Shenzhen Shichuangxinke Electronics Co.,Ltd
professional makes good quality, provide perfect product and service for every customer.
 |
| Place of Origin: | China(Mainland) |
| Brand Name: | SCX |
| Certification: | CE,ISO,FCC,UL |
| Model Number: | SCX-P4 |
| Minimum Order Quantity: | Negotiations |
|---|---|
| Price: | Negotiations |
| Packaging Details: | Carton,wooden and flight cases. |
| Delivery Time: | 12-15 working days. |
| Payment Terms: | T/T, Western Union, , MoneyGram |
| Supply Ability: | 5000sqm/month |
| Usage: | Outdoor | Tube Chip Color: | Full Color |
|---|---|---|---|
| Display Function: | Video | Pixels: | 4mm |
| Led Chip: | Epistar | Module Size: | 256x128mm |
| Weight: | 13KG/PCS | Screen Dimension: | Customized Size |
| Life Span: | 100000hours | Power Supply: | Meanwell |
| Highlight: | led display smd,smd led display |
||
HD Waterproof Customized Size SMD LED Screen P4 Indoor Video Ads RGB Display Epistar 5V 40A
Pre-sale service:
1. respond to inquiries within 24 hours.
2. Conduct market research and forecast for clients.
3. Provide professional solutions according to customers' requirements.
4. Provide samples and all documents according to customers' requirements.
5. Other services, such as factory visit.
After-sale service:
1. Lifetime maintenance and software upgrade.
2. Complaints response time of no more than 24 hours, within 48 hours to provide maintenance guidance and problem solutions. 3.
3. free technician training.
4. provide a full set of documents free of charge, including installation guide, software operation manual, simple maintenance manual and control system software CD-ROM,
Simple maintenance manuals and control system software CD-ROMs.
5. If necessary, engineers will guide the installation on site.
| SMD P4 | |||||
| Resolution/mm | 4 | ||||
| Pixel configuration | 1R1G1B | ||||
| Pixel density/pixels/m² | 62500dots/square meter | ||||
| Module resolution | 64x32mm | ||||
| Module size/mm | 256x128mm | ||||
| View distance | 4-30m | ||||
| Single point brightness adjust | Can be added | ||||
| Single point color adjust | Can be added | ||||
| White balance brightness | 900cd/square meter | ||||
| Color temperature | 6500K-9500K | ||||
| Horizontal view angle | 120(degrees) | ||||
| Vertical view angle | 60(degrees) | ||||
| Signal Process bit | 10 or 16bit | ||||
| Grey process | 1024x1024x1024 16834x16834x16834 65536x65536x65536 | ||||
| Control distances | Internet cable:100m, multimembrane:500m, monofilm:2km | ||||
| Driving mode | Constant driving current | ||||
| Scanning mode | 1/16 SCANNING | ||||
| Frame rate | 60Hz | ||||
| Refresh frequency | 1200Hz | ||||
| Control mode | Computer synchronous | ||||
| Brightness adjusted range | Manual, automatic operation, stepless continuous adjusted | ||||
| 255 steps. No grey loss | |||||
| Out of control point | <1/10000 | ||||
| Working hours | ≥72hours | ||||
| Mean Time Between Failure | >5000hours | ||||
| Life time | 100000hours | ||||
| Life-all-white(brightness halving) | 50000hours | ||||
| Environment temperature range | Operating temperature range: -20-45℃ | ||||
| Self-check technology | LED spot self-check, communications check, power check, | ||||
| temperature monitor(need customization) | |||||
| Remote monitoring | Remote supervision and control, record potential fault, | ||||
| send out warning signs to the operators.(need customization) | |||||
| Software environment | WindowsNT,Windows1999,WindowsXP | ||||
| Luminous point width between centres | Deviation<3% | ||||
| Brightness uniformity | <10% | ||||
| Color uniformity(chromaticity coordinate) | ±0.003 | ||||
| Power supply request | AC85-264V(50Hz-60Hz) | ||||
| Contrast | (1000:1) | ||||
| System protection | Moistureproof,dustproof,high temperature protection,anti-corrosion,anti-burning,anti-static,anti-vibration | ||||
| Humidity(working) | working:10-95% | ||||
| Humidity(storing) | storing:10-95% | ||||
Short details:
1.Flexible and bendable
The flexible chassis and soft cover design allows users to bend freely, so it can be assembled in any uneven or irregular position.
2.Ultra-thin and ultra-light
Flexible LED signs are made of special materials and advanced technology, making them one of the thinnest and lightest LED signs in the world.
Each module weighs only 800 grams.
3. Easy splicing, installation and maintenance
The modular design and no other connecting cables make installation very simple.
Users simply mount the iron sheet or magnetic product on the surface first, and then attach the flexible LED sign to the surface.
4. Low Power Consumption
Maximum power consumption of one module is less than 12W.
