Name: Advertising P3 P4 P5 1200cd/㎡ Full Color High Definition No Smear LED Display
Brand: Shenzhen ShiXin Display Technology Co.,Ltd
SKU: P4
Price: 5,500.00 USD
Availability: InStock

Home Products Indoor Full Color LED Display

Advertising P3 P4 P5 1200cd/㎡ Full Color High Definition No Smear LED Display

Product Details:

Place of Origin:	China
Brand Name:	SCX
Certification:	CE,ROHS,FCC,SASO，CB
Model Number:	P4

Payment & Shipping Terms:

Minimum Order Quantity:	1 SQM
Price:	USD 1000-10000
Packaging Details:	Wooden Case , Size: 60x62x50cm, Wooden Case, Size:70x65x55cm
Delivery Time:	7 working days
Payment Terms:	L/C, D/A, D/P, T/T, Western Union, MoneyGram
Supply Ability:	3000 sqm per month

Contact Now

Detailed Product Description

Led Module:	256*128mm	Pixel Density:	62500 Dots/sqm
Brightness:	≥1200cd/㎡	Color Temperature Condition:	3500K～9500K,(can Be Adjustable)
Led Lamp:	Kinglight/NationStar	Warranty:	4 Years
Pixels:	4mm	Usage:	Indoor
Display Function:	Video	Life Span:	100000 Hours
Cabinet Size:	512512mm78mm
Highlight:	led full color screen , indoor led billboard

HD Commercial Full Color indoor p3 p4 p5 high refresh rate led screen

Product Feature

1) Adopt high-quality Epistar LED chips with strong anti-static ability.

2) Adopt pure copper power cord and copper wire arrangement, stable and long service life.

3) Large viewing angle of more than 140°, smooth display, and excellent visual effects from all angles.

4) Ultra-high brightness, low attenuation, high reliability.

5) High refresh rate, high grayscale, ghosting elimination, low power consumption.

6) Can be designed and maintained on the front or back, convenient and fast maintenance.

7) Pass CE, ROHS, CB, IECEE certification

8) 3-year warranty and lifetime service

Specifications

Name	P4
Plate Size	256mm*128mm.
Resolution	64*32
Pixels pitch	4mm.
Light color	1R 1G 1B
LED lamp	SMD2121
Brightness	≥1200cd/sqm
Drive mode	1/16 scan,constant current
Pixel density	62500dots/sqm
Refresh rate	≥3840HZ
Failed Rate	<0.0001
Best viewing distance	≥4m
MTBF	10000 hrs
Work life	100000hrs
System operating platforms	WIN7WINXPWIN2000 etc.
Data communication	RF/S-video/RGB/RGBHV/YUV/YC/COMPOSITION etc.
Control system	PCTV card+DVI graphic card+control
Control mode	Synchronous/Asynchronous
Max power consumption	≤579W/sqm
Maximum Current	3.8A
Input Voltage(DC)	4.8-5.5v
Operating Environment	Temperature -20℃~+50℃;Humidity, 10%~90%RH.
Working Voltage	AC110V/220V ±10%

Production Process

Advertising P3 P4 P5 1200cd/㎡ Full Color High Definition No Smear LED Display 0

Advertising P3 P4 P5 1200cd/㎡ Full Color High Definition No Smear LED Display 1

Project

Advertising P3 P4 P5 1200cd/㎡ Full Color High Definition No Smear LED Display 2

FAQ

Q1. What about the lead time?

A: Sample needs 3-5 days, and average Production time is 7-15 working days after receiving the deposit.

Q2. Do you have any MOQ limit for led screen order?

A: Yes. Led module: 1 pcs; Led screen: 1 m2.

Q3. What's your payment term?

A: We accept T/T, Alibaba Trade Assurance, Western Union and Cash. At least 30-50 % deposit in advance, and the balance should be

paid before delivery.

Q4: Do you offer guarantee for the products?

A: Yes, we offer 2-5 years warranty to our products. During the warranty period, we can offer you related after-sales service. Our

professional engineering team are ready for your question during 6:00-23:30.

Q5. How about your after-sale service?

A: Our after-sale service as below:

1.We can instruct you how to use and configure your led display, how to do maintenance with spare parts.

2. We can send professional engineer to your city to offer on-site guide and training.

3. We have a professional 8 years technical team and patient sales team answering your question during 6:00-23:30.Q1. What about the lead time?A: Sample needs 3-5 days, and average Production time is 7-15 working days after receiving the deposit.
Q2. Do you have any MOQ limit for led screen order?A: Yes. Led module: 1 pcs; Led screen: 1 m2.
Q3. What's your payment term?A: We accept T/T, Alibaba Trade Assurance, Western Union and Cash. At least 30-50 % deposit in advance, and the balance should be

paid before delivery.
Q4: Do you offer guarantee for the products?A: Yes, we offer 2-5 years warranty to our products. During the warranty period, we can offer you related after-sales service. Our

professional engineering team are ready for your question during 6:00-23:30.
Q5. How about your after-sale service?A: Our after-sale service as below:

1.We can instruct you how to use and configure your led display, how to do maintenance with spare parts.

2. We can send professional engineer to your city to offer on-site guide and training.

3. We have a professional 8 years technical team and patient sales team answering your question during 6:00-23:30.
