Wide-Angle Screen, Large Viewing Angle, Rental Screen, 5500cd/M2 Stadium High-Definition Waterproof LED Display

Wide-Angle Screen, Large Viewing Angle, Rental Screen, 5500cd/M2 Stadium High-Definition Waterproof LED Display

  • Wide-Angle Screen, Large Viewing Angle, Rental Screen, 5500cd/M2 Stadium High-Definition Waterproof LED Display
  • Wide-Angle Screen, Large Viewing Angle, Rental Screen, 5500cd/M2 Stadium High-Definition Waterproof LED Display
  • Wide-Angle Screen, Large Viewing Angle, Rental Screen, 5500cd/M2 Stadium High-Definition Waterproof LED Display
  • Wide-Angle Screen, Large Viewing Angle, Rental Screen, 5500cd/M2 Stadium High-Definition Waterproof LED Display
Wide-Angle Screen, Large Viewing Angle, Rental Screen, 5500cd/M2 Stadium High-Definition Waterproof LED Display
Product Details:
Place of Origin: China(Mainland)
Brand Name: SCXK
Certification: CE,ISO,DCC,UL
Model Number: SCXK-P10
Payment & Shipping Terms:
Minimum Order Quantity: Negotiations
Price: 345-456USD/sqm
Packaging Details: Wooden and flight cases.
Delivery Time: 12-15 working days.
Payment Terms: T/T, Western Union, MoneyGram
Supply Ability: 5000 sqm/month
Contact Now
Detailed Product Description
Country Of Origin: China Brand: SCXK
Cabinet: Iron Brightness: 5500cd/sqm
Cabinet Size: 960*960mm Pixel Pitch: 10mm
Module Size: 320*160mm Pixel Density: 10000dots/sqm
Warranty: 3-5 Years Certificate: CE,ISO,DCC,UL
Highlight:

5500cd/sqm perimeter led display

,

Front led stadium display



Energy Saving Wide Angle Front Rear Access Optional Panel Screen Display Stadium Perimeter Board For Outdoor Advertising





Stadium Perimeter Ourdoor Series:



1. Outdoor full-color LED display screens are widely used, especially in today's rapidly developing era.

In the era of information explosion, the use of full-color display screens can be said to have reached its peak.

Major supermarkets, offline entities, and public relations media are inevitably used, especially in large-scale events, such as award ceremonies, concerts, weddings and entertainment.



2. Another major advantage of full-color display screens is energy saving and environmental protection,

This is very consistent with the theme of the current era, and is increasingly favored by the national government;

Generally speaking, many government projects are like this. Therefore, buying good products at a preferential price is your way to make money.



3. Our company has been established for more than ten years and has rich product

experience and sales services. At present, our products have been exported to more than 20 countries overseas

and have established long-term cooperative relations. In the future, we hope that you can become our next customer!





Our service:


1.Your inquiry related to our products or prices will be replied in 24hrs.


2.Well-trained and experienced staffs to answer all your enquires in fluent English .


3.OEM&ODM, any your customized screen we can help you to design and put into product.


4.Distributoer ship are offered for your unique design and some our current models .


5.Protection of your sales area, ideas of design and all your private information





Stadium Perimeter Specifications :



Outdoor Stadium P10 LED Display Screen
Resolution/mm 10
Pixel configuration 1R1G1B
Pixel density/pixels/m² 10000/square meter
Module resolution 32x16
Module size/mm 320x160
View distance 10-80m
Single point brightness adjust Can be added
Single point color adjust Can be added
White balance brightness 5500cd/square meter
Color temperature 6500K-9500K
Horizontal view angle 120(degrees)
Vertical view angle 60(degrees)
Signal Process bit 10 or 16bit
Grey process 1024x1024x1024 16834x16834x16834 65536x65536x65536
Control distances Internet cable:100m, multimembrane:500m, monofilm:2km
Driving mode Constant driving current
Scanning mode 1/4 SCANNING
Frame rate 60Hz
Refresh frequency >1200Hz
Control mode Computer synchronous
Brightness adjusted range Manual, automatic operation, stepless continuous adjusted
255 steps. No grey loss
Out of control point <1/10000
Working hours ≥72hours
Mean Time Between Failure >5000hours
Life time 100000hours
Life-all-white(brightness halving) 50000hours
Environment temperature range Operating temperature range: -20-45℃
Self-check technology LED spot self-check, communications check, power check,
temperature monitor(need customization)
Remote monitoring Remote supervision and control, record potential fault,
send out warning signs to the operators.(need customization)
Software environment WindowsNT,Windows1999,WindowsXP
Luminous point width between centres Deviation<3%
Brightness uniformity <10%
Color uniformity(chromaticity coordinate) ±0.003
Power supply request AC85-264V(50Hz-60Hz)
Contrast (1000:1)
System protection Moistureproof,dustproof,high temperature protection,anti-corrosion,anti-burning,anti-static,anti-vibration
Humidity(working) working:10-95%
Humidity(storing) storing:10-95%





