Die-Cast Aluminum Enclosure HD Flexible Module Indoor COB P2.5 P2 Flexible LED Module For Advertising Screen

Brand Name:	SCXK
Model Number:	SCXK-P2
MOQ:	Negotiations
Price:	Negotiations
Payment Terms:	Western Union, T/T
Supply Ability:	5000sqs/month

Detail Information

Product Description

Detail Information

Place of Origin:

China(Mianland)

Certification:

CE,RoHS,FCC,CCC,SAA,TUV,UL

Brand Name:

RGB LED Display

Brightness:

≥1200cd/sq

Certifications:

CE,RoHS,FCC,CCC,SAA,TUV,UL

LED Chip:

Epistar

Scan Mode:

1/32

Waterproof:

IP34

Operation Power:

220V 60HZ

Module Size:

256*128mm

Cabinet Size:

512*512mm

Control System:

LSN

Pixel Density:

250000dots/sq

Resolution:

128*64

LED Type:

SMD2121

Indoor Options:

P1.667,P1.923,P2,P2.5,P3,P3.91,P4,P5,P6,P10...

Packaging Details:

Wooden and flight cases,it's up to you.

Highlight:

P2 commercial led display

Flexible retail led display

Product Description

Indoor P2 Flexible LED Module HD Soft Video Wall Advertising LED Display

Specifications :

Indoor P2 LED Display
Resolution/mm	2
Pixel configuration	1R1G1B
Pixel density/pixels/m²	250000/square meter
Module resolution	128x64
Module size/mm	256x128
View distance	14-300m
Single point brightness adjust	Can be added
Single point color adjust	Can be added
White balance brightness	>1200cd/square meter
Color temperature	6500K-9500K
Horizontal view angle	120(degrees)
Vertical view angle	60(degrees)
Signal Process bit	10 or 16bit
Grey process	1024x1024x1024 16834x16834x16834 65536x65536x65536
Control distances	Internet cable:100m, multimembrane:500m, monofilm:2km
Driving mode	Constant driving current
Scanning mode	1/32 SCANNING
Frame rate	60Hz
Refresh frequency	>3000Hz
Control mode	Computer synchronous
Brightness adjusted range	Manual, automatic operation, stepless continuous adjusted
	255 steps. No grey loss
Out of control point	<1/10000
Working hours	≥72hours
Mean Time Between Failure	>5000hours
Life time	100000hours
Life-all-white(brightness halving)	50000hours
Environment temperature range	Operating temperature range: -20-45℃
Self-check technology	LED spot self-check, communications check, power check,
	temperature monitor(need customization)
Remote monitoring	Remote supervision and control, record potential fault,
	send out warning signs to the operators.(need customization)
Software environment	WindowsNT,Windows1999,WindowsXP
Luminous point width between centres	Deviation<3%
Brightness uniformity	<10%
Color uniformity(chromaticity coordinate)	±0.003
Power supply request	AC85-264V(50Hz-60Hz)
Contrast	(1000:1)
System protection	Moistureproof,dustproof,high temperature protection,anti-corrosion,anti-burning,anti-static,anti-vibration
Humidity(working)	working:10-95%
Humidity(storing)	storing:10-95%

Die-Cast Aluminum Enclosure HD Flexible Module Indoor COB P2.5 P2 Flexible LED Module For Advertising Screen 0

Die-Cast Aluminum Enclosure HD Flexible Module Indoor COB P2.5 P2 Flexible LED Module For Advertising Screen 3

Die-Cast Aluminum Enclosure HD Flexible Module Indoor COB P2.5 P2 Flexible LED Module For Advertising Screen 5

Die-Cast Aluminum Enclosure HD Flexible Module Indoor COB P2.5 P2 Flexible LED Module For Advertising Screen 6
