Shenzhen Shichuangxinke Electronics Co.,Ltd
professional makes good quality, provide perfect product and service for every customer.
 |
| Place of Origin: | China ,Guang Dong |
| Brand Name: | Shichuangxinke |
| Certification: | CE RoHS FCC CCC TUV UL |
| Model Number: | SCXK-P1.667 |
| Minimum Order Quantity: | 1 square meters |
|---|---|
| Price: | USD 500-8500 per square meters |
| Packaging Details: | wooden box flight case, wooden case, carton, it is up to you. |
| Delivery Time: | 7-10 working days after deposit payment received |
| Payment Terms: | L/C, T/T, Western Union |
| Supply Ability: | 5000sqm per month |
| Pixel Configuration: | 1R1G1B | Resolution/mm: | 1.667 |
|---|---|---|---|
| Scanning Mode: | 1/30 Scanning | Module Size: | 200x150MM |
| Cabinet Size: | 400x300MM | Material: | Aluminum/iron |
| Warranty: | 3-5 Years | IC: | MB5124/MB5024 |
| Certificates: | CE RoHS FCC CCC UL | Application: | Stadium,airport,shopping Mall,street Advertising |
| Highlight: | indoor led billboard,led full color screen |
||
Dust-proof Damp-proof Anti-collision GOB P1.667 indoor LED Display 1/30 Scanning Full Color Screen
Specifications :
| outdoor DIP P1.667 | |||||
| Resolution/mm | 1.667 | ||||
| Pixel configuration | 1R1G1B | ||||
| Pixel density/pixels/m² | 360000/m² | ||||
| Module resolution | 120x90 | ||||
| Module size/mm | 200x150MM | ||||
| View distance | 14-300m | ||||
| Single point brightness adjust | Can be added | ||||
| Single point color adjust | Can be added | ||||
| White balance brightness | >7500cd/㎡ | ||||
| Color temperature | 6500K-9500K | ||||
| Horizontal view angle | 120(degrees) | ||||
| Vertical view angle | 60(degrees) | ||||
| Signal Process bit | 10 or 16bit | ||||
| Grey process | 1024x1024x1024 16834x16834x16834 65536x65536x65536 | ||||
| Control distances | Internet cable:100m, multimembrane:500m, monofilm:2km | ||||
| Driving mode | Constant driving current | ||||
| Scanning mode | 1/30 SCANNING | ||||
| Frame rate | 60Hz | ||||
| Refresh frequency | >3000Hz | ||||
| Control mode | Computer synchronous | ||||
| Brightness adjusted range | Manual, automatic operation, stepless continuous adjusted | ||||
| 255 steps. No grey loss | |||||
| Out of control point | <1/10000 | ||||
| Working hours | ≥72hours | ||||
| Mean Time Between Failure | >5000hours | ||||
| Life time | 100000hours | ||||
| Life-all-white(brightness halving) | 50000hours | ||||
| Environment temperature range | Operating temperature range: -20-45℃ | ||||
| Self-check technology | LED spot self-check, communications check, power check, | ||||
| temperature monitor(need customization) | |||||
| Remote monitoring | Remote supervision and control, record potential fault, | ||||
| send out warning signs to the operators.(need customization) | |||||
| Software environment | WindowsNT,Windows1999,WindowsXP | ||||
| Luminous point width between centres | Deviation<3% | ||||
| Brightness uniformity | <10% | ||||
| Color uniformity(chromaticity coordinate) | ±0.003 | ||||
| Power supply request | AC85-264V(50Hz-60Hz) | ||||
| Contrast | (1000:1) | ||||
| System protection | Moistureproof,dustproof,high temperature protection,anti-corrosion,anti-burning,anti-static,anti-vibration | ||||
| Humidity(working) | working:10-95% | ||||
| Humidity(storing) | storing:10-95% | ||||
Product features:
1) Small pitch, high definition;
2) Perfect & vivid images;
3) High cost performance.
4) Good Consistency and High resolution.
5) High brightness and refresh rate .
6) Easy to install—standard modular design. With snap-fits installation can be done easily and quickly by hands. Fine aluminum frames ensure that modules piece together perfectly.
Trade Terms:
1. Payment method: T/T, 40% deposit before production, 60% balance before shipment.
2. Freight is quoted according to your requirements
3. Port of shipment: Shenzhen, China
4. Warranty period: 2 years. If there is no man-made problem, we will repair it for you free of charge
FAQ:
1. How long could i receive the inquiry reply ?
A: You will get a reply within 24 hours.
2.How long do you provide warranty time ?
A: Different product offer different time frame warranty, but all product here we offer 2 year at least warranty
3.How long will it take to deliver goods ?
A: We will start preparing goods when we get your bank receipt. The package will be shipped out in 1-2 working days after we get your payment.
4.What about your pre-sale service and post-sale service?
A: For pre-sale service: We have a professional sales team and a 12 years technical team who are willing to answer your question 24/7. We can offer a whole complete solution for your project!
For post-sale service: We can instruct you how to use, adjust the screens, and change the boken modules with spare parts.
Also, we can send technicals to your country to solve problems. Mostly, our led display will not have big problems within warranty time!
5. How can you ensure the led display product quality?
A: Our led display screen quality is our core competence, for 7 years, what we rely on.We have each stardard process to make quality products.
If any quality failures within warranty time, we will refund you on alibaba.