Some customers' concerns:



1. With a large initial investment, can you really make money?

- There is an old Chinese saying: Don't give up when the wolf comes.

If you want to do business, you must have foresight, patience and investment.

But the most important thing is that you should choose the right product, just like our product, which is suitable for many fields,

After choosing it, you should firmly believe that the product can bring you advantages.



2. I have never heard of your brand, how can I trust you?

- There are many things in the world that you have never seen, and you must have something you have bought at home, which is also a small brand, but it works well.

We can't guarantee that all our things are too famous to let everyone know, but we can guarantee you high quality and reasonable prices. The only thing you need to do is to give us a chance and try to trust us, we will not let you down!





Our company:



Shenzhen ShiChuangXin Ke Electronic Co.,Ltd is a high-tech enterprise integrating R&D, design, production, marketing and after-sales service of LED displays.

We can offer all types of indoor and outdoor led display, and it's videly used in banking, communicatins offices, electric power industry, traffic, stadiums and sporting area, business plaza, entertainment for the applications of advertising, sports,event, stock/ sport news ticker, message center, price etc. The basic LED cabinet are easier for customers' installation and maintenance to meet the market requirement.

We are also renowned for building custom LED Display that will meet your unique and specific need. More importantly, we are committed to providing quality products at competitive prices and superior customer services. With the quality management sustem ISO9001, the strong R&D and manufacturing group, SCXK became one of the leading companies or LED display industry in Shenzhen.

Wide-Angle Screen, Large Viewing Angle, Rental Screen, 5500cd/M2 Stadium High-Definition Waterproof LED Display 0Wide-Angle Screen, Large Viewing Angle, Rental Screen, 5500cd/M2 Stadium High-Definition Waterproof LED Display 1Wide-Angle Screen, Large Viewing Angle, Rental Screen, 5500cd/M2 Stadium High-Definition Waterproof LED Display 2Wide-Angle Screen, Large Viewing Angle, Rental Screen, 5500cd/M2 Stadium High-Definition Waterproof LED Display 3

Wide-Angle Screen, Large Viewing Angle, Rental Screen, 5500cd/M2 Stadium High-Definition Waterproof LED Display 4





FAQ:



Q1: What's the warranty of your LED Display Screen ?

A1: We have a 3-year warranty for our led display screen, and 100,000 hours life span of the led lamps.

Q2: What about your pre-sale service and post-sale service?

A2: For pre-sale service: We have a professional sales team and 13 years technical team who are willing to answer your question 24/7. We can offer a whole complete solution for your project!
For post-sale service: We can instruct you how to use, adjust the screens, and change the broken modules with spare parts.
Also, we can send technicians to your country to solve problems. Mostly, our led display will not have big problems within warranty time!

Q3: Whats your payment term? How long it takes to delivery?

A3: We accept T/T and L/C, For both T/T and L/C, At least 30% deposit in advance, and the rest 70% before delivery.
Our average Production time is 16 days, after receiving the deposit.

Q4: What's the control system?

A4: For synchronization control: We use Nova, Linsn Or Colorlight control system.
For asynchronous control: We use ONBON or XIXUN control system.

Q5: How can you ensure the led display product quality?

A5: Our led display screen quality is our core competence, for 8 years, what we rely on.
We have each standard process to make quality products.
If any quality failures within warranty time, we will refund you .





Welcome to visit our website and inquire us!!!
