in 1

Pixel density/pixels/m²

43222/m²

Module resolution

64x64

Module size/mm

250x250

View distance

≥2m

Single point brightness adjust

Can be added

Single point color adjust

Can be added

White balance brightness

>8000cd/㎡

Color temperature

6500K-9500K

Horizontal view angle

120(degrees)

Vertical view angle

60(degrees)

Signal Process bit

10 or 14 bit

Grey process

1024x1024x1024 16834x16834x16834 65536x65536x65536

Control distances

Internet cable:100m, multimembrane:500m, monofilm:5km

Driving mode

Constant driving current

Scanning mode

1/8

Frame rate

60Hz

Refresh frequency

>4200Hz

Control mode

Computer synchronous

Brightness adjusted range

Manual, automatic operation, stepless continuous adjusted
255 steps. No grey loss

Out of control point

<1/10000

Working hours

≥72hours

Mean Time Between Failure

>5000hours

Life time

100000hours

Life-all-white(brightness halving)

50000hours

Environment temperature range

Operating temperature range: -20-45℃ Storing temperature range: -30-65℃

Maximum power:/㎡

<1000W

Average power:/㎡

<280W

Self-check technology

LED spot self-check, communications check, power check,
temperature monitor(need customization)

Remote monitoring

Remote supervision and control, record potential fault,
send out warning signs to the operators.(need customization)

Software environment

WindowsNT,Windows1999,WindowsXP

Luminous point width between centres

Deviation<3%

Brightness uniformity

<10%

Color uniformity(chromaticity coordinate)

±0.003

Power supply request

AC85-264V(50Hz-60Hz)

Contrast

(1000:1)

System protection

Moistureproof,dustproof,high temperature protection,anti-corrosion,anti-burning,anti-static,anti-vibration

Humidity(working)

working:10-95%

Humidity(storing)

storing:10-95%

Product Details
Stage LED Screens delivering high resolution and brightness with modular design for setup and transport during outdoor events 0

Stage LED Screens delivering high resolution and brightness with modular design for setup and transport during outdoor events 1

Stage LED Screens delivering high resolution and brightness with modular design for setup and transport during outdoor events 2

Stage LED Screens delivering high resolution and brightness with modular design for setup and transport during outdoor events 3

Prepare for Installation

Stage LED Screens delivering high resolution and brightness with modular design for setup and transport during outdoor events 4

Module

Stage LED Screens delivering high resolution and brightness with modular design for setup and transport during outdoor events 5

Production process:
1) Incoming Inspection→2) SMD→3) Plug-in
→4) Wave Soldering→5) After Welding→6) Testing
→7) Semi Finished Aging→8) Module Assembly
→9) Gluing→10) Finished Aging→11) Detection Finishing Warehousing

Features
1. Seamless --- precision cabinet, light weight and more durable.
2. Quality LEDs --- with wide viewing angle to ensure vivid and sharp images and video.
3. High refresh rate and high gray scale --- to ensure color consistency and better images

Packaging and shipping
Wooden case or flight case package are available.
Shipping by sea,air or DHL,multiple shipping ways for your choice.

Our team will be forever here to offer you full supports
