GOB COB P1.56 P1.667 P1.923 Advertising LED Screen Indoor Waterproof High Definition Led Video Wall

GOB COB P1.56 P1.667 P1.923 Advertising LED Screen Indoor Waterproof High Definition Led Video Wall

GOB COB P1.56 P1.667 P1.923 Advertising LED Screen Indoor Waterproof High Definition Led Video Wall
GOB COB P1.56 P1.667 P1.923 Advertising LED Screen Indoor Waterproof High Definition Led Video Wall

Product Details:

Place of Origin: China
Brand Name: SCXK
Certification: CE,ROHS,FC,SASO
Model Number: P1.667

Payment & Shipping Terms:

Minimum Order Quantity: 1 SQM
Price: USD 500-1000
Packaging Details: Flight Case , Size: 60x62x50cm, Wooden Case, Size:70x65x55cm
Delivery Time: 10-20 working days
Payment Terms: L/C, D/A, D/P, T/T, Western Union, MoneyGram
Supply Ability: 1000 sqm per month
Contact Now
Detailed Product Description
Step Pixels: 1.667mm LED Shape & Size: 1.667mm SMD 1010
Module Dimension: 200 Mm X 150 Mm Module Resolution: 120 X 90
Viewing Angle: Horizontal 140° Vertical 120° Driving Method: 1/30
Led Chip: Epistar Led Lamp: NationStar
Refresh Rate: ≧3840HZ
High Light:

P1.923 led advertising board

,

P1.667 led advertising screen

New 2020 GOB COB P1.56 P1.667 P1.923 waterproof dampproof Advertising Led Screens for meeting room, events





GOB Features

1, Cabinet size:400*300mm;
2, Light weight and slim design;
3, 100% front maintenance service available;
4, 27" golden aspect ratio 16:9 cabinet size;
5, Cabinet with side quick lock & position pin;
6, High gray scale at even low brightness;
7, Ultra wide view angle and superior display effect

8.Glue on board technology to make sure its waterproof, dustproof, anti-collision, anti-uv

9. Reliable quality LEDs and IC to reduce maintenance cost .





Company Introduction



SCX LED has been devoting to high-quality LED display designing & manufacturing for over 12 years.
Fully equipped with professional team and modern facilities to manufacture fine LED display products, Hot Electronics make products that have found wide application in airports, stations, ports, gymnasiums, banks, schools, churches, etc.
Our LED products are widely spread across 100 countries all over world, covering Asia, Middle East, America, Europe and Africa.
From stadium to TV station, to conference & events, Hot Electronics provides a wide range of eye-catching and energy efficient LED
screen solutions to industrial, commercial and governmental markets worldwide.



GOB COB P1.56 P1.667 P1.923 Advertising LED Screen Indoor Waterproof High Definition Led Video Wall 0





Pamameter



      Module
Pixel Pitch
P1.667
Module Size
200x150mm
Module Resolution
166x187 pixels
LED Lamp
SMD1010




LED Panel
Cabinet Size
400x300mm
Cabinet Resolution
240x180 pixels
Cabinet Materials
Die-casting Aluminum
Cabinet Weight
≦6.5kg
Pixel Density
648000 pixels/m2
Brightness
≦1000cd
Refresh Rate
≧3840HZ






LED Screen
Grey Scale
14-16 bit
Avg.Power Consumption
100W/㎡
Max.Power Consumption
300W/㎡
View Angle
V 160°/ H 160°
IP Rate
IP30
Service
Front / Rear Maintenance
Working Environment
-20℃~50℃, 10%-90% RH
Storage Environment
-40℃~60℃, 10%-90% RH
Input Signal
VGA,DVI,HDMI,SDI,etc





Product Description
16:9 Golden Ratio Design, 2k 4k 8k Perfect Display
16:9 cabinet size design, point-to-point matching 2K/4K/8K standard resolution; front maintenance design, wall-mountable installation, easy installation and maintenance; automatic brightness adjustment technology, ensuring viewers in any environment to watch comfortably; support power and signal redundancy backup to meet the needs of high security applications.

GOB COB P1.56 P1.667 P1.923 Advertising LED Screen Indoor Waterproof High Definition Led Video Wall 1



FAQ



Q1. Can I have a sample order for LED display?

A: Yes, we welcome sample order to test and check quality. Both for module or whole screen.

Q2. What about the lead time?

A:Order less than 100 square meter led time take 15 working days

Q3. Do you have any MOQ limit for LED display order?

A: Low MOQ, 1 square meter or a moudle checking is available

Q4. How do you ship the goods and how long does it take to arrive?

A: We mostly accectp FOB train term, but we can help you order and arrange shipping agent. It usually take 20 30 day on sea. a few days for customer clearance

Q5. How to proceed an order for LED display?

A: Firstly let us know your requirements or application.

Secondly We quote according to your requirements or our suggestions.
Thirdly customer confirms the design document and places deposit for formal order.
Fourthly We arrange the production.

Q6. Is it OK to print my logo on the products?

A: Yes. Please inform us formally before our production and confirm the design firstly based on our sample.

Q7: Do you offer guarantee for the products?

A: Yes, we offer 1 years warranty to our products

Q8: How to deal with the faulty?

A: Firstly, Our products are produced in strict quality control system and the defective rate will be less
than 0.2%.
Secondly, during the guarantee period, we will send new module with new order for small quantity.

For defective batch products, we will repair them and resend them to you or we can discuss the solution

including re-call according to real situation.
